M93C86-RDW3TP/K Information
M93C86-RDW3TP/K by STMicroelectronics is an EEPROM.
EEPROMs are under the broader part category of Memory Components.
Memory components are essential in electronics for computer processing. They can be volatile or non-volatile, depending on the desired function. Read more about Memory Components on our Memory part category page.
Price & Stock for M93C86-RDW3TP/K
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
497-14438-1-ND
|
DigiKey | IC EEPROM 16KBIT MIC WIRE 8TSSOP Min Qty: 1 Lead time: 14 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) | Temporarily Out of Stock |
|
$0.4638 / $0.6900 | Buy Now |
|
DISTI #
M93C86-RDW3TP/K
|
Avnet Americas | EEPROM Serial-Microwire 16K-bit 2K x 8/1K x 16 2.5V/3.3V/5V 8-Pin TSSOP T/R - Tape and Reel (Alt: M93C86-RDW3TP/K) RoHS: Compliant Min Qty: 4000 Package Multiple: 4000 Lead time: 14 Weeks, 0 Days Container: Reel | 0 |
|
$0.4406 / $0.4498 | Buy Now |
|
DISTI #
511-M93C86-RDW3TP/K
|
Mouser Electronics | EEPROM Auto 16-Kb MICROWIRE serial EEPROM RoHS: Compliant | 372 |
|
$0.4590 / $0.7100 | Buy Now |
|
DISTI #
V79:2366_17796935
|
Arrow Electronics | EEPROM Serial-Microwire 16K-bit 2K x 8/1K x 16 2.5V/3.3V/5V Automotive AEC-Q100 8-Pin TSSOP T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 99 Weeks Date Code: 1421 | Americas - 2900 |
|
$0.4784 | Buy Now |
|
DISTI #
70521103
|
RS | M93C86-RDW3TP/K Serial EEPROM Memory, 16kbit, 4ms, 1.8 to 5.5 V 8-Pin TSSOP Min Qty: 10 Package Multiple: 1 Container: Bulk | 0 |
|
$0.7800 | RFQ |
|
|
STMicroelectronics | Automotive 16-Kbit MICROWIRE serial EEPROM RoHS: Compliant Min Qty: 1 | 372 |
|
$0.5200 / $0.7000 | Buy Now |
|
DISTI #
26119502
|
Verical | EEPROM Serial-Microwire 16K-bit 2K x 8/1K x 16 2.5V/3.3V/5V Automotive AEC-Q100 8-Pin TSSOP T/R RoHS: Compliant Min Qty: 13 Package Multiple: 1 Date Code: 1421 | Americas - 2900 |
|
$0.4784 | Buy Now |
|
|
Bristol Electronics | 3820 |
|
RFQ | ||
|
|
Quest Components | 3056 |
|
$0.5402 / $1.8005 | Buy Now | |
|
DISTI #
M93C86-RDW3TP/K
|
Avnet Silica | EEPROM SerialMicrowire 16Kbit 2K x 81K x 16 25V33V5V 8Pin TSSOP TR (Alt: M93C86-RDW3TP/K) RoHS: Compliant Min Qty: 4000 Package Multiple: 4000 Lead time: 15 Weeks, 0 Days | Silica - 4000 |
|
Buy Now |
Part Details for M93C86-RDW3TP/K
M93C86-RDW3TP/K CAD Models
M93C86-RDW3TP/K Part Data Attributes
|
|
M93C86-RDW3TP/K
STMicroelectronics
Buy Now
Datasheet
|
Compare Parts:
M93C86-RDW3TP/K
STMicroelectronics
Automotive 16-Kbit MICROWIRE serial EEPROM
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | STMICROELECTRONICS | |
| Package Description | 0.169 INCH, HALOGEN FREE AND ROHS COMPLIANT, TSSOP-8 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.32.00.51 | |
| Factory Lead Time | 14 Weeks | |
| Samacsys Manufacturer | STMicroelectronics | |
| Alternate Memory Width | 8 | |
| Clock Frequency-Max (fCLK) | 2 MHz | |
| JESD-30 Code | R-PDSO-G8 | |
| JESD-609 Code | e4 | |
| Length | 4.4 mm | |
| Memory Density | 16384 bit | |
| Memory IC Type | EEPROM | |
| Memory Width | 16 | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 8 | |
| Number of Words | 1024 words | |
| Number of Words Code | 1000 | |
| Operating Mode | SYNCHRONOUS | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Organization | 1KX16 | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | TSSOP | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, THIN PROFILE, SHRINK PITCH | |
| Parallel/Serial | SERIAL | |
| Peak Reflow Temperature (Cel) | 260 | |
| Screening Level | AEC-Q100 | |
| Seated Height-Max | 1.2 mm | |
| Serial Bus Type | MICROWIRE | |
| Supply Voltage-Max (Vsup) | 5.5 V | |
| Supply Voltage-Min (Vsup) | 1.8 V | |
| Supply Voltage-Nom (Vsup) | 2.5 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Temperature Grade | AUTOMOTIVE | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 3 mm | |
| Write Cycle Time-Max (tWC) | 4 ms |
