MIC47100-1.2YML-TR Information
MIC47100-1.2YML-TR by Microchip Technology Inc is a Linear Regulator IC.
Linear Regulator ICs are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for MIC47100-1.2YML-TR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
71Y1315
|
Newark | 1A High Speed, Low Vin Ldo 8 Vdfn 2X2X0.9Mm T/R Rohs Compliant: Yes |Microchip MIC47100-1.2YML-TR RoHS: Compliant Min Qty: 5000 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$2.1900 | Buy Now |
|
DISTI #
576-3115-1-ND
|
DigiKey | IC REG LINEAR 1.2V 1A 8-MLF Min Qty: 1 Lead time: 7 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
9437 In Stock |
|
$1.8100 / $2.3900 | Buy Now |
|
DISTI #
MIC47100-1.2YML-TR
|
Avnet Americas | LDO Regulator Pos 1.2V 1A 8-Pin VDFN T/R - Tape and Reel (Alt: MIC47100-1.2YML-TR) RoHS: Compliant Min Qty: 5000 Package Multiple: 5000 Lead time: 7 Weeks, 0 Days Container: Reel | 0 |
|
$1.8018 / $1.9250 | Buy Now |
|
DISTI #
998-MIC471001.2YMLTR
|
Mouser Electronics | LDO Voltage Regulators 1A High Speed, Low Vin LDO RoHS: Compliant | 2354 |
|
$1.8000 / $2.3900 | Buy Now |
|
DISTI #
V72:2272_07849153
|
Arrow Electronics | LDO Regulator Pos 1.2V 1A 8-Pin DFN EP T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 7 Weeks Date Code: 2320 Container: Cut Strips | Americas - 18195 |
|
$2.0670 / $2.3830 | Buy Now |
|
DISTI #
MIC47100-1.2YML-TR
|
Microchip Technology Inc | 1A High Speed, Low Vin LDO, VDFN, Projected EOL: 2034-05-09 COO: China, Malaysia ECCN: EAR99 RoHS: Compliant Lead time: 7 Weeks, 0 Days Container: Reel |
4970 Alternates Available |
|
$1.7200 / $2.3900 | Buy Now |
|
|
Onlinecomponents.com | LDO Regulator Pos 1.2V 1A 8-Pin DFN EP T/R RoHS: Compliant |
5000 In Stock |
|
$1.6500 / $4.8600 | Buy Now |
|
DISTI #
68402940
|
Verical | LDO Regulator Pos 1.2V 1A 8-Pin DFN EP T/R RoHS: Compliant Min Qty: 3 Package Multiple: 1 Date Code: 2320 | Americas - 18195 |
|
$2.0670 / $2.3830 | Buy Now |
|
DISTI #
66402243
|
Verical | LDO Regulator Pos 1.2V 1A 8-Pin DFN EP T/R RoHS: Compliant Min Qty: 20 Package Multiple: 10 Date Code: 2248 | Americas - 5000 |
|
$2.8722 / $6.3199 | Buy Now |
|
DISTI #
MIC47100-1.2YML-TR
|
IBS Electronics | LDO REGULATOR POS 1.2V 1A 8-PIN VDFN T/R Min Qty: 10 Package Multiple: 1 | 5000 |
|
$2.1450 / $6.3180 | Buy Now |
Part Details for MIC47100-1.2YML-TR
MIC47100-1.2YML-TR CAD Models
MIC47100-1.2YML-TR Part Data Attributes
|
|
MIC47100-1.2YML-TR
Microchip Technology Inc
Buy Now
Datasheet
|
Compare Parts:
MIC47100-1.2YML-TR
Microchip Technology Inc
1.2V FIXED POSITIVE LDO REGULATOR, 0.25V DROPOUT, PDSO8
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | MICROCHIP TECHNOLOGY INC | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Factory Lead Time | 7 Weeks | |
| Samacsys Manufacturer | Microchip | |
| Adjustability | FIXED | |
| Dropout Voltage1-Max | 0.25 V | |
| Dropout Voltage1-Nom | 0.08 V | |
| Input Voltage Absolute-Max | 4 V | |
| Input Voltage-Max | 3.6 V | |
| Input Voltage-Min | 1.7 V | |
| JESD-30 Code | S-XDSO-N8 | |
| JESD-609 Code | e4 | |
| Length | 2 mm | |
| Line Regulation-Max | 0.00114% | |
| Load Regulation-Max | 0.006% | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 1 | |
| Number of Outputs | 1 | |
| Number of Terminals | 8 | |
| Operating Temperature TJ-Max | 125 °C | |
| Operating Temperature TJ-Min | -40 °C | |
| Output Current1-Max | 1 A | |
| Output Voltage1-Max | 1.224 V | |
| Output Voltage1-Min | 1.176 V | |
| Output Voltage1-Nom | 1.2 V | |
| Package Body Material | UNSPECIFIED | |
| Package Code | HVSON | |
| Package Equivalence Code | SOLCC8,.08,20 | |
| Package Shape | SQUARE | |
| Package Style | SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE | |
| Packing Method | TR | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Regulator Type | FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR | |
| Seated Height-Max | 0.9 mm | |
| Surface Mount | YES | |
| Technology | NMOS | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | NO LEAD | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 40 | |
| Voltage Tolerance-Max | 2% | |
| Width | 2 mm |
