MSP430FR5889IRGCT Information
MSP430FR5889IRGCT by Texas Instruments is a Microcontroller.
Microcontrollers are under the broader part category of Microcontrollers and Processors.
Microcontrollers (MCUs) are small, low-power integrated circuits used to control embedded systems. Microcontrollers are primarily used to automate and control devices. Read more about Microcontrollers and Processors on our Microcontrollers and Processors part category page.
Available Datasheets
| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| MSP430FR5889IRGCT | Texas Instruments | MSP430FR5889 16 MHz ULP Microcontroller featuring 128 KB FRAM, 2 KB SRAM, 40 IO, ADC12, Scan IF 64-VQFN -40 to 85 |
Price & Stock for MSP430FR5889IRGCT
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
296-42019-1-ND
|
DigiKey | IC MCU 16BIT 128KB FRAM 64VQFN Min Qty: 1 Lead time: 12 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
250 In Stock |
|
$5.2375 / $8.8900 | Buy Now |
|
DISTI #
595-SP430FR5889IRGCT
|
Mouser Electronics | 16-bit Microcontrollers - MCU Ultra low power MCU A 595-SP430FR5889IRGCR RoHS: Compliant | 0 |
|
$5.2300 / $8.8900 | Order Now |
|
|
Vyrian | Peripheral ICs | 418 |
|
RFQ |
Part Details for MSP430FR5889IRGCT
MSP430FR5889IRGCT CAD Models
MSP430FR5889IRGCT Part Data Attributes
|
|
MSP430FR5889IRGCT
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
MSP430FR5889IRGCT
Texas Instruments
Rotary Sensing MCU with extended scan interface, 128KB FRAM, 2KB SRAM for flow meters 64-VQFN -40 to 85
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Package Description | VQFN-64 | |
| Reach Compliance Code | compliant | |
| ECCN Code | 5A992.C | |
| HTS Code | 8542.31.00.01 | |
| Samacsys Manufacturer | Texas Instruments | |
| Has ADC | YES | |
| Address Bus Width | ||
| Bit Size | 16 | |
| Boundary Scan | YES | |
| CPU Family | MSP430 | |
| Clock Frequency-Max | 24 MHz | |
| DAC Channels | NO | |
| DMA Channels | YES | |
| External Data Bus Width | ||
| Format | FIXED POINT | |
| Integrated Cache | YES | |
| JESD-30 Code | S-PQCC-N64 | |
| JESD-609 Code | e4 | |
| Length | 9 mm | |
| Low Power Mode | YES | |
| Moisture Sensitivity Level | 3 | |
| Number of DMA Channels | 3 | |
| Number of External Interrupts | ||
| Number of I/O Lines | 48 | |
| Number of Serial I/Os | 3 | |
| Number of Terminals | 64 | |
| Number of Timers | 5 | |
| On Chip Data RAM Width | 8 | |
| On Chip Program ROM Width | 8 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| PWM Channels | YES | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | HVQCCN | |
| Package Shape | SQUARE | |
| Package Style | CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE | |
| Peak Reflow Temperature (Cel) | 260 | |
| RAM (bytes) | 2048 | |
| RAM (words) | 2 | |
| ROM (words) | 131072 | |
| ROM Programmability | FRAM | |
| Seated Height-Max | 1 mm | |
| Speed | 16 MHz | |
| Supply Current-Max | 1.62 mA | |
| Supply Voltage-Max | 3.6 V | |
| Supply Voltage-Min | 3 V | |
| Supply Voltage-Nom | 3 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | NO LEAD | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | QUAD | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 9 mm | |
| uPs/uCs/Peripheral ICs Type | MICROCONTROLLER, RISC |
MSP430FR5889IRGCT Frequently Asked Questions (FAQ)
-
The maximum operating temperature range for the MSP430FR5889IRGCT is -40°C to 85°C, but it can be extended to -40°C to 105°C with some limitations on the clock frequency and supply voltage.
-
To configure the MSP430FR5889IRGCT for low-power operation, you can use the Power Management Module (PMM) to select the lowest possible clock frequency, disable unused peripherals, and use the Low Power Mode 3 (LPM3) or Low Power Mode 4 (LPM4) modes. You can also use the FRAM retention mode to reduce power consumption.
-
The maximum frequency of the MSP430FR5889IRGCT's CPU is 16 MHz, but it can be overclocked to 24 MHz with some limitations on the supply voltage and temperature range.
-
The MSP430FR5889IRGCT's FRAM (Ferroelectric Random Access Memory) can be used as a non-volatile memory for data storage. You can access the FRAM using the FRAM controller, and you need to follow the specific programming and erase procedures to ensure data integrity.
-
The JTAG (Joint Test Action Group) interface on the MSP430FR5889IRGCT is used for debugging and programming the device. It allows you to connect a debugger or programmer to the device and perform tasks such as flashing the firmware, debugging code, and performing boundary scan tests.
