MC74VHC139DR2G Information
MC74VHC139DR2G by onsemi is a Decoder/Driver.
Decoder/Drivers are under the broader part category of Logic Components.
Digital logic governs the behavior of signals in electronic circuits, enabling complex decisions based on simple binary inputs (yes/no). Logic components perform operations from these signals. Read more about Logic Components on our Logic part category page.
Price & Stock for MC74VHC139DR2G
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
45J1394
|
Newark | Ic, decoder/Demux,2-To-4-Line, ahc/Vhc-Cmos, sop,16Pin, plastic Rohs Compliant: Yes |Onsemi MC74VHC139DR2G RoHS: Compliant Min Qty: 2500 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.2240 / $0.2980 | Buy Now |
|
DISTI #
MC74VHC139DR2GOSCT-ND
|
DigiKey | IC DECODER/DEMUX 1 X 2:4 16-SOIC Min Qty: 1 Lead time: 9 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
1954 In Stock |
|
$0.2166 / $0.6600 | Buy Now |
|
DISTI #
MC74VHC139DR2G
|
Avnet Americas | 2-to-4 Line Decoder / Demultiplexer, 74VHC, 8 Outputs, 2 V to 5.5 V, 16 Pins, SOIC - Tape and Reel (Alt: MC74VHC139DR2G) RoHS: Compliant Min Qty: 3334 Package Multiple: 1 Lead time: 0 Weeks, 2 Days Container: Reel | 7500 Partner Stock |
|
$0.1737 / $0.1923 | Buy Now |
|
DISTI #
MC74VHC139DR2G
|
Avnet Americas | 2-to-4 Line Decoder / Demultiplexer, 74VHC, 8 Outputs, 2 V to 5.5 V, 16 Pins, SOIC - Tape and Reel (Alt: MC74VHC139DR2G) RoHS: Compliant Min Qty: 5000 Package Multiple: 2500 Lead time: 9 Weeks, 0 Days Container: Reel | 7500 Factory Stock |
|
$0.1737 / $0.1773 | Buy Now |
|
DISTI #
863-MC74VHC139DR2G
|
Mouser Electronics | Encoders, Decoders, Multiplexers & Demultiplexers 2-5.5V Dual 2-to-4 Decoder RoHS: Compliant | 2551 |
|
$0.2160 / $1.2100 | Buy Now |
|
DISTI #
V72:2272_07296407
|
Arrow Electronics | Decoder/Demultiplexer Dual 2-to-4 16-Pin SOIC T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 9 Weeks Date Code: 2343 Container: Cut Strips | Americas - 4990 |
|
$0.2693 / $0.2967 | Buy Now |
|
|
Onlinecomponents.com | Dual 2-to-4 Decoder/Demultiplexer RoHS: Compliant | 0 |
|
$0.2091 / $0.2342 | Buy Now |
|
DISTI #
86002094
|
Verical | Decoder/Demultiplexer Dual 2-to-4 16-Pin SOIC T/R RoHS: Compliant Min Qty: 1023 Package Multiple: 1 Date Code: 1001 | Americas - 67285 |
|
$0.3669 | Buy Now |
|
DISTI #
86005182
|
Verical | Decoder/Demultiplexer Dual 2-to-4 16-Pin SOIC T/R RoHS: Compliant Min Qty: 1023 Package Multiple: 1 Date Code: 0501 | Americas - 5000 |
|
$0.3669 | Buy Now |
|
DISTI #
73505096
|
Verical | Decoder/Demultiplexer Dual 2-to-4 16-Pin SOIC T/R RoHS: Compliant Min Qty: 22 Package Multiple: 1 Date Code: 2343 | Americas - 4990 |
|
$0.2693 / $0.2784 | Buy Now |
Part Details for MC74VHC139DR2G
MC74VHC139DR2G CAD Models
MC74VHC139DR2G Part Data Attributes
|
|
MC74VHC139DR2G
onsemi
Buy Now
Datasheet
|
Compare Parts:
MC74VHC139DR2G
onsemi
Dual 2-to-4 Decoder/Demultiplexer, SOIC 16 LEAD, 2500-REEL
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ONSEMI | |
| Part Package Code | SOIC 16 LEAD | |
| Pin Count | 16 | |
| Manufacturer Package Code | 751B-05 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Factory Lead Time | 2 Days | |
| Samacsys Manufacturer | onsemi | |
| Family | AHC/VHC | |
| Input Conditioning | STANDARD | |
| JESD-30 Code | R-PDSO-G16 | |
| JESD-609 Code | e3 | |
| Length | 9.9 mm | |
| Load Capacitance (CL) | 50 pF | |
| Logic IC Type | 2-LINE TO 4-LINE DECODER | |
| Max I(ol) | 0.008 A | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 2 | |
| Number of Terminals | 16 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -55 °C | |
| Output Polarity | INVERTED | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | SOP | |
| Package Equivalence Code | SOP16,.25 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Packing Method | TR | |
| Peak Reflow Temperature (Cel) | 260 | |
| Prop. Delay@Nom-Sup | 10.5 ns | |
| Propagation Delay (tpd) | 16.5 ns | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.75 mm | |
| Supply Voltage-Max (Vsup) | 5.5 V | |
| Supply Voltage-Min (Vsup) | 2 V | |
| Supply Voltage-Nom (Vsup) | 3.3 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Temperature Grade | MILITARY | |
| Terminal Finish | Matte Tin (Sn) - annealed | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 1.27 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 3.9 mm |
