MCS04020D1001BE000 Information
MCS04020D1001BE000 by Vishay Intertechnologies is a Thin Film Resistor.
Thin Film Resistors are under the broader part category of Resistors.
Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.
Price & Stock for MCS04020D1001BE000
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
69AK8588
|
Newark | Res, 1K, 0.1%, 0.063W, Thin Film, 0402 Rohs Compliant: Yes |Vishay MCS04020D1001BE000 RoHS: Compliant Min Qty: 10000 Package Multiple: 1 Date Code: 1 Container: Reel | 10000 |
|
$0.0530 | Buy Now |
|
DISTI #
64AK9981
|
Newark | Res, 1K, 0.1%, 0.063W, Thin Film, 0402 Rohs Compliant: Yes |Vishay MCS04020D1001BE000 RoHS: Compliant Min Qty: 10 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 6720 |
|
$0.0690 / $0.0990 | Buy Now |
|
DISTI #
MCS04020D1001BE000
|
Avnet Americas | MCS 0402-25 0.1% E0 1K0 - Tape and Reel (Alt: MCS04020D1001BE000) RoHS: Compliant Min Qty: 10000 Package Multiple: 10000 Lead time: 9 Weeks, 0 Days Container: Reel | 0 |
|
$0.0416 / $0.0451 | Buy Now |
|
DISTI #
594-MCS04020D1001BE0
|
Mouser Electronics | Thin Film Resistors - SMD 1/16W 0.1% 1kOhms RoHS: Compliant | 25591 |
|
$0.0480 / $0.1100 | Buy Now |
|
DISTI #
E02:0323_04195290
|
Arrow Electronics | Res Thin Film 0402 1K Ohm 0.1% 0.063W(1/16W) ±25ppm/°C Sulfur Resistant Pad SMD T/R Medical Min Qty: 1 Package Multiple: 1 Lead time: 11 Weeks Date Code: 2435 | Europe - 9900 |
|
$0.0425 / $0.1047 | Buy Now |
|
DISTI #
MCS04020D1001BE000
|
TTI | Thin Film Resistors - SMD 1/16W 0.1% 1kOhms RoHS: Compliant pbFree: Pb-Free Min Qty: 10000 Package Multiple: 10000 Container: Reel |
Americas - 10000 In Stock |
|
$0.0620 | Buy Now |
|
DISTI #
MCS04020D1001BE000
|
Avnet Abacus | MCS 040225 01 E0 1K0 (Alt: MCS04020D1001BE000) RoHS: Compliant Min Qty: 20000 Package Multiple: 10000 Lead time: 12 Weeks, 0 Days | Abacus - 0 |
|
Buy Now | |
|
|
New Advantage Corporation | PROFESSIONAL FLAT CHIP RESISTOR, E0 RoHS: Compliant Min Qty: 1 Package Multiple: 10000 | 30000 |
|
$0.0300 | Buy Now |
Part Details for MCS04020D1001BE000
MCS04020D1001BE000 CAD Models
MCS04020D1001BE000 Part Data Attributes
|
|
MCS04020D1001BE000
Vishay Intertechnologies
Buy Now
Datasheet
|
Compare Parts:
MCS04020D1001BE000
Vishay Intertechnologies
Fixed Resistor, Thin Film, 0.063W, 1000ohm, 50V, 0.1% +/-Tol, 25ppm/Cel, Surface Mount, 0402, CHIP
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | VISHAY INTERTECHNOLOGY INC | |
| Package Description | CHIP | |
| Reach Compliance Code | compliant | |
| Factory Lead Time | 9 Weeks | |
| Samacsys Manufacturer | Vishay | |
| Additional Feature | ANTI-SULFUR, LASER TRIMMABLE, PRECISION, RATED AC VOLTAGE: 50V | |
| Construction | Rectangular | |
| JESD-609 Code | e3 | |
| Mounting Feature | SURFACE MOUNT | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Height | 0.32 mm | |
| Package Length | 1 mm | |
| Package Style | SMT | |
| Package Width | 0.5 mm | |
| Packing Method | TR, PAPER, 7 INCH | |
| Rated Power Dissipation (P) | 0.063 W | |
| Rated Temperature | 70 °C | |
| Reference Standard | CECC40401-801 | |
| Resistance | 1000 Ω | |
| Resistor Type | FIXED RESISTOR | |
| Size Code | 0402 | |
| Surface Mount | YES | |
| Technology | THIN FILM | |
| Temperature Coefficient | 25 ppm/°C | |
| Terminal Finish | MATTE TIN OVER NICKEL | |
| Terminal Shape | WRAPAROUND | |
| Tolerance | 0.1% | |
| Working Voltage | 50 V |
Alternate Parts for MCS04020D1001BE000
This table gives cross-reference parts and alternative options found for MCS04020D1001BE000. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of MCS04020D1001BE000, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| 239062741002L | YAGEO Corporation | Check for Price | Fixed Resistor, Thin Film, 0.0625W, 1000ohm, 50V, 0.1% +/-Tol, -25,25ppm/Cel, 0402, | MCS04020D1001BE000 vs 239062741002L |
| 239060731002 | YAGEO Corporation | Check for Price | Res,SMT,Thin Film,1K Ohms,50WV,.05% +/-Tol,25ppm TC,0402 Case | MCS04020D1001BE000 vs 239060731002 |
| 239060741002 | YAGEO Corporation | Check for Price | Fixed Resistor, Thin Film, 0.0625W, 1000ohm, 50V, 0.1% +/-Tol, 25ppm/Cel, Surface Mount, 0402, CHIP | MCS04020D1001BE000 vs 239060741002 |
| MCS0402-250.1%E01K00 | Vishay Intertechnologies | Check for Price | Fixed Resistor, Thin Film, 0.063W, 1000ohm, 50V, 0.1% +/-Tol, 25ppm/Cel, Surface Mount, 0402, CHIP | MCS04020D1001BE000 vs MCS0402-250.1%E01K00 |
| MCS04020D1001BE000 | Vishay Beyschlag | Check for Price | RESISTOR, THIN FILM, 0.063 W, 0.1 %, 25 ppm, 1000 ohm, SURFACE MOUNT, 0402, CHIP, ROHS COMPLIANT | MCS04020D1001BE000 vs MCS04020D1001BE000 |
| MCS04020D1001BE500 | Vishay Intertechnologies | Check for Price | Fixed Resistor, Thin Film, 0.063W, 1000ohm, 50V, 0.1% +/-Tol, 25ppm/Cel, Surface Mount, 0402, CHIP | MCS04020D1001BE000 vs MCS04020D1001BE500 |
| MCS0402-250.1%E11K00 | Vishay Intertechnologies | Check for Price | Fixed Resistor, Thin Film, 0.063W, 1000ohm, 50V, 0.1% +/-Tol, 25ppm/Cel, Surface Mount, 0402, CHIP | MCS04020D1001BE000 vs MCS0402-250.1%E11K00 |
| MCS04020D1001BE1 | Vishay Intertechnologies | Check for Price | Fixed Resistor, Thin Film, 0.063W, 1000ohm, 50V, 0.1% +/-Tol, 25ppm/Cel, Surface Mount, 0402, CHIP | MCS04020D1001BE000 vs MCS04020D1001BE1 |
