MAX5702BAUB+T Information
MAX5702BAUB+T by Analog Devices Inc is a Digital to Analog Converter.
Digital to Analog Converters are under the broader part category of Converters.
A converter is an electrical circuit that transforms electric energy into a different form that will support a elecrical load needed by a device. Read more about Converters on our Converters part category page.
Price & Stock for MAX5702BAUB+T
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
700-MAX5702BAUB+T
|
Mouser Electronics | Digital to Analog Converters - DAC Ultra-Small, Dual-Channel, 8-/10-/12-Bit RoHS: Compliant | 0 |
|
$3.3200 | Order Now |
|
|
Analog Devices Inc | Ultra-Small, Dual-Channel, 8-/ Min Qty: 2500 Package Multiple: 1 | 10000 |
|
$2.6600 / $3.5877 | Buy Now |
Part Details for MAX5702BAUB+T
MAX5702BAUB+T CAD Models
MAX5702BAUB+T Part Data Attributes
|
|
MAX5702BAUB+T
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
MAX5702BAUB+T
Analog Devices Inc
Ultra-Small, Dual-Channel, 8-/10-/12-Bit Buffered Output DACs with Internal Reference and SPI Interface, 10-MINI_SO-N/A, 10 Pins, -40 to 125C
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Part Package Code | 10-MINI_SO-N/A | |
| Pin Count | 10 | |
| Manufacturer Package Code | 10-MINI_SO-N/A | |
| Reach Compliance Code | compliant | |
| Date Of Intro | 2012-10-05 | |
| Samacsys Manufacturer | Analog Devices | |
| Converter Type | D/A CONVERTER | |
| Input Bit Code | OFFSET BINARY | |
| JESD-30 Code | R-PDSO-G10 | |
| JESD-609 Code | e3 | |
| Linearity Error-Max (EL) | 0.024% | |
| Moisture Sensitivity Level | 1 | |
| Number of Bits | 12 | |
| Number of Functions | 2 | |
| Number of Terminals | 10 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | TSSOP | |
| Package Equivalence Code | TSSOP10,.19,20 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, THIN PROFILE, SHRINK PITCH | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Supply Current-Max | 0.9 mA | |
| Surface Mount | YES | |
| Technology | BICMOS | |
| Temperature Grade | AUTOMOTIVE | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 |
