MCT6S Information
MCT6S by onsemi is an Optocoupler.
Optocoupler are under the broader part category of Optoelectronics.
Optoelectronic components work to detect, generate, and control light. They can essentially produce and/or react to light. Read more about Optoelectronics on our Optoelectronics part category page.
Price & Stock for MCT6S
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
MCT6S-ND
|
DigiKey | OPTOISOLATOR 5KV 2CH TRANS 8-SMD Min Qty: 1 Lead time: 15 Weeks Container: Tube |
1776 In Stock |
|
$0.3037 / $0.9300 | Buy Now |
|
DISTI #
MCT6S
|
Avnet Americas | Optocoupler DC-IN 2-CH Transistor DC-OUT 8-Pin PDIP SMD Black Bulk - Bulk (Alt: MCT6S) RoHS: Compliant Min Qty: 4000 Package Multiple: 1000 Lead time: 15 Weeks, 0 Days Container: Bulk | 0 |
|
$0.2112 / $0.2368 | Buy Now |
|
DISTI #
512-MCT6S
|
Mouser Electronics | Transistor Output Optocouplers SO-8 DUAL PH TRAN RoHS: Compliant | 3457 |
|
$0.2780 / $0.8400 | Buy Now |
|
DISTI #
V36:1790_06302231
|
Arrow Electronics | Optocoupler DC-IN 2-CH Transistor DC-OUT 8-Pin PDIP SMD Black Bag RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 15 Weeks Date Code: 2343 | Americas - 856 |
|
$0.2125 / $0.3738 | Buy Now |
|
|
Future Electronics | Dual Channel 30 V 5000 Vrms SMT Phototransistor Optocoupler - DIP-8 RoHS: Compliant pbFree: Yes Min Qty: 1 Package Multiple: 1 Lead time: 15 Weeks Container: Tube | 584Tube |
|
$0.2150 / $0.2400 | Buy Now |
|
|
Onlinecomponents.com | Optocoupler DC-IN 2-CH Transistor DC-OUT 8-Pin PDIP SMD Black Bulk RoHS: Compliant | 0 |
|
$0.2577 / $0.3179 | Buy Now |
|
DISTI #
79056847
|
Verical | Optocoupler DC-IN 2-CH Transistor DC-OUT 8-Pin PDIP SMD Black Bag RoHS: Compliant Min Qty: 31 Package Multiple: 1 Date Code: 2343 | Americas - 856 |
|
$0.2125 / $0.3134 | Buy Now |
|
|
Future Electronics | Dual Channel 30 V 5000 Vrms SMT Phototransistor Optocoupler - DIP-8 Min Qty: 1 Package Multiple: 1 |
584 null |
|
$0.2150 / $0.2400 | Buy Now |
|
DISTI #
MCT6S
|
TME | Optocoupler, SMD, Ch: 2, OUT: transistor, Uinsul: 5kV, Uce: 85V, DIP8 Min Qty: 1 | 0 |
|
$0.3160 / $0.8020 | RFQ |
|
DISTI #
MCT6S
|
IBS Electronics | OPTOCOUPLER DC-IN 2-CH TRANSISTOR DC-OUT 8-PIN PDIP SMD BLACK BULK Min Qty: 40 Package Multiple: 1 | 584 |
|
$0.2795 / $0.3120 | Buy Now |
Part Details for MCT6S
MCT6S CAD Models
MCT6S Part Data Attributes
|
|
MCT6S
onsemi
Buy Now
Datasheet
|
Compare Parts:
MCT6S
onsemi
8-Pin DIP Dual-Channel Phototransistor Output Optocoupler, PDIP-8 GW, 1000-BLKBG
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ONSEMI | |
| Part Package Code | PDIP-8 GW | |
| Manufacturer Package Code | 709AF | |
| Reach Compliance Code | compliant | |
| HTS Code | 8541.40.80.00 | |
| Factory Lead Time | 15 Weeks | |
| Samacsys Manufacturer | onsemi | |
| Additional Feature | UL RECOGNIZED | |
| Coll-Emtr Bkdn Voltage-Min | 30 V | |
| Configuration | SEPARATE, 2 CHANNELS | |
| Current Transfer Ratio-Min | 20% | |
| Current Transfer Ratio-Nom | 20% | |
| Dark Current-Max | 100 nA | |
| Forward Current-Max | 0.06 A | |
| Forward Voltage-Max | 1.5 V | |
| Isolation Voltage-Max | 5000 V | |
| JESD-609 Code | e3 | |
| Mounting Feature | SURFACE MOUNT | |
| Number of Elements | 2 | |
| On-State Current-Max | 0.03 A | |
| Operating Temperature-Max | 100 °C | |
| Operating Temperature-Min | -55 °C | |
| Optoelectronic Device Type | TRANSISTOR OUTPUT OPTOCOUPLER | |
| Power Dissipation-Max | 0.15 W | |
| Surface Mount | YES | |
| Terminal Finish | Matte Tin (Sn) - annealed |
MCT6S Frequently Asked Questions (FAQ)
-
The MCT6S can operate from -40°C to 150°C, but the recommended operating temperature range is -40°C to 125°C for optimal performance and reliability.
-
The MCT6S requires a bias voltage of 5V to 15V, and the recommended bias current is 10mA to 20mA. Ensure the bias voltage is stable and noise-free to achieve optimal performance.
-
Use a multi-layer PCB with a solid ground plane to minimize noise and EMI. Ensure good thermal conductivity by using thermal vias and a heat sink if necessary. Keep the component away from heat sources and ensure good airflow.
-
Use ESD protection devices such as TVS diodes or ESD arrays on the input and output pins of the MCT6S. Ensure the ESD protection devices are rated for the maximum voltage and current of the application.
-
Store the MCT6S in a dry, cool place away from direct sunlight and moisture. Handle the component by the body, not the leads, to prevent damage. Use anti-static packaging and handling procedures to prevent ESD damage.
