Part Symbol
-
Footprint
-
3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
Part Details for MSP430F67791AIPZ by Texas Instruments
Results Overview of MSP430F67791AIPZ by Texas Instruments
- Distributor Offerings: (5 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (1 option)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
MSP430F67791AIPZ Information
MSP430F67791AIPZ by Texas Instruments is an Other uP/uC/Peripheral IC.
Other uPs/uCs/Peripheral ICs are under the broader part category of Microcontrollers and Processors.
Microcontrollers (MCUs) are small, low-power integrated circuits used to control embedded systems. Microcontrollers are primarily used to automate and control devices. Read more about Microcontrollers and Processors on our Microcontrollers and Processors part category page.
Available Datasheets
| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| MSP430F67791AIPZR | Texas Instruments | Polyphase Metering SoC with 7 Sigma-Delta ADCs, LCD, Real-Time Clock, 512KB Flash, 32KB RAM 100-LQFP -40 to 85 | |
| MSP430F67791AIPZ | Texas Instruments | Polyphase Metering SoC with 7 Sigma-Delta ADCs, LCD, Real-Time Clock, 512KB Flash, 32KB RAM 100-LQFP -40 to 85 |
Price & Stock for MSP430F67791AIPZ
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
296-MSP430F67791AIPZCT-ND
|
DigiKey | IC MCU 16BIT 512KB FLASH 100LQFP Min Qty: 1 Lead time: 12 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
83 In Stock |
|
$9.8905 / $15.7600 | Buy Now |
|
DISTI #
595-P430F67791AIPZ
|
Mouser Electronics | Metering Systems on a Chip - SoC Ultra low power Micr o Controller A 595-P430F67791AIPZR RoHS: Compliant | 35 |
|
$9.8900 / $15.7600 | Buy Now |
|
DISTI #
MSP430F67791AIPZ
|
TME | IC: microcontroller, LQFP100, 32kBSRAM,512kBFLASH, 1.8÷3.6VDC Min Qty: 1 | 0 |
|
$11.8000 / $18.3000 | RFQ |
|
|
Vyrian | Peripheral ICs | 779 |
|
RFQ | |
|
|
Win Source Electronics | IC MCU 16BIT 512KB FLASH 100LQFP / MSP430 CPUXV2 MSP430F6xx Microcontroller IC 16-Bit 25MHz 512KB (512K x 8) FLASH 100-LQFP (14x14) | 4000 |
|
$13.0470 / $19.5705 | Buy Now |
Part Details for MSP430F67791AIPZ
MSP430F67791AIPZ CAD Models
MSP430F67791AIPZ Part Data Attributes
|
|
MSP430F67791AIPZ
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
MSP430F67791AIPZ
Texas Instruments
Polyphase metering SoC with 7 Sigma-Delta ADCs, LCD, real-time clock, 512KB Flash, 32KB RAM 100-LQFP -40 to 85
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Part Package Code | QFP | |
| Package Description | LQFP-100 | |
| Pin Count | 100 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.31.00.01 | |
| Samacsys Manufacturer | Texas Instruments | |
| Has ADC | YES | |
| Additional Feature | IT ALSO OPERATES IN 1.8V MINIMUM SUPPLY | |
| Address Bus Width | ||
| Bit Size | 16 | |
| Bus Compatibility | I2C; SPI; UART | |
| CPU Family | MSP430 | |
| Clock Frequency-Max | 25 MHz | |
| DAC Channels | NO | |
| DMA Channels | YES | |
| External Data Bus Width | ||
| JESD-30 Code | S-PQFP-G100 | |
| JESD-609 Code | e4 | |
| Length | 14 mm | |
| Moisture Sensitivity Level | 3 | |
| Number of I/O Lines | 62 | |
| Number of Terminals | 100 | |
| On Chip Program ROM Width | 8 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| PWM Channels | YES | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | LFQFP | |
| Package Shape | SQUARE | |
| Package Style | FLATPACK, LOW PROFILE, FINE PITCH | |
| Peak Reflow Temperature (Cel) | 260 | |
| RAM (bytes) | 32768 | |
| RAM (words) | 32 | |
| ROM (words) | 524288 | |
| ROM Programmability | FLASH | |
| Seated Height-Max | 1.6 mm | |
| Speed | 25 MHz | |
| Supply Voltage-Max | 3.6 V | |
| Supply Voltage-Min | 2.4 V | |
| Supply Voltage-Nom | 3.3 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | QUAD | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 14 mm | |
| uPs/uCs/Peripheral ICs Type | SoC |
Alternate Parts for MSP430F67791AIPZ
This table gives cross-reference parts and alternative options found for MSP430F67791AIPZ. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of MSP430F67791AIPZ, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| MSP430F67791AIPZR | Texas Instruments | $5.6718 | Polyphase metering SoC with 7 Sigma-Delta ADCs, LCD, real-time clock, 512KB Flash, 32KB RAM 100-LQFP -40 to 85 | MSP430F67791AIPZ vs MSP430F67791AIPZR |
MSP430F67791AIPZ Frequently Asked Questions (FAQ)
-
The maximum clock frequency of the MSP430F67791AIPZ is 8 MHz.
-
To configure the MSP430F67791AIPZ for low power consumption, use the Low Power Mode 3 (LPM3) or Low Power Mode 4 (LPM4) modes, which can reduce power consumption to as low as 1.1 μA. Additionally, disable unused peripherals and use the Power Manager to control power consumption.
-
Yes, the MSP430F67791AIPZ can operate with a power supply voltage range of 1.8V to 3.6V, making it compatible with 3.3V power supplies.
-
The MSP430F67791AIPZ can be programmed using the Spy-Bi-Wire (SBW) interface, which is a 2-wire interface that allows for programming and debugging. You can use the Texas Instruments Code Composer Studio (CCS) or IAR Embedded Workbench to program the device.
-
The MSP430F67791AIPZ has 256 KB of flash memory available for program storage.
