MMBT3904T-TP by: Micro Commercial Components

Small Signal Bipolar Transistor, 0.2A I(C), 40V V(BR)CEO, 1-Element, NPN, Silicon, ROHS COMPLIANT, PLASTIC, PACKAGE-3

Part Details for MMBT3904T-TP by Micro Commercial Components

Results Overview of MMBT3904T-TP by Micro Commercial Components

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Consumer Electronics Audio and Video Systems

MMBT3904T-TP Information

MMBT3904T-TP by Micro Commercial Components is a Small Signal Field-Effect Transistor.
Small Signal Field-Effect Transistors are under the broader part category of Transistors.

A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.

Price & Stock for MMBT3904T-TP

Part # Distributor Description Stock Price Buy
DISTI # MMBT3904T-TPCT-ND
DigiKey TRANS NPN 40V 0.2A SOT-523 Min Qty: 1 Lead time: 16 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) 2260
In Stock
  • 1 $0.1700
  • 10 $0.1020
  • 100 $0.0628
  • 500 $0.0456
  • 1,000 $0.0400
  • 3,000 $0.0329
  • 6,000 $0.0293
  • 9,000 $0.0274
  • 15,000 $0.0254
  • 21,000 $0.0241
  • 30,000 $0.0229
  • 75,000 $0.0203
  • 150,000 $0.0187
  • 300,000 $0.0173
$0.0173 / $0.1700 Buy Now
DISTI # 833-MMBT3904T-TP
Mouser Electronics Bipolar Transistors - BJT 600mA 40V RoHS: Compliant 4083
  • 1 $0.1700
  • 10 $0.1020
  • 100 $0.0630
  • 500 $0.0460
  • 1,000 $0.0400
  • 3,000 $0.0390
  • 6,000 $0.0290
  • 9,000 $0.0240
$0.0240 / $0.1700 Buy Now
Bristol Electronics   6223
RFQ
Vyrian Transistors 8063
RFQ

Part Details for MMBT3904T-TP

MMBT3904T-TP CAD Models

  • Part Symbol

    Part Symbol

  • Footprint

    footprint

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

MMBT3904T-TP Part Data Attributes

Parametric Data
MMBT3904T-TP Micro Commercial Components
Buy Now Datasheet
Compare Parts:
MMBT3904T-TP Micro Commercial Components Small Signal Bipolar Transistor, 0.2A I(C), 40V V(BR)CEO, 1-Element, NPN, Silicon, ROHS COMPLIANT, PLASTIC, PACKAGE-3
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer MICRO COMMERCIAL COMPONENTS CORP
Package Description ROHS COMPLIANT, PLASTIC, PACKAGE-3
Pin Count 3
Reach Compliance Code compliant
ECCN Code EAR99
Samacsys Manufacturer MCC
Collector Current-Max (IC) 0.2 A
Collector-Emitter Voltage-Max 40 V
Configuration SINGLE
DC Current Gain-Min (hFE) 100
JESD-30 Code R-PDSO-G3
JESD-609 Code e3
Moisture Sensitivity Level 1
Number of Elements 1
Number of Terminals 3
Operating Temperature-Max 150 °C
Package Body Material PLASTIC/EPOXY
Package Shape RECTANGULAR
Package Style SMALL OUTLINE
Peak Reflow Temperature (Cel) 260
Polarity/Channel Type NPN
Qualification Status Not Qualified
Surface Mount YES
Terminal Finish MATTE TIN
Terminal Form GULL WING
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) 10
Transistor Application AMPLIFIER
Transistor Element Material SILICON
Transition Frequency-Nom (fT) 300 MHz
Turn-off Time-Max (toff) 250 ns
Turn-on Time-Max (ton) 70 ns
