MF-NSMF150-2 Information
MF-NSMF150-2 by Bourns Inc is a Non-linear Resistor.
Non-linear Resistors are under the broader part category of Resistors.
Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.
Price & Stock for MF-NSMF150-2
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
79AH4213
|
Newark | Ptc Resettable 1.5A 6V Smd 1206 Rohs Compliant: Yes |Bourns MF-NSMF150-2 RoHS: Compliant Min Qty: 3000 Package Multiple: 1 Date Code: 0 Container: Reel | 24000 |
|
$0.1070 / $0.2780 | Buy Now |
|
DISTI #
97K4787
|
Newark | Multifuse, Smd, 1.5A, Thermistor Mounting:Smd, Product Range:Mf-Nsmf Series, Holding Current:1.5A, Tripping Current:3A, Voltage Rating:6V, Operating Temperature Min:-40°C, Operating Temperature Max:85°C, Automotive Qualification Rohs Compliant: Yes |Bourns MF-NSMF150-2 RoHS: Compliant Min Qty: 5 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 2639 |
|
$0.3790 / $0.5590 | Buy Now |
|
DISTI #
MF-NSMF150-2CT-ND
|
DigiKey | PTC RESET FUSE 6V 1.5A 1206 Min Qty: 1 Lead time: 14 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
3479 In Stock |
|
$0.1125 / $0.3100 | Buy Now |
|
DISTI #
MF-NSMF150-2
|
Avnet Americas | SMD Resettable Fuse, PPTC, 1206 (3216 Metric), MF-NSMF, 6 V, 1.5 A, 3 A, 300 ms - Tape and Reel (Alt: MF-NSMF150-2) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 14 Weeks, 0 Days Container: Reel | 24000 |
|
$0.1063 / $0.2775 | Buy Now |
|
DISTI #
652-MF-NSMF150-2
|
Mouser Electronics | Resettable Fuses - PPTC 6V 1.5A-HD 100A MAX RoHS: Compliant | 530 |
|
$0.1110 / $0.2600 | Buy Now |
|
DISTI #
V72:2272_06254240
|
Arrow Electronics | PTC Resettable Fuse 1.5A(hold) 3A(trip) 6V 100A 0.6W 0.3s 0.03Ohm SMD Solder Pad 1206 T/R Automotive AEC-Q200 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 14 Weeks Date Code: 1711 Container: Cut Strips | Americas - 3429 |
|
$0.0639 / $0.1159 | Buy Now |
|
DISTI #
70153461
|
RS | Fuse, Resettable, Fast Acting, 100A, Sz 1206, 0.134x0.071x0.028", SMT, 6VDC, PCB Min Qty: 3000 Package Multiple: 1 Lead time: 13 Weeks, 0 Days Container: Bulk | 0 |
|
$0.4160 | RFQ |
|
|
Onlinecomponents.com | PTC Resettable Fuse 1.5A(hold) 3A(trip) 6V 100A 0.6W 0.3s 0.03Ohm SMD Solder Pad 1206 T/R Automotive RoHS: Compliant | 0 |
|
$0.3588 / $0.3698 | Buy Now |
|
DISTI #
25740401
|
Verical | PTC Resettable Fuse 1.5A(hold) 3A(trip) 6V 100A 0.6W 0.3s 0.03Ohm SMD Solder Pad 1206 T/R Automotive AEC-Q200 RoHS: Compliant Min Qty: 51 Package Multiple: 1 Date Code: 1711 | Americas - 3429 |
|
$0.0639 / $0.0890 | Buy Now |
|
DISTI #
64958829
|
Verical | PTC Resettable Fuse 1.5A(hold) 3A(trip) 6V 100A 0.6W 0.3s 0.03Ohm SMD Solder Pad 1206 T/R Automotive AEC-Q200 RoHS: Compliant Min Qty: 101 Package Multiple: 1 | Americas - 2985 |
|
$0.2200 | Buy Now |
Part Details for MF-NSMF150-2
MF-NSMF150-2 CAD Models
MF-NSMF150-2 Part Data Attributes
|
|
MF-NSMF150-2
Bourns Inc
Buy Now
Datasheet
|
Compare Parts:
MF-NSMF150-2
Bourns Inc
PTC Resettable Fuse, Surface Mount, CHIP, 1206
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | BOURNS INC | |
| Package Description | CHIP | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8533.40.80.70 | |
| Factory Lead Time | 14 Weeks | |
| Samacsys Manufacturer | Bourns | |
| Additional Feature | RMIN AT 23 DEG CEL | |
| JESD-609 Code | e4 | |
| Mounting Feature | SURFACE MOUNT | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Height | 0.7 mm | |
| Package Length | 3.4 mm | |
| Package Shape | RECTANGULAR PACKAGE | |
| Package Style | SMT | |
| Package Width | 1.8 mm | |
| Packing Method | TR, 7 INCH | |
| Reference Standard | AEC-Q200; CUL; TUV; UL | |
| Resistance | 0.03 Ω | |
| Resistor Type | PTC RESETTABLE FUSE | |
| Surface Mount | YES | |
| Terminal Finish | GOLD OVER NICKEL | |
| Terminal Placement | DUAL ENDED | |
| Terminal Shape | WRAPAROUND | |
| Thermistor Application | OVERCURRENT PROTECTION | |
| Working Voltage | 6 V |
