MCP4725A0T-E/CHVAO Information
MCP4725A0T-E/CHVAO by Microchip Technology Inc is a Digital to Analog Converter.
Digital to Analog Converters are under the broader part category of Converters.
A converter is an electrical circuit that transforms electric energy into a different form that will support a elecrical load needed by a device. Read more about Converters on our Converters part category page.
Price & Stock for MCP4725A0T-E/CHVAO
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
150-MCP4725A0T-E/CHVAOCT-ND
|
DigiKey | IC DAC 12BIT V-OUT SOT23-6 Min Qty: 1 Lead time: 7 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) | Temporarily Out of Stock |
|
$2.4400 | Buy Now |
|
DISTI #
MCP4725A0T-E/CHVAO
|
Microchip Technology Inc | SINGLE, 12 BIT NV DAC WITH I2C INTERFACE, SOT-23, Projected EOL: 2039-06-27 COO: Thailand ECCN: EAR99 RoHS: Compliant Lead time: 7 Weeks, 0 Days Container: Reel |
645 Alternates Available |
|
$0.9300 / $1.6000 | Buy Now |
|
|
Chip 1 Exchange | INSTOCK | 2557 |
|
RFQ | |
|
|
Vyrian | Converters | 20829 |
|
RFQ |
Part Details for MCP4725A0T-E/CHVAO
MCP4725A0T-E/CHVAO CAD Models
MCP4725A0T-E/CHVAO Part Data Attributes
|
|
MCP4725A0T-E/CHVAO
Microchip Technology Inc
Buy Now
Datasheet
|
Compare Parts:
MCP4725A0T-E/CHVAO
Microchip Technology Inc
D/A Converter, 1 Func, Serial Input Loading, 6us Settling Time, PDSO6
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | MICROCHIP TECHNOLOGY INC | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Factory Lead Time | 7 Weeks | |
| Samacsys Manufacturer | Microchip | |
| Analog Output Voltage-Max | 5.5 V | |
| Analog Output Voltage-Min | ||
| Converter Type | D/A CONVERTER | |
| Input Bit Code | BINARY | |
| Input Format | SERIAL | |
| JESD-30 Code | R-PDSO-G6 | |
| JESD-609 Code | e3 | |
| Length | 2.9 mm | |
| Linearity Error-Max (EL) | 0.354% | |
| Number of Bits | 12 | |
| Number of Functions | 1 | |
| Number of Terminals | 6 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | LSSOP | |
| Package Equivalence Code | TSOP6,.11,37 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, LOW PROFILE, SHRINK PITCH | |
| Screening Level | AEC-Q100 | |
| Seated Height-Max | 1.45 mm | |
| Settling Time-Nom (tstl) | 6 µs | |
| Supply Current-Max | 0.4 mA | |
| Supply Voltage-Nom | 5 V | |
| Surface Mount | YES | |
| Temperature Grade | AUTOMOTIVE | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.95 mm | |
| Terminal Position | DUAL | |
| Width | 1.55 mm |
MCP4725A0T-E/CHVAO Frequently Asked Questions (FAQ)
-
The maximum output current of the MCP4725A0T-E/CHVAO is 25mA per channel.
-
To ensure accurate voltage output, make sure to use a high-quality external reference voltage, and follow proper PCB layout and grounding techniques to minimize noise and interference.
-
While the MCP4725A0T-E/CHVAO is primarily designed as a voltage source, it can be used as a current source with some limitations. However, it's essential to consider the output impedance and current capability of the device when designing a current source application.
-
To program the MCP4725A0T-E/CHVAO using SPI, follow the SPI protocol outlined in the datasheet, and ensure that the clock frequency is within the recommended range of 10 kHz to 3.4 MHz.
-
The MCP4725A0T-E/CHVAO has a power-on reset feature that initializes the device to a default state, including a zero-scale output voltage, after a power cycle or reset event.
