Transistors / Small Signal Bipolar Transistors / MMBT2222AT-TP-HF
Datasheets
MMBT2222AT-TP-HF by: Micro Commercial Components

Small Signal Bipolar Transistor, 0.6A I(C), 40V V(BR)CEO, 1-Element, NPN, Silicon, HALOGEN FREE AND ROHS COMPLIANT, PLASTIC PACKAGE-3

Part Details for MMBT2222AT-TP-HF by Micro Commercial Components

Results Overview of MMBT2222AT-TP-HF by Micro Commercial Components

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Consumer Electronics Audio and Video Systems

MMBT2222AT-TP-HF Information

MMBT2222AT-TP-HF by Micro Commercial Components is a Small Signal Bipolar Transistor.
Small Signal Bipolar Transistors are under the broader part category of Transistors.

A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.

Price & Stock for MMBT2222AT-TP-HF

Part # Distributor Description Stock Price Buy
DISTI # 353-MMBT2222AT-TP-HF-ND
DigiKey TRANS NPN 40V 0.6A SOT-523 Lead time: 16 Weeks Container: Bulk Temporarily Out of Stock
Buy Now
DISTI # 833-MMBT2222AT-TP-HF
Mouser Electronics Bipolar Transistors - BJT NPN GENERAL PURPOSE AMPLIFIER RoHS: Compliant 0
  • 1 $0.3500
  • 10 $0.2370
  • 100 $0.1500
  • 1,000 $0.0670
  • 3,000 $0.0580
  • 9,000 $0.0440
  • 24,000 $0.0420
  • 45,000 $0.0390
  • 99,000 $0.0340
$0.0340 / $0.3500 Order Now

Part Details for MMBT2222AT-TP-HF

MMBT2222AT-TP-HF CAD Models

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

MMBT2222AT-TP-HF Part Data Attributes

Parametric Data
MMBT2222AT-TP-HF Micro Commercial Components
Buy Now Datasheet
Compare Parts:
MMBT2222AT-TP-HF Micro Commercial Components Small Signal Bipolar Transistor, 0.6A I(C), 40V V(BR)CEO, 1-Element, NPN, Silicon, HALOGEN FREE AND ROHS COMPLIANT, PLASTIC PACKAGE-3
Rohs Code Yes
Part Life Cycle Code Obsolete
Ihs Manufacturer MICRO COMMERCIAL COMPONENTS CORP
Package Description HALOGEN FREE AND ROHS COMPLIANT, PLASTIC PACKAGE-3
Reach Compliance Code compliant
ECCN Code EAR99
Samacsys Manufacturer MCC
Collector Current-Max (IC) 0.6 A
Collector-Emitter Voltage-Max 40 V
Configuration SINGLE
DC Current Gain-Min (hFE) 40
JESD-30 Code R-PDSO-G3
Number of Elements 1
Number of Terminals 3
Operating Temperature-Max 150 °C
Package Body Material PLASTIC/EPOXY
Package Shape RECTANGULAR
Package Style SMALL OUTLINE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Polarity/Channel Type NPN
Power Dissipation-Max (Abs) 0.35 W
Surface Mount YES
Terminal Form GULL WING
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Transistor Application AMPLIFIER
Transistor Element Material SILICON
Transition Frequency-Nom (fT) 300 MHz
Turn-off Time-Max (toff) 285 ns
Turn-on Time-Max (ton) 35 ns
