MMSD3070 Information
MMSD3070 by onsemi is a Rectifier Diode.
Rectifier Diodes are under the broader part category of Diodes.
A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.
Price & Stock for MMSD3070
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
18C7478
|
Newark | Small Signal Diode 200V 200Ma Sod-123, Full Reel, Diode Configuration:Single, Repetitive Peak Reverse Voltage:200V, Average Forward Current:200Ma, Forward Voltage Max:1V, Reverse Recovery Time:50Ns, Forward Surge Current:2A Rohs Compliant: Yes |Onsemi MMSD3070 RoHS: Compliant Min Qty: 6000 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.0360 / $0.0500 | Buy Now |
|
DISTI #
MMSD3070CT-ND
|
DigiKey | DIODE STANDARD 200V 200MA SOD123 Min Qty: 1 Lead time: 14 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
119723 In Stock |
|
$0.0323 / $0.1900 | Buy Now |
|
DISTI #
MMSD3070
|
Avnet Americas | Diode Small Signal Switching 200V 0.2A 2-Pin SOD-123 T/R - Tape and Reel (Alt: MMSD3070) RoHS: Compliant Min Qty: 21000 Package Multiple: 3000 Lead time: 14 Weeks, 0 Days Container: Reel | 0 |
|
$0.0310 / $0.0339 | Buy Now |
|
DISTI #
512-MMSD3070
|
Mouser Electronics | Small Signal Switching Diodes Small Signal Diode RoHS: Compliant | 913710 |
|
$0.0320 / $0.1900 | Buy Now |
|
DISTI #
E02:0323_00849452
|
Arrow Electronics | Diode Small Signal Switching 200V 0.2A 2-Pin SOD-123 T/R RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 14 Weeks Date Code: 2349 | Europe - 9000 |
|
$0.0313 | Buy Now |
|
DISTI #
V72:2272_06302540
|
Arrow Electronics | Diode Small Signal Switching 200V 0.2A 2-Pin SOD-123 T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 14 Weeks Date Code: 2237 Container: Cut Strips | Americas - 1384 |
|
$0.0331 / $0.0816 | Buy Now |
|
|
Onlinecomponents.com | Diode Ultra Fast Recovery Rectifier 200V 0.2A 2-Pin SOD-123 T/R RoHS: Compliant | 0 |
|
$0.0309 / $0.0369 | Buy Now |
|
DISTI #
86011546
|
Verical | Diode Small Signal Switching 200V 0.2A 2-Pin SOD-123 T/R RoHS: Compliant Min Qty: 6865 Package Multiple: 1 Date Code: 2301 | Americas - 18000 |
|
$0.0546 | Buy Now |
|
DISTI #
76839122
|
Verical | Diode Small Signal Switching 200V 0.2A 2-Pin SOD-123 T/R RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Date Code: 2349 | Americas - 9000 |
|
$0.0314 | Buy Now |
|
DISTI #
87892770
|
Verical | Diode Small Signal Switching 200V 0.2A 2-Pin SOD-123 T/R RoHS: Compliant Min Qty: 933 Package Multiple: 1 Date Code: 2210 | Americas - 5800 |
|
$0.0256 / $0.0298 | Buy Now |
Part Details for MMSD3070
MMSD3070 CAD Models
MMSD3070 Part Data Attributes
|
|
MMSD3070
onsemi
Buy Now
Datasheet
|
Compare Parts:
MMSD3070
onsemi
Small Signal Diode, SOD-123, 3000-REEL
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ONSEMI | |
| Part Package Code | SOD-123 | |
| Package Description | SOD-123, 2 PIN | |
| Manufacturer Package Code | 425-04 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8541.10.00.70 | |
| Factory Lead Time | 14 Weeks | |
| Samacsys Manufacturer | onsemi | |
| Application | GENERAL PURPOSE | |
| Configuration | SINGLE | |
| Diode Element Material | SILICON | |
| Diode Type | RECTIFIER DIODE | |
| Forward Voltage-Max (VF) | 1 V | |
| JESD-30 Code | R-PDSO-G2 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Non-rep Pk Forward Current-Max | 2 A | |
| Number of Elements | 1 | |
| Number of Phases | 1 | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 150 °C | |
| Output Current-Max | 0.2 A | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Power Dissipation-Max | 0.4 W | |
| Qualification Status | Not Qualified | |
| Rep Pk Reverse Voltage-Max | 200 V | |
| Reverse Recovery Time-Max | 0.05 µs | |
| Surface Mount | YES | |
| Terminal Finish | Matte Tin (Sn) - annealed | |
| Terminal Form | GULL WING | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 |
