Part Details for MAX3318CDBR by Texas Instruments
Results Overview of MAX3318CDBR by Texas Instruments
- Distributor Offerings: (10 listings)
- Number of FFF Equivalents: (9 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (10 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
MAX3318CDBR Information
MAX3318CDBR by Texas Instruments is a Line Driver or Receiver.
Line Driver or Receivers are under the broader part category of Drivers And Interfaces.
A driver controls the current or voltage delivered to components like LCDs or motors, while an interface component connects systems for data transfer and control. Read more about Drivers And Interfaces on our Drivers And Interfaces part category page.
Available Datasheets
| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| MAX3318CDBR | Texas Instruments | 2.5-V 460-Kbps RS-232 Transceiver With +/-15 KV ESD Protection 20-SSOP 0 to 70 |
Price & Stock for MAX3318CDBR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
2156-MAX3318CDBR-ND
|
DigiKey | IC TRANSCEIVER FULL 2/2 20SSOP Min Qty: 1 Lead time: 6 Weeks Container: Bulk MARKETPLACE PRODUCT |
9950 In Stock |
|
$1.7600 | Buy Now |
|
DISTI #
296-20935-1-ND
|
DigiKey | IC TRANSCEIVER FULL 2/2 20SSOP Min Qty: 1 Lead time: 6 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) | Temporarily Out of Stock |
|
$1.7369 / $3.2900 | Buy Now |
|
DISTI #
595-MAX3318CDBR
|
Mouser Electronics | RS-232 Interface IC 2.5V 460-Kbps Transc eiver A 595-MAX3318CDB RoHS: Compliant | 0 |
|
$1.6900 / $1.7400 | Order Now |
|
DISTI #
85993252
|
Verical | Dual Transmitter/Receiver RS-232 20-Pin SSOP T/R RoHS: Compliant Min Qty: 187 Package Multiple: 1 Date Code: 0701 | Americas - 4000 |
|
$1.8000 / $2.0125 | Buy Now |
|
DISTI #
85993885
|
Verical | Dual Transmitter/Receiver RS-232 20-Pin SSOP T/R RoHS: Compliant Min Qty: 187 Package Multiple: 1 Date Code: 1301 | Americas - 3950 |
|
$1.8000 / $2.0125 | Buy Now |
|
DISTI #
86000860
|
Verical | Dual Transmitter/Receiver RS-232 20-Pin SSOP T/R RoHS: Compliant Min Qty: 187 Package Multiple: 1 Date Code: 0501 | Americas - 2000 |
|
$1.8000 / $2.0125 | Buy Now |
|
|
Bristol Electronics | 3012 |
|
RFQ | ||
|
|
Quest Components | 2409 |
|
$2.9025 / $5.8050 | Buy Now | |
|
|
Quest Components | 20 |
|
$2.1000 / $3.3600 | Buy Now | |
|
|
Rochester Electronics | MAX3318 2.5-V 460-Kbps RS-232 Transceiver With +/-15 KV ESD Protection RoHS: Compliant Status: Active Min Qty: 1 | 9950 |
|
$1.3500 / $1.6900 | Buy Now |
Part Details for MAX3318CDBR
MAX3318CDBR CAD Models
MAX3318CDBR Part Data Attributes
|
|
MAX3318CDBR
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
MAX3318CDBR
Texas Instruments
2.5-V dual channel 460kbps RS-232 line driver/receiver with +/-15-kV ESD protection 20-SSOP 0 to 70
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Part Package Code | SSOP | |
| Package Description | GREEN, SSOP-20 | |
| Pin Count | 20 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Texas Instruments | |
| Differential Output | NO | |
| Driver Number of Bits | 2 | |
| Input Characteristics | SCHMITT TRIGGER | |
| Interface IC Type | LINE TRANSCEIVER | |
| Interface Standard | EIA-232 | |
| JESD-30 Code | R-PDSO-G20 | |
| JESD-609 Code | e4 | |
| Length | 7.2 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 2 | |
| Number of Terminals | 20 | |
| Operating Temperature-Max | 70 °C | |
| Operating Temperature-Min | ||
| Out Swing-Min | 7.4 V | |
| Output Polarity | TRUE | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | SSOP | |
| Package Equivalence Code | SSOP20,.3 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, SHRINK PITCH | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Receiver Number of Bits | 2 | |
| Seated Height-Max | 2 mm | |
| Supply Current-Max | 2 mA | |
| Supply Voltage-Max | 3 V | |
| Supply Voltage-Min | 2.25 V | |
| Supply Voltage-Nom | 2.5 V | |
| Supply Voltage1-Max | 3 V | |
| Supply Voltage1-Min | 2.25 V | |
| Supply Voltage1-Nom | 2.5 V | |
| Surface Mount | YES | |
| Temperature Grade | COMMERCIAL | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 5.3 mm |
