MS12ASG13 Information
MS12ASG13 by NKK Switches is a Slide Switch.
Slide Switches are under the broader part category of Switches.
Electrical switches are binary devices that control the flow of current in a circuit by either allowing or preventing the flow of electrons. Read more about Switches on our Switches part category page.
Price & Stock for MS12ASG13
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
11X3331
|
Newark | Switch, Slide, Spdt, 0.1A, 28V, Panel, Contact Configuration:Spdt, Switch Operation:On-None-On, Switch Mounting:Panel Mount, Product Range:-, Contact Current Max:100Ma, Contact Voltage Ac Max:28V, Contact Voltage Dc Max:28V Rohs Compliant: Yes |Nkk Switches MS12ASG13 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Bulk | 0 |
|
Buy Now | |
|
DISTI #
70366979
|
RS | MINIATURE SLIDE Min Qty: 1 Package Multiple: 1 Lead time: 11 Weeks, 0 Days Container: Bulk | 16 |
|
$5.1400 / $7.2400 | Buy Now |
|
DISTI #
MS12ASG13
|
TTI | Slide Switches SPDT ON-NONE-ON BRKT Min Qty: 1 Package Multiple: 1 Container: Bulk |
Americas - 36 In Stock |
|
$5.5800 | Buy Now |
|
DISTI #
MS12ASG13
|
TTI | Slide Switches SPDT ON-NONE-ON BRKT Min Qty: 1 Package Multiple: 1 Container: Bulk |
Americas - 36 In Stock |
|
$5.5800 | Buy Now |
|
|
Powell Electronics | MINIATURE SLIDE Min Qty: 1 | 160 |
|
$4.4000 / $6.4200 | Buy Now |
Part Details for MS12ASG13
MS12ASG13 CAD Models
MS12ASG13 Part Data Attributes
|
|
MS12ASG13
NKK Switches
Buy Now
Datasheet
|
Compare Parts:
MS12ASG13
NKK Switches
Miniature Slide; part status: Active; Poles: SPDT; contact timing: Non-Shorting (BBM); Circuits: On-On; Current Rating: 0.4VA (AC/DC); Rating (AC): 28V; Rating (DC): 28V; Actuator Type: Standard; actuator length: 5.10mm; contact material: Copper; contact finish: Gold; Mounting Type: Through Hole; Termination Style: PC Pin; Features: Epoxy Sealed Terminals; Rating: 0.4
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | NKK SWITCHES CO LTD | |
| Reach Compliance Code | not_compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8536.50.90.50 | |
| Samacsys Manufacturer | NKK Switches | |
| Actuator Angle | ||
| Actuator Length | 0.185 inch | |
| Actuator Type | SLIDE | |
| Body Breadth | 7.112 mm | |
| Body Height | 18.542 mm | |
| Body Length or Diameter | 12.7 mm | |
| Center Contact Material | COPPER ALLOY | |
| Center Contact Plating | GOLD OVER NICKEL | |
| Contact (DC) Max Power Rating R Load | 0.4VA@28VDC | |
| Contact Function | ON-ON | |
| Contact Resistance | 0.02 mΩ | |
| Contact Timing | BREAK-BEFORE-MAKE | |
| Dielectric Withstand Volts | 1500VAC V | |
| Electrical Life | 50000 Cycle(s) | |
| End Contact Material | COPPER ALLOY | |
| End Contact Plating | GOLD OVER NICKEL | |
| Housing Material | STAINLESS STEEL | |
| Insulation Resistance | 1000000000 Ω | |
| Insulator Material | GLASS FILLED DIALLYL PHTHALATE | |
| Mounting Feature | THROUGH HOLE-STRAIGHT | |
| Number of Positions | 2 | |
| Operating Temperature-Max | 70 °C | |
| Operating Temperature-Min | -10 °C | |
| PCB Hole Count | 7 | |
| Sealing | EPOXY | |
| Solderability | WAVE | |
| Surface Mount | NO | |
| Switch Action | HORIZONTAL | |
| Switch Function | SPDT | |
| Switch Type | SLIDE SWITCH | |
| Terminal Length | 0.264 inch | |
| Terminal Material | COPPER ALLOY | |
| Termination Type | SOLDER |
