MF-NSMF020-2 Information
MF-NSMF020-2 by Bourns Inc is a Non-linear Resistor.
Non-linear Resistors are under the broader part category of Resistors.
Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.
Price & Stock for MF-NSMF020-2
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
61J7365
|
Newark | Fuse, Ptc Reset, 24V, 200Ma, 1206, Pptc Case Style:1206 (3216 Metric), Product Range:Mf-Nsmf Series, Voltage Rating:24Vdc, Holding Current:200Ma, Trip Current:460Ma, Time To Trip:0.6S, Current Rating Max:10A, External Depth:0.67Mm Rohs Compliant: Yes |Bourns MF-NSMF020-2 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 3355 |
|
$0.1840 / $0.2430 | Buy Now |
|
DISTI #
84W7273
|
Newark | Fuse, Resettable Ptc, 24V, 200Ma, 1206, Full Reel, Pptc Case Style:1206 (3216 Metric), Product Range:Mf-Nsmf Series, Voltage Rating:24Vdc, Holding Current:200Ma, Trip Current:460Ma, Time To Trip:0.6S, Current Rating Max:10A Rohs Compliant: Yes |Bourns MF-NSMF020-2 RoHS: Compliant Min Qty: 24000 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.1410 | Buy Now |
|
DISTI #
79AH4212
|
Newark | Ptc Resettable 0.2A 24V Smd 1206 Rohs Compliant: Yes |Bourns MF-NSMF020-2 RoHS: Compliant Min Qty: 3000 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.3280 | Buy Now |
|
DISTI #
MF-NSMF020-2CT-ND
|
DigiKey | PTC RESET FUSE 24V 200MA 1206 Min Qty: 1 Lead time: 14 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
14096 In Stock |
|
$0.0495 / $0.1700 | Buy Now |
|
DISTI #
MF-NSMF020-2
|
Avnet Americas | PTC Resettable Fuse 10A 0.6s 24VDC 600m Ohm 2-Pin 1206 T/R - Tape and Reel (Alt: MF-NSMF020-2) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 14 Weeks, 0 Days Container: Reel | 0 |
|
$0.1125 / $0.2963 | Buy Now |
|
DISTI #
61J7365
|
Avnet Americas | PTC Resettable Fuse 10A 0.6s 24VDC 600m Ohm 2-Pin 1206 T/R - Product that comes on tape, but is not reeled (Alt: 61J7365) RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 13 Weeks, 3 Days Container: Ammo Pack | 0 |
|
$0.3900 / $0.4760 | Buy Now |
|
DISTI #
652-MF-NSMF020-2
|
Mouser Electronics | Resettable Fuses - PPTC 24V .2A-HD 10A MAX RoHS: Compliant | 27355 |
|
$0.1200 / $0.1800 | Buy Now |
|
DISTI #
E02:0323_00124041
|
Arrow Electronics | PTC Resettable Fuse 0.2A(hold) 0.46A(trip) 24V 10A 0.6W 0.6s 0.6Ohm SMD Solder Pad 1206 T/R Automotive AEC-Q200 RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 16 Weeks Date Code: 2443 | Europe - 726000 |
|
$0.3133 | Buy Now |
|
DISTI #
V36:1790_06254236
|
Arrow Electronics | PTC Resettable Fuse 0.2A(hold) 0.46A(trip) 24V 10A 0.6W 0.6s 0.6Ohm SMD Solder Pad 1206 T/R Automotive AEC-Q200 RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 14 Weeks Date Code: 2423 | Americas - 21000 |
|
$0.2686 | Buy Now |
|
DISTI #
V72:2272_06254236
|
Arrow Electronics | PTC Resettable Fuse 0.2A(hold) 0.46A(trip) 24V 10A 0.6W 0.6s 0.6Ohm SMD Solder Pad 1206 T/R Automotive AEC-Q200 RoHS: Compliant Min Qty: 346 Package Multiple: 1 Lead time: 14 Weeks Date Code: 2305 Container: Cut Strips | Americas - 14629 |
|
$0.2713 / $0.2889 | Buy Now |
Part Details for MF-NSMF020-2
MF-NSMF020-2 CAD Models
MF-NSMF020-2 Part Data Attributes
|
|
MF-NSMF020-2
Bourns Inc
Buy Now
Datasheet
|
Compare Parts:
MF-NSMF020-2
Bourns Inc
PTC Resettable Fuse, Surface Mount, CHIP, 1206
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | BOURNS INC | |
| Package Description | CHIP | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8533.40.80.70 | |
| Factory Lead Time | 14 Weeks | |
| Samacsys Manufacturer | Bourns | |
| Additional Feature | RMIN AT 23 DEG CEL | |
| JESD-609 Code | e4 | |
| Mounting Feature | SURFACE MOUNT | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Height | 0.85 mm | |
| Package Length | 3.4 mm | |
| Package Shape | RECTANGULAR PACKAGE | |
| Package Style | SMT | |
| Package Width | 1.8 mm | |
| Packing Method | TR, 7 INCH | |
| Reference Standard | AEC-Q200; CUL; TUV; UL | |
| Resistance | 0.6 Ω | |
| Resistor Type | PTC RESETTABLE FUSE | |
| Surface Mount | YES | |
| Terminal Finish | GOLD OVER NICKEL | |
| Terminal Placement | DUAL ENDED | |
| Terminal Shape | WRAPAROUND | |
| Thermistor Application | OVERCURRENT PROTECTION | |
| Working Voltage | 24 V |
