MSP430F5522IRGCR by:

25 MHz MCU with 32KB Flash, 8KB SRAM, 12-bit ADC, comparator, DMA, UART/SPI/I2C, USB, HW multiplier 64-VQFN -40 to 85

Part Details for MSP430F5522IRGCR by Texas Instruments

Results Overview of MSP430F5522IRGCR by Texas Instruments

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Security and Surveillance Space Technology Environmental Monitoring Internet of Things (IoT) Smart Cities Transportation and Logistics Agriculture Technology Telecommunications Communication and Networking Automotive Robotics and Drones

MSP430F5522IRGCR Information

MSP430F5522IRGCR by Texas Instruments is a Microcontroller.
Microcontrollers are under the broader part category of Microcontrollers and Processors.

Microcontrollers (MCUs) are small, low-power integrated circuits used to control embedded systems. Microcontrollers are primarily used to automate and control devices. Read more about Microcontrollers and Processors on our Microcontrollers and Processors part category page.

Price & Stock for MSP430F5522IRGCR

Part # Distributor Description Stock Price Buy
DISTI # 296-MSP430F5522IRGCRCT-ND
DigiKey IC MCU 16BIT 32KB FLASH 64VQFN Min Qty: 1 Lead time: 18 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) 3399
In Stock
  • 1 $4.1100
  • 10 $3.1070
  • 25 $2.8568
  • 100 $2.5824
  • 250 $2.4514
  • 500 $2.3725
  • 1,000 $2.3075
  • 2,000 $2.0550
$2.0550 / $4.1100 Buy Now
DISTI # 595-MSP430F5522IRGCR
Mouser Electronics 16-bit Microcontrollers - MCU Mixed Signal Micro c ontroller A 595-MSP430F5522IRGCT RoHS: Compliant 1933
  • 1 $4.1100
  • 10 $2.8600
  • 100 $2.5900
  • 250 $2.4500
  • 500 $2.3700
  • 1,000 $2.3100
  • 2,000 $2.0500
$2.0500 / $4.1100 Buy Now
ComSIT USA MIXED-SIGNAL MICROCONTROLLER RISC Microcontroller, 16-Bit, FLASH, MSP430 CPU, 25MHz, CMOS, PQCC64 ECCN: EAR99 RoHS: Compliant Stock DE - 6350
Stock ES - 0
Stock US - 0
Stock MX - 0
Stock CN - 0
Stock HK - 0
RFQ
Velocity Electronics Our Stock 9
RFQ
LCSC Other Series 25MHz VQFN-64-EP(9x9) Microcontrollers (MCU/MPU/SOC) ROHS 10
  • 1 $6.1245
  • 10 $5.1053
  • 30 $4.5454
  • 100 $3.9127
$3.9127 / $6.1245 Buy Now
Vyrian Peripheral ICs 27545
RFQ
Win Source Electronics IC MCU 16BIT 32KB FLASH 64VQFN 3700
  • 15 $4.0282
  • 35 $3.3051
  • 55 $3.2019
  • 75 $3.0986
  • 97 $2.9953
  • 130 $2.6854
$2.6854 / $4.0282 Buy Now

Part Details for MSP430F5522IRGCR

MSP430F5522IRGCR CAD Models

  • Part Symbol

    Part Symbol

  • Footprint

    footprint

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

MSP430F5522IRGCR Part Data Attributes

Parametric Data
MSP430F5522IRGCR Texas Instruments
Buy Now Datasheet
Compare Parts:
MSP430F5522IRGCR Texas Instruments 25 MHz MCU with 32KB Flash, 8KB SRAM, 12-bit ADC, comparator, DMA, UART/SPI/I2C, USB, HW multiplier 64-VQFN -40 to 85
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer TEXAS INSTRUMENTS INC
Part Package Code QFN
Package Description GREEN, PLASTIC, VQFN-64
Pin Count 64
Reach Compliance Code compliant
ECCN Code EAR99
HTS Code 8542.31.00.01
Samacsys Manufacturer Texas Instruments
Has ADC YES
Additional Feature ALSO OPERATES AT 1.8 MINIMUM SUPPLY AT 8 MHZ
Address Bus Width
Bit Size 16
Boundary Scan YES
CPU Family MSP430
Clock Frequency-Max 32 MHz
DAC Channels NO
DMA Channels YES
External Data Bus Width
Format FIXED POINT
Integrated Cache NO
JESD-30 Code S-PQCC-N64
JESD-609 Code e4
Length 9 mm
Low Power Mode YES
Moisture Sensitivity Level 3
Number of DMA Channels 3
Number of External Interrupts
Number of I/O Lines 47
Number of Serial I/Os 4
Number of Terminals 64
Number of Timers 4
On Chip Data RAM Width 8
On Chip Program ROM Width 8
Operating Temperature-Max 85 °C
Operating Temperature-Min -40 °C
PWM Channels YES
Package Body Material PLASTIC/EPOXY
Package Code HVQCCN
Package Equivalence Code LCC64,.35SQ,20
Package Shape SQUARE
Package Style CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE
Peak Reflow Temperature (Cel) 260
Qualification Status Not Qualified
RAM (bytes) 8192
RAM (words) 8
ROM (words) 32768
ROM Programmability FLASH
Seated Height-Max 1 mm
Speed 25 MHz
Supply Current-Max 11 mA
Supply Voltage-Max 3.6 V
Supply Voltage-Min 3 V
Supply Voltage-Nom 3 V
Surface Mount YES
Technology CMOS
Temperature Grade INDUSTRIAL
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Form NO LEAD
Terminal Pitch 0.5 mm
Terminal Position QUAD
Time@Peak Reflow Temperature-Max (s) 30
Width 9 mm
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC

Alternate Parts for MSP430F5522IRGCR

This table gives cross-reference parts and alternative options found for MSP430F5522IRGCR. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of MSP430F5522IRGCR, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
MSP430F5513IRGCR Texas Instruments $1.5920 25 MHz MCU with 32KB Flash, 4KB SRAM, comparator, DMA, UART/SPI/I2C, USB, timer, HW multiplier 64-VQFN -40 to 85 MSP430F5522IRGCR vs MSP430F5513IRGCR
MSP430F5308IRGCT Texas Instruments $1.7180 25 MHz MCU with 16KB Flash, 6KB SRAM, 10-bit ADC, comparator, DMA, UART/SPI/I2C, HW multiplier 64-VQFN -40 to 85 MSP430F5522IRGCR vs MSP430F5308IRGCT
MSP430F5526IRGCT Texas Instruments $3.1597 25 MHz MCU with 96KB Flash, 6KB SRAM, 12-bit ADC, comparator, DMA, UART/SPI/I2C, USB, HW multiplier 64-VQFN -40 to 85 MSP430F5522IRGCR vs MSP430F5526IRGCT
MSP430F5524IRGCR Texas Instruments $3.2817 25 MHz MCU with 64KB Flash, 4KB SRAM, 12-bit ADC, comparator, DMA, UART/SPI/I2C, USB, HW multiplier 64-VQFN -40 to 85 MSP430F5522IRGCR vs MSP430F5524IRGCR
MSP430F5528IRGCR Texas Instruments $3.6047 25 MHz MCU with 128KB Flash, 8KB SRAM, 12-bit ADC, comparator, DMA, UART/SPI/I2C, USB, HW multiplier 64-VQFN -40 to 85 MSP430F5522IRGCR vs MSP430F5528IRGCR
MSP430F5513IRGCT Texas Instruments Check for Price 16-BIT, FLASH, 25MHz, RISC MICROCONTROLLER, PQCC64, GREEN, PLASTIC, VQFN-64 MSP430F5522IRGCR vs MSP430F5513IRGCT
MSP430F5526IRGCR Texas Instruments Check for Price 25 MHz MCU with 96KB Flash, 6KB SRAM, 12-bit ADC, comparator, DMA, UART/SPI/I2C, USB, HW multiplier 64-VQFN -40 to 85 MSP430F5522IRGCR vs MSP430F5526IRGCR
MSP430F5310IRGC Texas Instruments Check for Price IC 16-BIT, FLASH, 25 MHz, RISC MICROCONTROLLER, PQCC64, PLASTIC, VQFN-64, Microcontroller MSP430F5522IRGCR vs MSP430F5310IRGC
MSP430F5309IRGC Texas Instruments Check for Price IC 16-BIT, FLASH, 25 MHz, RISC MICROCONTROLLER, PQCC64, PLASTIC, VQFN-64, Microcontroller MSP430F5522IRGCR vs MSP430F5309IRGC
MSP430F5526IRGC Texas Instruments Check for Price 16-BIT, FLASH, 25MHz, RISC MICROCONTROLLER, PQCC64, PLASTIC, VQFN-64 MSP430F5522IRGCR vs MSP430F5526IRGC

MSP430F5522IRGCR Related Parts

MSP430F5522IRGCR Frequently Asked Questions (FAQ)

  • The maximum clock frequency of the MSP430F5522IRGCR is 25 MHz.

  • To configure the MSP430F5522IRGCR for low power consumption, use the low-power modes (LPM3, LPM4) and adjust the clock frequency, disable unused peripherals, and use the Power Management Module (PMM) to control power consumption.

  • Yes, the MSP430F5522IRGCR can operate with a 3.3V power supply, but it is recommended to use a 1.8V to 3.6V power supply for optimal performance.
