MCP111-270E/TO by: Microchip Technology Inc

1-CHANNEL POWER SUPPLY SUPPORT CKT, PBCY3, LEAD FREE, PLASTIC, TO-92, 3 PIN

Part Details for MCP111-270E/TO by Microchip Technology Inc

Results Overview of MCP111-270E/TO by Microchip Technology Inc

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Consumer Electronics Education and Research Environmental Monitoring Industrial Automation Audio and Video Systems Agriculture Technology Medical Imaging Entertainment and Gaming

MCP111-270E/TO Information

MCP111-270E/TO by Microchip Technology Inc is a Power Management Circuit.
Power Management Circuits are under the broader part category of Power Circuits.

A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.

Price & Stock for MCP111-270E/TO

Part # Distributor Description Stock Price Buy
DISTI # 56J7319
Newark Ic, volt Detector, fixed,+2.63V, sip,3Pin, plastic Rohs Compliant: Yes |Microchip MCP111-270E/TO RoHS: Compliant Min Qty: 3000 Package Multiple: 1 Date Code: 0 Container: Bulk 0
  • 100 $0.5200
$0.5200 Buy Now
DISTI # MCP111-270E/TO-ND
DigiKey IC SUPERVISOR 1 CHANNEL TO92-3 Min Qty: 2000 Lead time: 9 Weeks Container: Bag Temporarily Out of Stock
  • 3,000 $0.4900
$0.4900 Buy Now
DISTI # MCP111-270E/TO
Avnet Americas Volt Supervisor Detect 2.63V 3-Pin TO-92 - Bag (Alt: MCP111-270E/TO) RoHS: Compliant Min Qty: 3000 Package Multiple: 1000 Lead time: 9 Weeks, 0 Days Container: Bag 0
  • 2,000 $0.2932
  • 4,000 $0.2917
  • 6,000 $0.2902
  • 10,000 $0.2887
  • 20,000 $0.2872
$0.2872 / $0.2932 Buy Now
DISTI # 579-MCP111-270E/TO
Mouser Electronics Supervisory Circuits Open Drain RoHS: Compliant 1708
  • 1 $0.6400
  • 25 $0.5300
  • 100 $0.4900
$0.4900 / $0.6400 Buy Now
DISTI # MCP111-270E/TO
Microchip Technology Inc 1UA SUPERVISOR PUSH-PULL ACTIVE LOW, TO-92, Projected EOL: 2034-06-11 COO: Philippines, Taiwan ECCN: EAR99 RoHS: Compliant Lead time: 9 Weeks, 0 Days Container: Bag 0

Alternates Available
  • 1 $0.6400
  • 25 $0.5300
  • 100 $0.4900
  • 1,000 $0.4100
  • 5,000 $0.3700
$0.3700 / $0.6400 Buy Now
DISTI # 70388567
RS Voltage supervisor,2.70V, OD, Low, TO92 Min Qty: 2000 Package Multiple: 1 Lead time: 52 Weeks, 0 Days Container: Bulk 0
  • 2,000 $0.6100
  • 20,000 $0.5800
  • 100,000 $0.5500
  • 200,000 $0.5200
$0.5200 / $0.6100 RFQ
Onlinecomponents.com Processor Supervisor 2.63V 1 Active Low/Open Drain Automotive 3-Pin TO-92 Bag RoHS: Compliant 37000 Factory Stock
  • 750 $0.4800
  • 1,500 $0.3600
  • 2,250 $0.3360
  • 3,000 $0.3293
$0.3293 / $0.4800 Buy Now
DISTI # MCP111-270E/TO
TME IC: supervisor circuit, open drain, Active logical level: low Min Qty: 1 0
  • 1 $0.7110
  • 5 $0.5150
  • 25 $0.4630
  • 100 $0.4090
  • 250 $0.3680
  • 1,000 $0.3430
  • 2,000 $0.3190
$0.3190 / $0.7110 RFQ
NAC 1uA Supervisor Open-Drain Active Low - Package: 3 TO-92 BAG RoHS: Compliant Min Qty: 2000 Package Multiple: 1000 Container: Bag 0
  • 1 $0.3700
  • 100 $0.3300
  • 500 $0.3100
  • 1,000 $0.3000
$0.3000 / $0.3700 Buy Now
DISTI # MCP111-270E/TO
Avnet Silica Volt Supervisor Detect 263V 3Pin TO92 (Alt: MCP111-270E/TO) RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Lead time: 11 Weeks, 0 Days Silica - 0
Buy Now
DISTI # MCP111-270E/TO
EBV Elektronik Volt Supervisor Detect 263V 3Pin TO92 (Alt: MCP111-270E/TO) RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Lead time: 10 Weeks, 0 Days EBV - 0
Buy Now
Master Electronics Processor Supervisor 2.63V 1 Active Low/Open Drain Automotive 3-Pin TO-92 Bag RoHS: Compliant 37000 Factory Stock
  • 750 $0.4800
  • 1,500 $0.3600
  • 2,250 $0.3360
  • 3,000 $0.3293
$0.3293 / $0.4800 Buy Now

Part Details for MCP111-270E/TO

MCP111-270E/TO CAD Models

  • Part Symbol

    Part Symbol

  • Footprint

    footprint

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

MCP111-270E/TO Part Data Attributes

Parametric Data
MCP111-270E/TO Microchip Technology Inc
Buy Now Datasheet
Compare Parts:
MCP111-270E/TO Microchip Technology Inc 1-CHANNEL POWER SUPPLY SUPPORT CKT, PBCY3, LEAD FREE, PLASTIC, TO-92, 3 PIN
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer MICROCHIP TECHNOLOGY INC
Part Package Code TO-92
Pin Count 3
Reach Compliance Code compliant
ECCN Code EAR99
HTS Code 8542.39.00.01
Factory Lead Time 9 Weeks
Samacsys Manufacturer Microchip
Additional Feature MNL RST:N;PW FL IO:N;PRG RST DLY:N;WD:N;WDO:N;WWD:N
Adjustable Threshold NO
Analog IC - Other Type VOLTAGE DETECTOR
JESD-30 Code O-PBCY-W3
JESD-609 Code e3
Number of Channels 1
Number of Functions 1
Number of Terminals 3
Operating Temperature-Max 125 °C
Operating Temperature-Min -40 °C
Package Body Material PLASTIC/EPOXY
Package Code TO-92
Package Equivalence Code SIP3,.1,50
Package Shape ROUND
Package Style CYLINDRICAL
Qualification Status Not Qualified
Screening Level TS 16949
Supply Current-Max (Isup) 0.00175 mA
Supply Voltage-Max (Vsup) 5.5 V
Supply Voltage-Min (Vsup) 1 V
Supply Voltage-Nom (Vsup) 3 V
Surface Mount NO
Temperature Grade AUTOMOTIVE
Terminal Finish Matte Tin (Sn)
Terminal Form WIRE
Terminal Pitch 1.27 mm
Terminal Position BOTTOM
Threshold Voltage-Nom +2.63V
