Part Details for MOCD207M by onsemi
Results Overview of MOCD207M by onsemi
- Distributor Offerings: (39 listings)
- Number of FFF Equivalents: (1 replacement)
- CAD Models: (Available)
- Number of Functional Equivalents: (10 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
MOCD207M Information
MOCD207M by onsemi is an Optocoupler.
Optocoupler are under the broader part category of Optoelectronics.
Optoelectronic components work to detect, generate, and control light. They can essentially produce and/or react to light. Read more about Optoelectronics on our Optoelectronics part category page.
Price & Stock for MOCD207M
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
67K0803
|
Newark | Optocoupler, Transistor, 2500Vrms, No. Of Channels:2 Channel, Optocoupler Case Style:Soic, No. Of Pins:8Pins, Forward Current If Max:60Ma, Isolation Voltage:2.5Kv, Ctr Min:100%, Collector Emitter Voltage V(Br)Ceo:70V, Product Range:-Rohs Compliant: Yes |Onsemi MOCD207M RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk | 3571 |
|
$0.3580 / $0.3880 | Buy Now |
|
DISTI #
26AC2378
|
Newark | 8So 2-Ch Tr Rohs Compliant: Yes |Onsemi MOCD207M RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Bulk | 0 |
|
$0.3860 / $0.5990 | Buy Now |
|
DISTI #
MOCD207M-ND
|
DigiKey | OPTOISO 2.5KV 2CH TRANS 8-SOIC Min Qty: 50 Lead time: 15 Weeks Container: Tube |
2740 In Stock |
|
$0.3987 / $0.6152 | Buy Now |
|
DISTI #
MOCD207M
|
Avnet Americas | Optocoupler Dual Open Collector-OUT 2.5kVrms 8-Pin SOIC Tube - Rail/Tube (Alt: MOCD207M) RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 15 Weeks, 0 Days Container: Tube | 35082 |
|
$0.2337 / $0.2516 | Buy Now |
|
DISTI #
67K0803
|
Avnet Americas | Optocoupler Dual Open Collector-OUT 2.5kVrms 8-Pin SOIC Tube - Bulk (Alt: 67K0803) RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 11 Weeks, 4 Days Container: Bulk | 3571 Partner Stock |
|
$0.5670 / $0.9120 | Buy Now |
|
DISTI #
MOCD207M
|
Avnet Americas | Optocoupler Dual Open Collector-OUT 2.5kVrms 8-Pin SOIC Tube - Rail/Tube (Alt: MOCD207M) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 15 Weeks, 0 Days Container: Tube | 0 |
|
RFQ | |
|
DISTI #
512-MOCD207M
|
Mouser Electronics | Transistor Output Optocouplers SO-8 DUAL CH PHOTO RoHS: Compliant | 16302 |
|
$0.3200 / $0.8900 | Buy Now |
|
DISTI #
V36:1790_06302958
|
Arrow Electronics | Optocoupler DC-IN 2-CH Transistor DC-OUT 8-Pin SOIC Tube RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 15 Weeks Date Code: 2249 | Americas - 110163 |
|
$0.2636 / $0.2928 | Buy Now |
|
DISTI #
E02:0323_00036788
|
Arrow Electronics | Optocoupler DC-IN 2-CH Transistor DC-OUT 8-Pin SOIC Tube RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 15 Weeks Date Code: 2441 | Europe - 28979 |
|
$0.2499 / $0.3403 | Buy Now |
|
DISTI #
V99:2348_06302958
|
Arrow Electronics | Optocoupler DC-IN 2-CH Transistor DC-OUT 8-Pin SOIC Tube RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 15 Weeks Date Code: 2345 | Americas - 219 |
|
$0.4002 / $0.7308 | Buy Now |
Part Details for MOCD207M
MOCD207M CAD Models
MOCD207M Part Data Attributes
|
|
MOCD207M
onsemi
Buy Now
Datasheet
|
Compare Parts:
MOCD207M
onsemi
8-pin SOIC Dual-Channel Phototransistor Output Optocoupler, SOIC-8, 3000-TUBE
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ONSEMI | |
| Part Package Code | SOIC-8 | |
| Manufacturer Package Code | 751DZ | |
| Reach Compliance Code | compliant | |
| HTS Code | 8541.40.80.00 | |
| Factory Lead Time | 11 Weeks, 4 Days | |
| Samacsys Manufacturer | onsemi | |
| Additional Feature | UL APPROVED | |
| Coll-Emtr Bkdn Voltage-Min | 70 V | |
| Configuration | SEPARATE, 2 CHANNELS | |
| Current Transfer Ratio-Min | 34% | |
| Current Transfer Ratio-Nom | 100% | |
| Dark Current-Max | 50 nA | |
| Forward Current-Max | 0.06 A | |
| Forward Voltage-Max | 1.55 V | |
| Isolation Voltage-Max | 2500 V | |
| JESD-609 Code | e3 | |
| Mounting Feature | SURFACE MOUNT | |
| Number of Elements | 2 | |
| On-State Current-Max | 0.15 A | |
| Operating Temperature-Max | 100 °C | |
| Operating Temperature-Min | -40 °C | |
| Optoelectronic Device Type | TRANSISTOR OUTPUT OPTOCOUPLER | |
| Packing Method | TUBE | |
| Power Dissipation-Max | 0.15 W | |
| Surface Mount | YES | |
| Terminal Finish | Matte Tin (Sn) - annealed |
Alternate Parts for MOCD207M
This table gives cross-reference parts and alternative options found for MOCD207M. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of MOCD207M, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| MOCD207MR1 | Fairchild Semiconductor Corporation | Check for Price | Transistor Output Optocoupler, 2-Element, 2500V Isolation, PLASTIC, SOIC-8 | MOCD207M vs MOCD207MR1 |
