Part Details for MLP2520H2R2MT0S1 by TDK Corporation
Results Overview of MLP2520H2R2MT0S1 by TDK Corporation
- Distributor Offerings: (8 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Environmental Monitoring
Industrial Automation
MLP2520H2R2MT0S1 Information
MLP2520H2R2MT0S1 by TDK Corporation is a Fixed Inductor.
Fixed Inductors are under the broader part category of Inductors.
Inductors are passive components that resist sudden changes in current by storing and releasing energy in an electromagnetic fiel. They are often used in power circuits and energy storage. Read more about Inductors on our Inductors part category page.
Price & Stock for MLP2520H2R2MT0S1
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
3386717RL
|
Farnell | INDUCTOR, 2.2UH, 1008, 1.3A, SHLD RoHS: Compliant Min Qty: 50 Lead time: 13 Weeks, 4 Days Container: Reel | 2350 |
|
$0.1437 / $0.1930 | Buy Now |
|
DISTI #
3386717
|
Farnell | INDUCTOR, 2.2UH, 1008, 1.3A, SHLD RoHS: Compliant Min Qty: 5 Lead time: 13 Weeks, 4 Days Container: Cut Tape | 2350 |
|
$0.1437 / $0.2608 | Buy Now |
|
DISTI #
445-MLP2520H2R2MT0S1CT-ND
|
DigiKey | FIXED IND 2.2UH 1.3A 117MOHM SMD Min Qty: 1 Lead time: 10 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
8814 In Stock |
|
$0.1050 / $0.2700 | Buy Now |
|
DISTI #
MLP2520H2R2MT0S1
|
Avnet Americas | MLP2520H2R2MT0S1 - Tape and Reel (Alt: MLP2520H2R2MT0S1) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 10 Weeks, 0 Days Container: Reel | 3000 |
|
$0.0901 / $0.0987 | Buy Now |
|
DISTI #
810-MLP2520H2R2MT0S1
|
Mouser Electronics | Power Inductors - SMD 2.5mm x 2mm x 0.85mm, -40 to +125 degC, 1300mA, 2.2?H, 117mohm RoHS: Compliant | 3402 |
|
$0.1090 / $0.2700 | Buy Now |
|
DISTI #
32325470
|
Verical | Inductor Power Shielded Multi-Layer 2.2uH 20% 2MHz Ferrite 1.3A 0.117Ohm DCR 1008 T/R RoHS: Compliant Min Qty: 453 Package Multiple: 1 | Americas - 11590 |
|
$0.1450 / $0.2370 | Buy Now |
|
DISTI #
MLP2520H2R2MT0S1
|
Avnet Abacus | MLP2520H2R2MT0S1 (Alt: MLP2520H2R2MT0S1) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 15 Weeks, 0 Days | Abacus - 0 |
|
Buy Now | |
|
DISTI #
MLP2520H2R2MT0S1
|
Chip One Stop | SMD Inductor RoHS: Compliant Min Qty: 5 Lead time: 0 Weeks, 1 Days Container: Cut Tape | 11590 |
|
$0.0971 / $0.2370 | Buy Now |
Part Details for MLP2520H2R2MT0S1
MLP2520H2R2MT0S1 CAD Models
MLP2520H2R2MT0S1 Part Data Attributes
|
|
MLP2520H2R2MT0S1
TDK Corporation
Buy Now
Datasheet
|
Compare Parts:
MLP2520H2R2MT0S1
TDK Corporation
General Purpose Inductor, 2.2uH, 20%, Ferrite-Core, 1008,
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TDK CORP | |
| Package Description | CHIP | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8504.50.80.00 | |
| Factory Lead Time | 10 Weeks | |
| Samacsys Manufacturer | TDK | |
| Case/Size Code | 1008 | |
| Construction | Rectangular | |
| Core Material | FERRITE | |
| DC Resistance | 0.09 Ω | |
| Inductance-Nom (L) | 2.2 µH | |
| Inductor Application | POWER INDUCTOR | |
| Inductor Type | GENERAL PURPOSE INDUCTOR | |
| Number of Functions | 1 | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Height | 1 mm | |
| Package Length | 2.5 mm | |
| Package Style | SMT | |
| Package Width | 2 mm | |
| Packing Method | TR, Embossed Plastic, 7 Inch | |
| Rated Current-Max | 1.3 A | |
| Shape/Size Description | RECTANGULAR PACKAGE | |
| Shielded | YES | |
| Special Feature | DC RESISTANCE IS MEASURED AT: 30% | |
| Surface Mount | YES | |
| Terminal Placement | DUAL ENDED | |
| Terminal Shape | WRAPAROUND | |
| Test Frequency | 2 MHz | |
| Tolerance | 20% |
