MCT61S Information
MCT61S by onsemi is an Optocoupler.
Optocoupler are under the broader part category of Optoelectronics.
Optoelectronic components work to detect, generate, and control light. They can essentially produce and/or react to light. Read more about Optoelectronics on our Optoelectronics part category page.
Price & Stock for MCT61S
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
34C1152
|
Newark | Optocoupler, No. Of Channels:2 Channel, Optocoupler Case Style:Dip, No. Of Pins:8Pins, Forward Current If Max:60Ma, Isolation Voltage:5Kv, Ctr Min:50%, Collector Emitter Voltage V(Br)Ceo:85V, Product Range:-, Input Current:20Ma Rohs Compliant: Yes |Onsemi MCT61S RoHS: Compliant Min Qty: 1000 Package Multiple: 1 Date Code: 0 Container: Bulk | 0 |
|
$0.2980 / $0.3800 | Buy Now |
|
DISTI #
MCT61S-ND
|
DigiKey | OPTOISOLATOR 5KV 2CH TRANS 8-SMD Min Qty: 1 Lead time: 15 Weeks Container: Tube |
1749 In Stock |
|
$0.3245 / $0.9900 | Buy Now |
|
DISTI #
MCT61S
|
Avnet Americas | Optocoupler DC-IN 2-CH Transistor DC-OUT 8-Pin PDIP SMD Black Bulk - Bulk (Alt: MCT61S) RoHS: Compliant Min Qty: 4000 Package Multiple: 1000 Lead time: 15 Weeks, 0 Days Container: Bulk | 0 |
|
$0.2301 / $0.2349 | Buy Now |
|
DISTI #
512-MCT61S
|
Mouser Electronics | Transistor Output Optocouplers SO-8 DUAL PH TRAN RoHS: Compliant | 955 |
|
$0.3050 / $0.9400 | Buy Now |
|
DISTI #
V99:2348_06302223
|
Arrow Electronics | Optocoupler DC-IN 2-CH Transistor DC-OUT 8-Pin PDIP SMD Black Bag RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 15 Weeks Date Code: 2233 | Americas - 79 |
|
$0.2772 / $0.5046 | Buy Now |
|
|
Onlinecomponents.com | Optocoupler DC-IN 2-CH Transistor DC-OUT 8-Pin PDIP SMD Black Bulk RoHS: Compliant | 0 |
|
$0.2765 / $0.3412 | Buy Now |
|
DISTI #
69833875
|
Verical | Optocoupler DC-IN 2-CH Transistor DC-OUT 8-Pin PDIP SMD Black Bag RoHS: Compliant Min Qty: 21 Package Multiple: 1 Date Code: 2233 | Americas - 79 |
|
$0.2772 / $0.2864 | Buy Now |
|
DISTI #
MCT61S
|
Avnet Silica | Optocoupler DCIN 2CH Transistor DCOUT 8Pin PDIP SMD Black Bulk (Alt: MCT61S) RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Lead time: 16 Weeks, 0 Days | Silica - 0 |
|
Buy Now | |
|
DISTI #
MCT61S
|
EBV Elektronik | Optocoupler DCIN 2CH Transistor DCOUT 8Pin PDIP SMD Black Bulk (Alt: MCT61S) RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Lead time: 17 Weeks, 0 Days | EBV - 3000 |
|
Buy Now | |
|
|
New Advantage Corporation | RoHS: Compliant Min Qty: 1 Package Multiple: 1000 | 2000 |
|
$0.8769 / $0.9500 | Buy Now |
Part Details for MCT61S
MCT61S CAD Models
MCT61S Part Data Attributes
|
|
MCT61S
onsemi
Buy Now
Datasheet
|
Compare Parts:
MCT61S
onsemi
8-Pin DIP Dual-Channel Phototransistor Output Optocoupler, PDIP-8 GW, 1000-BLKBG
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ONSEMI | |
| Part Package Code | PDIP-8 GW | |
| Manufacturer Package Code | 709AF | |
| Reach Compliance Code | compliant | |
| HTS Code | 8541.40.80.00 | |
| Factory Lead Time | 15 Weeks | |
| Samacsys Manufacturer | onsemi | |
| Additional Feature | UL APPROVED, VDE APPROVED | |
| Coll-Emtr Bkdn Voltage-Min | 30 V | |
| Configuration | SEPARATE, 2 CHANNELS | |
| Current Transfer Ratio-Min | 50% | |
| Current Transfer Ratio-Nom | 50% | |
| Dark Current-Max | 100 nA | |
| Forward Current-Max | 0.06 A | |
| Forward Voltage-Max | 1.5 V | |
| Isolation Voltage-Max | 5000 V | |
| JESD-609 Code | e3 | |
| Mounting Feature | SURFACE MOUNT | |
| Number of Elements | 2 | |
| On-State Current-Max | 0.03 A | |
| Operating Temperature-Max | 100 °C | |
| Operating Temperature-Min | -55 °C | |
| Optoelectronic Device Type | TRANSISTOR OUTPUT OPTOCOUPLER | |
| Power Dissipation-Max | 0.15 W | |
| Surface Mount | YES | |
| Terminal Finish | Matte Tin (Sn) - annealed |
MCT61S Frequently Asked Questions (FAQ)
-
The recommended operating voltage range for the MCT61S is 4.5V to 5.5V, with a typical operating voltage of 5V.
-
To ensure reliable operation in high-temperature environments, it is recommended to derate the device's power dissipation according to the thermal derating curve provided in the datasheet, and to ensure good thermal conduction between the device and the heat sink or PCB.
-
The maximum allowable current through the MCT61S's output pins is 20mA per pin, with a total device current limit of 100mA.
-
The MCT61S can be interfaced with a microcontroller or other digital logic using standard CMOS logic levels, with a pull-up resistor and/or a voltage translator if necessary to match the voltage levels.
-
The internal pull-up resistors on the MCT61S are used to pull the output pins high when the device is in a high-impedance state, helping to prevent unwanted output transitions and reduce power consumption.
