MC15XS3400DHFK Information
MC15XS3400DHFK by NXP Semiconductors is a Peripheral Driver.
Peripheral Drivers are under the broader part category of Drivers And Interfaces.
A driver controls the current or voltage delivered to components like LCDs or motors, while an interface component connects systems for data transfer and control. Read more about Drivers And Interfaces on our Drivers And Interfaces part category page.
Price & Stock for MC15XS3400DHFK
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
89T6110
|
Newark | High-Side Switch, 12V, Quad 15Mohms, Pqfn 24/ Tray Rohs Compliant: Yes |Nxp MC15XS3400DHFK RoHS: Compliant Min Qty: 840 Package Multiple: 1 Date Code: 0 Container: Bulk | 0 |
|
$4.9400 | Buy Now |
|
|
Rochester Electronics | High-Side Switch, 12V, Quad 15mOhms, PQFN 24 RoHS: Compliant Status: Obsolete Min Qty: 1 | 8 |
|
$3.8200 / $4.7700 | Buy Now |
Part Details for MC15XS3400DHFK
MC15XS3400DHFK CAD Models
MC15XS3400DHFK Part Data Attributes
|
|
MC15XS3400DHFK
NXP Semiconductors
Buy Now
Datasheet
|
Compare Parts:
MC15XS3400DHFK
NXP Semiconductors
4 CHANNEL, BUF OR INV BASED PRPHL DRVR, BCC24
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | NXP SEMICONDUCTORS | |
| Package Description | 12 X 12 MM, 2.10 HEIGHT, 0.90 PITCH, ROHS COMPLIANT, PQFN-24 | |
| Reach Compliance Code | not_compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Factory Lead Time | 4 Weeks | |
| Samacsys Manufacturer | NXP | |
| Additional Feature | ALSO OPERATES WITH 4 TO 28 VOLTS | |
| Built-in Protections | TRANSIENT; OVER CURRENT; OVER VOLTAGE; THERMAL; UNDER VOLTAGE | |
| Driver Number of Bits | 4 | |
| Interface IC Type | BUFFER OR INVERTER BASED PERIPHERAL DRIVER | |
| JESD-30 Code | S-XBCC-B24 | |
| Length | 12 mm | |
| Moisture Sensitivity Level | 3 | |
| Number of Functions | 4 | |
| Number of Terminals | 24 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Current Flow Direction | SINK | |
| Package Body Material | UNSPECIFIED | |
| Package Code | HBCC | |
| Package Equivalence Code | LCC24(UNSPEC) | |
| Package Shape | SQUARE | |
| Package Style | CHIP CARRIER, HEAT SINK/SLUG | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 2.2 mm | |
| Supply Voltage-Max | 20 V | |
| Supply Voltage-Min | 6 V | |
| Supply Voltage-Nom | 12 V | |
| Surface Mount | YES | |
| Temperature Grade | AUTOMOTIVE | |
| Terminal Form | BUTT | |
| Terminal Position | BOTTOM | |
| Time@Peak Reflow Temperature-Max (s) | 40 | |
| Turn-off Time | 90 µs | |
| Turn-on Time | 90 µs | |
| Width | 12 mm |
