MCP47CVB01-E/MF by: Microchip Technology Inc

D/A Converter

Part Details for MCP47CVB01-E/MF by Microchip Technology Inc

Results Overview of MCP47CVB01-E/MF by Microchip Technology Inc

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Consumer Electronics Education and Research Industrial Automation Audio and Video Systems Electronic Manufacturing Entertainment and Gaming

MCP47CVB01-E/MF Information

MCP47CVB01-E/MF by Microchip Technology Inc is a Digital to Analog Converter.
Digital to Analog Converters are under the broader part category of Converters.

A converter is an electrical circuit that transforms electric energy into a different form that will support a elecrical load needed by a device. Read more about Converters on our Converters part category page.

Price & Stock for MCP47CVB01-E/MF

Part # Distributor Description Stock Price Buy
DISTI # 71AC1478
Newark I2C, Single Channel, 8-Bit, Volatile 10 Dfn 3X3X0.9Mm Tube Rohs Compliant: Yes |Microchip MCP47CVB01-E/MF RoHS: Compliant Min Qty: 480 Package Multiple: 1 Date Code: 0 Container: Bulk 0
  • 100 $0.7300
$0.7300 Buy Now
DISTI # MCP47CVB01-E/MF-ND
DigiKey IC DAC 8BIT V-OUT 10DFN Min Qty: 1 Lead time: 4 Weeks Container: Tube 1080
In Stock
  • 1 $0.9700
  • 25 $0.8100
  • 100 $0.7300
$0.7300 / $0.9700 Buy Now
DISTI # MCP47CVB01-E/MF
Avnet Americas DAC 1-Channel Resistor-Ladder 8-bit 10-Pin DFN Tube - Rail/Tube (Alt: MCP47CVB01-E/MF) RoHS: Compliant Min Qty: 480 Package Multiple: 120 Lead time: 4 Weeks, 0 Days Container: Tube 0
  • 480 $0.7625
  • 720 $0.7502
  • 1,200 $0.7380
  • 2,400 $0.7258
  • 4,800 $0.7137
$0.7137 / $0.7625 Buy Now
DISTI # 579-MCP47CVB01-E/MF
Mouser Electronics Digital to Analog Converters - DAC I2C, Single Channel, 8-Bit, Volatile RoHS: Compliant 368
  • 1 $0.9700
  • 25 $0.8100
  • 120 $0.7300
$0.7300 / $0.9700 Buy Now
DISTI # MCP47CVB01-E/MF
Microchip Technology Inc 8-bit, Single Channel Volatile DAC with I2C Interface, DFN, Projected EOL: 2044-08-27 COO: Thailand ECCN: EAR99 RoHS: Compliant Lead time: 7 Weeks, 0 Days Container: Tube 9920

Alternates Available
  • 1 $0.9700
  • 25 $0.8100
  • 100 $0.7300
  • 1,000 $0.7200
  • 5,000 $0.7000
$0.7000 / $0.9700 Buy Now
Onlinecomponents.com DAC - 1-Channel - 8-bit - 10-Pin DFN EP - Tube RoHS: Compliant 8840 Factory Stock
  • 120 $0.7710
  • 360 $0.7400
  • 600 $0.7290
  • 1,080 $0.7010
  • 2,520 $0.6670
  • 5,040 $0.6570
$0.6570 / $0.7710 Buy Now
DISTI # MCP47CVB01-E/MF
TME IC: D/A converter, 8bit, 3.4Msps, Ch: 1, 1.8÷5.5V, DFN10, -40÷125°C Min Qty: 1 0
  • 1 $1.0800
  • 5 $1.0000
  • 25 $0.9000
  • 100 $0.8100
$0.8100 / $1.0800 RFQ
NAC I2C, Single Channel, 8-Bit, Volatile - Package: 10 DFN 3x3x0.9mm TUBE RoHS: Compliant Min Qty: 480 Package Multiple: 120 Container: Tube 0
  • 1 $0.9400
  • 100 $0.8500
  • 500 $0.7800
  • 1,000 $0.7600
$0.7600 / $0.9400 Buy Now
DISTI # MCP47CVB01-E/MF
EBV Elektronik DAC 1Channel ResistorLadder 8bit 10Pin DFN Tube (Alt: MCP47CVB01-E/MF) RoHS: Compliant Min Qty: 120 Package Multiple: 120 Lead time: 5 Weeks, 0 Days EBV - 0
Buy Now
Master Electronics DAC - 1-Channel - 8-bit - 10-Pin DFN EP - Tube RoHS: Compliant 8840 Factory Stock
  • 120 $0.7710
  • 360 $0.7400
  • 600 $0.7290
  • 1,080 $0.7010
  • 2,520 $0.6670
  • 5,040 $0.6570
$0.6570 / $0.7710 Buy Now
Vyrian Converters 4484
RFQ

Part Details for MCP47CVB01-E/MF

MCP47CVB01-E/MF Part Data Attributes

Parametric Data
MCP47CVB01-E/MF Microchip Technology Inc
Buy Now Datasheet
Compare Parts:
MCP47CVB01-E/MF Microchip Technology Inc D/A Converter
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer MICROCHIP TECHNOLOGY INC
Package Description DFN-10
Reach Compliance Code unknown
ECCN Code EAR99
HTS Code 8542.39.00.01
Factory Lead Time 4 Weeks
Date Of Intro 2018-09-26
Samacsys Manufacturer Microchip
Converter Type D/A CONVERTER
Input Bit Code BINARY
Input Format SERIAL
JESD-30 Code S-PDSO-N10
JESD-609 Code e3
Length 3 mm
Linearity Error-Max (EL) 0.0391%
Number of Bits 8
Number of Functions 1
Number of Terminals 10
Operating Temperature-Max 125 °C
Operating Temperature-Min -40 °C
Package Body Material PLASTIC/EPOXY
Package Code HVSON
Package Equivalence Code SOLCC10,.12,20
Package Shape SQUARE
Package Style SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE
Screening Level TS 16949
Seated Height-Max 1 mm
Settling Time-Nom (tstl) 16 µs
Supply Current-Max 0.7 mA
Supply Voltage-Nom 5 V
Surface Mount YES
Temperature Grade AUTOMOTIVE
Terminal Finish Matte Tin (Sn)
Terminal Form NO LEAD
Terminal Pitch 0.5 mm
Terminal Position DUAL
Width 3 mm

Alternate Parts for MCP47CVB01-E/MF

This table gives cross-reference parts and alternative options found for MCP47CVB01-E/MF. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of MCP47CVB01-E/MF, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
MCP47CVB01-E/UN Microchip Technology Inc $0.7880 D/A Converter, 1 Func, Serial Input Loading, 16us Settling Time, PDSO8 MCP47CVB01-E/MF vs MCP47CVB01-E/UN
