MMA02040C5900FB300 Information
MMA02040C5900FB300 by Vishay Intertechnologies is a Thin Film Resistor.
Thin Film Resistors are under the broader part category of Resistors.
Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.
Price & Stock for MMA02040C5900FB300
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
MMA02040C5900FB300
|
Avnet Americas | MMA 0204-50 1% BL 590R - Product that comes on tape, but is not reeled (Alt: MMA02040C5900FB300) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 9 Weeks, 0 Days Container: Ammo Pack | 0 |
|
$0.0249 / $0.0255 | Buy Now |
|
|
Quest Components | FIXED RESISTOR, THIN FILM, 0.4W, 590OHM, 200V, 1% +/-TOL, 50PPM/CEL, SURFACE MOUNT, 1406 | 31200 |
|
$0.0225 / $0.1500 | Buy Now |
|
DISTI #
MMA02040C5900FB300
|
TTI | MELF Resistors 1/4watt 590ohm 1% 50ppm RoHS: Compliant pbFree: Pb-Free Min Qty: 3000 Package Multiple: 3000 Container: Reel | Americas - 0 |
|
$0.0244 / $0.0269 | Buy Now |
|
DISTI #
MMA02040C5900FB300
|
Avnet Abacus | MMA 020450 1 BL 590R (Alt: MMA02040C5900FB300) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 12 Weeks, 0 Days | Abacus - 3000 |
|
Buy Now | |
|
|
New Advantage Corporation | MINI-MELF, 8MM BLISTER TAPE, 7"-REEL 0204 RoHS: Compliant Min Qty: 1 Package Multiple: 3000 | 18000 |
|
$0.0100 / $0.0200 | Buy Now |
Part Details for MMA02040C5900FB300
MMA02040C5900FB300 CAD Models
MMA02040C5900FB300 Part Data Attributes
|
|
MMA02040C5900FB300
Vishay Intertechnologies
Buy Now
Datasheet
|
Compare Parts:
MMA02040C5900FB300
Vishay Intertechnologies
Fixed Resistor, Thin Film, 0.4W, 590ohm, 200V, 1% +/-Tol, 50ppm/Cel, Surface Mount, 1406, MELF
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | VISHAY INTERTECHNOLOGY INC | |
| Package Description | MELF | |
| Reach Compliance Code | compliant | |
| Factory Lead Time | 9 Weeks | |
| Samacsys Manufacturer | Vishay | |
| Additional Feature | ANTI-SULFUR; LASER TRIMMABLE; RATED AC VOLTAGE (V): 200; STANDARD: CECC40401-803 | |
| Construction | Cylindrical | |
| JESD-609 Code | e3 | |
| Mounting Feature | SURFACE MOUNT | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 155 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Diameter | 1.4 mm | |
| Package Length | 3.6 mm | |
| Package Style | MELF | |
| Packing Method | TR, BLISTER, 7 INCH | |
| Rated Power Dissipation (P) | 0.4 W | |
| Rated Temperature | 70 °C | |
| Reference Standard | AEC-Q200 | |
| Resistance | 590 Ω | |
| Resistor Type | FIXED RESISTOR | |
| Size Code | 1406 | |
| Surface Mount | YES | |
| Technology | THIN FILM | |
| Temperature Coefficient | 50 ppm/°C | |
| Terminal Finish | Matte Tin (Sn) - with Nickel (Ni) barrier | |
| Terminal Shape | WRAPAROUND | |
| Tolerance | 1% | |
| Working Voltage | 200 V |
