MIC37302WR-TR Information
MIC37302WR-TR by Microchip Technology Inc is a Linear Regulator IC.
Linear Regulator ICs are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for MIC37302WR-TR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
57AC2572
|
Newark | Ldo, Adj, 1.24-5.5V, 3A, S-Pak-5, Output Type:Adjustable, Input Voltage Min:2.25V, Input Voltage Max:6V, Fixed Output Voltage Nom.:-, Adjustable Output Voltage Min:1.24V, Adjustable Output Voltage Max:5.5V, Output Current:3A, Dropoutrohs Compliant: Yes |Microchip MIC37302WR-TR RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 1759 |
|
$4.0200 | Buy Now |
|
DISTI #
71Y0883
|
Newark | 3A Low Voltage Ldo Regulator 5 Spak - T/R Rohs Compliant: Yes |Microchip MIC37302WR-TR RoHS: Compliant Min Qty: 750 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$2.8700 | Buy Now |
|
DISTI #
576-1167-1-ND
|
DigiKey | IC REG LINEAR POS ADJ 3A 5-SPAK Min Qty: 1 Lead time: 4 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
994 In Stock |
|
$2.1800 / $2.8900 | Buy Now |
|
DISTI #
MIC37302WR-TR
|
Avnet Americas | LDO Regulator Pos 1.24V to 5.5V 3A 5-Pin SPAK T/R - Tape and Reel (Alt: MIC37302WR-TR) RoHS: Compliant Min Qty: 750 Package Multiple: 750 Lead time: 4 Weeks, 0 Days Container: Reel | 0 |
|
$2.1800 / $2.8900 | Buy Now |
|
DISTI #
998-MIC37302WRTR
|
Mouser Electronics | LDO Voltage Regulators 3A Low Voltage LDO Regulator RoHS: Compliant | 1032 |
|
$2.0300 / $2.2700 | Buy Now |
|
DISTI #
V72:2272_07449545
|
Arrow Electronics | LDO Regulator Pos 1.24V to 5.5V 3A 6-Pin(5+Tab) SPAK T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 4 Weeks Date Code: 2305 Container: Cut Strips | Americas - 1038 |
|
$2.3850 / $2.6280 | Buy Now |
|
DISTI #
MIC37302WR-TR
|
Microchip Technology Inc | 3A Low Voltage LDO Regulator, SPAK, Projected EOL: 2034-02-22 COO: China ECCN: EAR99 RoHS: Compliant Lead time: 8 Weeks, 0 Days Container: Reel |
12985 Alternates Available |
|
$2.1000 / $2.8900 | Buy Now |
|
|
Onlinecomponents.com | LDO Regulator Pos 1.24V to 5.5V 3A 6-Pin(5+Tab) SPAK T/R RoHS: Compliant |
750 In Stock 9000 Factory Stock |
|
$1.9500 / $4.2600 | Buy Now |
|
DISTI #
67002651
|
Verical | LDO Regulator Pos 1.24V to 5.5V 3A 6-Pin(5+Tab) SPAK T/R RoHS: Compliant Min Qty: 3 Package Multiple: 1 Date Code: 2305 | Americas - 1038 |
|
$2.3850 / $2.6280 | Buy Now |
|
DISTI #
66990829
|
Verical | LDO Regulator Pos 1.24V to 5.5V 3A 6-Pin(5+Tab) SPAK T/R RoHS: Compliant Min Qty: 20 Package Multiple: 10 Date Code: 2310 | Americas - 750 |
|
$3.0424 / $5.5397 | Buy Now |
Part Details for MIC37302WR-TR
MIC37302WR-TR CAD Models
MIC37302WR-TR Part Data Attributes
|
|
MIC37302WR-TR
Microchip Technology Inc
Buy Now
Datasheet
|
Compare Parts:
MIC37302WR-TR
Microchip Technology Inc
IC,VOLT REGULATOR,ADJUSTABLE,+1.24 TO +5.5,BIPOLAR,SIP,5PIN,PLASTIC
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | MICROCHIP TECHNOLOGY INC | |
| Package Description | SPAK-5 | |
| Reach Compliance Code | not_compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Factory Lead Time | 8 Weeks | |
| Samacsys Manufacturer | Microchip | |
| Adjustability | ADJUSTABLE | |
| JESD-30 Code | R-PSSO-G5 | |
| JESD-609 Code | e3 | |
| Length | 9.395 mm | |
| Line Regulation-Max (%/V) | 0.13 | |
| Load Regulation-Max(%) | 1% | |
| Number of Functions | 1 | |
| Number of Outputs | 1 | |
| Number of Terminals | 5 | |
| Operating Temperature TJ-Max | 125 °C | |
| Operating Temperature TJ-Min | -40 °C | |
| Output Current1-Max | 3 A | |
| Output Voltage1-Max | 5.5 V | |
| Output Voltage1-Min | 1.24 V | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | TO-263 | |
| Package Equivalence Code | SMSIP5H,.41,67TB | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Packing Method | TR | |
| Regulator Type | ADJUSTABLE POSITIVE SINGLE OUTPUT LDO REGULATOR | |
| Seated Height-Max | 2.16 mm | |
| Surface Mount | YES | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 1.7 mm | |
| Terminal Position | SINGLE | |
| Width | 8 mm |
