MMBT2222ATT3G by: onsemi

NPN Bipolar Junction Transistor, SC-75 (SOT-416) 3 LEAD, 10000-REEL

Part Details for MMBT2222ATT3G by onsemi

Results Overview of MMBT2222ATT3G by onsemi

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Consumer Electronics Audio and Video Systems

MMBT2222ATT3G Information

MMBT2222ATT3G by onsemi is a Small Signal Bipolar Transistor.
Small Signal Bipolar Transistors are under the broader part category of Transistors.

A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.

Price & Stock for MMBT2222ATT3G

Part # Distributor Description Stock Price Buy
DISTI # 16M4499
Newark Bipolar Transistor, Npn, 40V, Transistor Polarity:Npn, Collector Emitter Voltage Max:40V, Continuous Collector Current:600Ma, Power Dissipation:150Mw, Transistor Mounting:Surface Mount, No. Of Pins:3Pins, Transition Frequency:300Mhz Rohs Compliant: Yes |Onsemi MMBT2222ATT3G RoHS: Compliant Min Qty: 20000 Package Multiple: 1 Date Code: 0 Container: Reel 0
  • 18,000 $0.0210
  • 30,000 $0.0170
$0.0170 / $0.0210 Buy Now
DISTI # MMBT2222ATT3GOSCT-ND
DigiKey TRANS NPN 40V 0.6A SC75 SOT416 Min Qty: 1 Lead time: 8 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) 10008
In Stock
  • 1 $0.1500
  • 10 $0.0920
  • 100 $0.0568
  • 500 $0.0411
  • 1,000 $0.0360
  • 2,000 $0.0317
  • 5,000 $0.0271
  • 10,000 $0.0242
  • 20,000 $0.0217
  • 30,000 $0.0205
  • 50,000 $0.0191
  • 70,000 $0.0182
  • 100,000 $0.0174
  • 250,000 $0.0157
  • 500,000 $0.0146
$0.0146 / $0.1500 Buy Now
DISTI # MMBT2222ATT3G
Avnet Americas Transistor GP BJT NPN 40V 0.6A 3-Pin SOT-416 T/R - Tape and Reel (Alt: MMBT2222ATT3G) RoHS: Compliant Min Qty: 50000 Package Multiple: 10000 Lead time: 8 Weeks, 0 Days Container: Reel 0
  • 50,000 $0.0152
  • 70,000 $0.0151
  • 120,000 $0.0150
  • 250,000 $0.0150
  • 500,000 $0.0149
$0.0149 / $0.0152 Buy Now
DISTI # 863-MMBT2222ATT3G
Mouser Electronics Bipolar Transistors - BJT SS SC75 GP XSTR NPN 75V RoHS: Compliant 32239
  • 1 $0.1500
  • 10 $0.0920
  • 100 $0.0570
  • 500 $0.0410
  • 1,000 $0.0300
  • 2,500 $0.0290
  • 5,000 $0.0250
  • 10,000 $0.0210
  • 20,000 $0.0190
$0.0190 / $0.1500 Buy Now
Onlinecomponents.com NPN Bipolar Junction Transistor RoHS: Compliant 0
  • 10,000 $0.0155
  • 30,000 $0.0153
  • 50,000 $0.0149
  • 100,000 $0.0143
  • 150,000 $0.0141
  • 250,000 $0.0139
  • 500,000 $0.0137
$0.0137 / $0.0155 Buy Now
DISTI # 87651348
Verical Trans GP BJT NPN 40V 0.6A 150mW 3-Pin SOT-416 T/R RoHS: Compliant Min Qty: 10000 Package Multiple: 10000 Americas - 70000
  • 10,000 $0.0161
$0.0161 Buy Now
DISTI # 86009268
Verical Trans GP BJT NPN 40V 0.6A 150mW 3-Pin SOT-416 T/R RoHS: Compliant Min Qty: 9837 Package Multiple: 1 Date Code: 2201 Americas - 40000
  • 9,837 $0.0381
$0.0381 Buy Now
Rochester Electronics Small Signal Bipolar Transistor, 0.6A, 40V, NPN RoHS: Compliant Status: Active Min Qty: 1 49013
  • 100 $0.0305
  • 500 $0.0275
  • 1,000 $0.0253
  • 10,000 $0.0226
  • 100,000 $0.0189
$0.0189 / $0.0305 Buy Now
DISTI # MMBT2222ATT3G
Avnet Silica Transistor GP BJT NPN 40V 06A 3Pin SOT416 TR (Alt: MMBT2222ATT3G) RoHS: Compliant Min Qty: 10000 Package Multiple: 10000 Lead time: 9 Weeks, 0 Days Silica - 0
Buy Now
DISTI # MMBT2222ATT3G
EBV Elektronik Transistor GP BJT NPN 40V 06A 3Pin SOT416 TR (Alt: MMBT2222ATT3G) RoHS: Compliant Min Qty: 10000 Package Multiple: 10000 Lead time: 10 Weeks, 0 Days EBV - 0
Buy Now
Vyrian Transistors 32591
RFQ

Part Details for MMBT2222ATT3G

MMBT2222ATT3G CAD Models

  • Part Symbol

    Part Symbol

  • Footprint

    footprint

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

MMBT2222ATT3G Part Data Attributes

Parametric Data
MMBT2222ATT3G onsemi
Buy Now Datasheet
Compare Parts:
MMBT2222ATT3G onsemi NPN Bipolar Junction Transistor, SC-75 (SOT-416) 3 LEAD, 10000-REEL
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer ONSEMI
Part Package Code SC-75 (SOT-416) 3 LEAD
Package Description LEAD FREE, CASE 463-01, SC-75, 3 PIN
Pin Count 3
Manufacturer Package Code 463-01
Reach Compliance Code compliant
ECCN Code EAR99
Factory Lead Time 8 Weeks
Samacsys Manufacturer onsemi
Collector Current-Max (IC) 0.6 A
Collector-Emitter Voltage-Max 40 V
Configuration SINGLE
DC Current Gain-Min (hFE) 40
JESD-30 Code R-PDSO-G3
JESD-609 Code e3
Moisture Sensitivity Level 1
Number of Elements 1
Number of Terminals 3
Operating Temperature-Max 150 °C
Package Body Material PLASTIC/EPOXY
Package Shape RECTANGULAR
Package Style SMALL OUTLINE
Peak Reflow Temperature (Cel) 260
Polarity/Channel Type NPN
Qualification Status Not Qualified
Surface Mount YES
Terminal Finish Matte Tin (Sn) - annealed
Terminal Form GULL WING
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) 30
Transistor Application AMPLIFIER
Transistor Element Material SILICON
Transition Frequency-Nom (fT) 300 MHz
Turn-off Time-Max (toff) 285 ns
Turn-on Time-Max (ton) 35 ns
