Part Details for MCDHN-08F-T-V by SPC Multicomp
Results Overview of MCDHN-08F-T-V by SPC Multicomp
- Distributor Offerings: (1 listing)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Energy and Power Systems
Transportation and Logistics
Renewable Energy
Automotive
MCDHN-08F-T-V Information
MCDHN-08F-T-V by SPC Multicomp is a DIP Switch.
DIP Switches are under the broader part category of Switches.
Electrical switches are binary devices that control the flow of current in a circuit by either allowing or preventing the flow of electrons. Read more about Switches on our Switches part category page.
Price & Stock for MCDHN-08F-T-V
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
11N5429
|
Newark | Switch, Dip, 8 Position, Spst, Top Tape Sealed, No. Of Circuits:8Circuits, Switch Actuator Style:Slide, Switch Mounting:Surface Mount, Contact Configuration:Spst, Contact Voltage Dc Max:24Vdc, Contact Current Dc Max:25Ma Rohs Compliant: Yes |Multicomp Pro MCDHN-08F-T-V RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Cut Tape | 22015 |
|
$1.8800 / $2.6200 | Buy Now |
Part Details for MCDHN-08F-T-V
MCDHN-08F-T-V CAD Models
MCDHN-08F-T-V Part Data Attributes
|
|
MCDHN-08F-T-V
SPC Multicomp
Buy Now
Datasheet
|
Compare Parts:
MCDHN-08F-T-V
SPC Multicomp
Slide Dip Switch, 8 Switches, SPST, Latched, 0.025A, 24VDC, Solder Terminal, Surface Mount-straight, LEAD FREE
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | MULTICOMP PRO | |
| Reach Compliance Code | unknown | |
| ECCN Code | EAR99 | |
| HTS Code | 8536.50.90.65 | |
| Samacsys Manufacturer | Multicomp Pro | |
| Actuator Color | WHITE | |
| Actuator Type | SLIDE TYPE | |
| Body Breadth | 4.5 mm | |
| Body Color | BLACK | |
| Body Height | 1.5 mm | |
| Body Length or Diameter | 11.39 mm | |
| Center Contact Material | COPPER ALLOY | |
| Center Contact Plating | GOLD | |
| Contact Current(DC)-Max | 0.025 A | |
| Contact (DC) Max Rating R Load | .025A@24VDC | |
| Contact Resistance | 0.1 mΩ | |
| Contact Voltage(DC)-Max | 24 V | |
| Dielectric Withstand Volts | 300VAC V | |
| Electrical Life | 1000 Cycle(s) | |
| End Contact Material | COPPER ALLOY | |
| End Contact Plating | GOLD | |
| Insulation Resistance | 100000000 Ω | |
| JESD-609 Code | e4 | |
| Mounting Feature | SURFACE MOUNT-STRAIGHT | |
| Number of Positions | 8 | |
| Number of Switch Sections | 8 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Sealing | TOP TAPE SEALED | |
| Surface Mount | NO | |
| Switch Action | LATCHED | |
| Switch Function | SPST | |
| Switch Type | SLIDE DIP SWITCH | |
| Terminal Finish | Gold (Au) | |
| Terminal Material | BRASS | |
| Termination Type | SOLDER |
