MOCD207R2VM Information
MOCD207R2VM by onsemi is an Optocoupler.
Optocoupler are under the broader part category of Optoelectronics.
Optoelectronic components work to detect, generate, and control light. They can essentially produce and/or react to light. Read more about Optoelectronics on our Optoelectronics part category page.
Price & Stock for MOCD207R2VM
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
84H6391
|
Newark | Optocoupler, Transistor, 2.5Kv, Soic-8, No. Of Channels:2 Channel, Optocoupler Case Style:Soic, No. Of Pins:8Pins, Forward Current If Max:60Ma, Isolation Voltage:2.5Kv, Ctr Min:100%, Collector Emitter Voltage V(Br)Ceo:70V Rohs Compliant: Yes |Onsemi MOCD207R2VM RoHS: Compliant Min Qty: 2500 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.3040 / $0.4120 | Buy Now |
|
DISTI #
MOCD207R2VMCT-ND
|
DigiKey | OPTOISO 2.5KV 2CH TRANS 8-SOIC Min Qty: 1 Lead time: 8 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
4092 In Stock |
|
$0.4391 / $1.2600 | Buy Now |
|
DISTI #
MOCD207R2VM
|
Avnet Americas | Optocoupler DC-IN 2-CH Transistor DC-OUT 8-Pin SOIC N T/R - Tape and Reel (Alt: MOCD207R2VM) RoHS: Compliant Min Qty: 5000 Package Multiple: 2500 Lead time: 8 Weeks, 0 Days Container: Reel | 0 |
|
$0.2448 / $0.2543 | Buy Now |
|
DISTI #
512-MOCD207R2VM
|
Mouser Electronics | Transistor Output Optocouplers 8-Pin Optocoupler 2Ch Phototransistor RoHS: Compliant | 2401 |
|
$0.3520 / $1.0600 | Buy Now |
|
DISTI #
E02:0323_00840699
|
Arrow Electronics | Optocoupler DC-IN 2-CH Transistor DC-OUT 8-Pin SOIC T/R RoHS: Compliant Min Qty: 2500 Package Multiple: 2500 Lead time: 8 Weeks | Europe - 2500 |
|
$0.3788 | Buy Now |
|
|
Onlinecomponents.com | Optocoupler Dc-in 2-CH Transistor Dc-out 8-PIN SOIC N T/r RoHS: Compliant | 0 |
|
$0.2850 / $0.3106 | Buy Now |
|
DISTI #
87021103
|
Verical | Optocoupler DC-IN 2-CH Transistor DC-OUT 8-Pin SOIC T/R RoHS: Compliant Min Qty: 2500 Package Multiple: 2500 Date Code: 2341 | Americas - 2500 |
|
$0.3800 | Buy Now |
|
DISTI #
MOCD207R2VM
|
IBS Electronics | OPTOCOUPLER DC-IN 2-CH TRANSISTOR DC-OUT 8-PIN SOIC N T/R Min Qty: 2500 Package Multiple: 1 | 0 |
|
$0.3055 / $0.3185 | Buy Now |
|
DISTI #
MOCD207R2VM
|
Avnet Silica | Optocoupler DCIN 2CH Transistor DCOUT 8Pin SOIC N TR (Alt: MOCD207R2VM) RoHS: Compliant Min Qty: 2500 Package Multiple: 2500 Lead time: 9 Weeks, 0 Days | Silica - 0 |
|
Buy Now | |
|
|
Cytech Systems Limited | OPTOISO 2.5KV 2CH TRANS 8SOIC | 5000 |
|
RFQ |
Part Details for MOCD207R2VM
MOCD207R2VM CAD Models
MOCD207R2VM Part Data Attributes
|
|
MOCD207R2VM
onsemi
Buy Now
Datasheet
|
Compare Parts:
MOCD207R2VM
onsemi
8-pin SOIC Dual-Channel Phototransistor Output Optocoupler, SOIC-8, 2500-REEL
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ONSEMI | |
| Part Package Code | SOIC-8 | |
| Manufacturer Package Code | 751DZ | |
| Reach Compliance Code | compliant | |
| HTS Code | 8541.40.80.00 | |
| Factory Lead Time | 8 Weeks | |
| Samacsys Manufacturer | onsemi | |
| Additional Feature | UL APPROVED, VDE APPROVED | |
| Coll-Emtr Bkdn Voltage-Min | 70 V | |
| Configuration | SEPARATE, 2 CHANNELS | |
| Current Transfer Ratio-Min | 34% | |
| Current Transfer Ratio-Nom | 100% | |
| Dark Current-Max | 50 nA | |
| Forward Current-Max | 0.06 A | |
| Forward Voltage-Max | 1.55 V | |
| Isolation Voltage-Max | 2500 V | |
| JESD-609 Code | e3 | |
| Mounting Feature | SURFACE MOUNT | |
| Number of Elements | 2 | |
| On-State Current-Max | 0.15 A | |
| Operating Temperature-Max | 100 °C | |
| Operating Temperature-Min | -40 °C | |
| Optoelectronic Device Type | TRANSISTOR OUTPUT OPTOCOUPLER | |
| Power Dissipation-Max | 0.15 W | |
| Surface Mount | YES | |
| Terminal Finish | Matte Tin (Sn) - annealed |
