Part Details for M80-5C12005M3 by Harwin
Results Overview of M80-5C12005M3 by Harwin
- Distributor Offerings: (6 listings)
- Number of FFF Equivalents: (1 replacement)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
M80-5C12005M3 Information
M80-5C12005M3 by Harwin is a Header and Edge Type Connector.
Headers and Edge Type Connectors are under the broader part category of Connectors.
Connectors are devices that join electrical termination points to form circuits. With various types designed for specific functions like data, power, or signal transmission, choosing the right connector is essential for compatibility and device performance. Read more about Connectors on our Connectors part category page.
Price & Stock for M80-5C12005M3
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
52AC5370
|
Newark | 10+10 Pos. Male Dil 24-28Awg Cable Conn. Kit, Panel Mount Rohs Compliant: Yes |Harwin M80-5C12005M3 RoHS: Compliant Min Qty: 13 Package Multiple: 1 Date Code: 0 Container: Bulk | 0 |
|
Buy Now | |
|
DISTI #
M80-5C12005M3-ND
|
DigiKey | DATAMATE J-TEK DIL MALE SMALL BO Min Qty: 1 Lead time: 11 Weeks Container: Bulk |
12 In Stock |
|
$21.0057 / $31.0100 | Buy Now |
|
DISTI #
855-M80-5C12005M3
|
Mouser Electronics | Power to the Board DatamateJTekMDIL Cbl Conn Kit RoHS: Compliant | 38 |
|
$20.2200 / $30.9100 | Buy Now |
|
|
Powell Electronics | Datamate J-Tek DIL Male Small Bore (24-2 Min Qty: 1 | 12 |
|
$35.0300 | Buy Now |
|
DISTI #
M80-5C12005M3
|
Avnet Abacus | Rectangular Connector Datamate JTek M80 20 Contacts Plug 2 mm Crimp 2 Row (Alt: M80-5C12005M3) RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 11 Weeks, 0 Days | Abacus - 0 |
|
Buy Now | |
|
|
New Advantage Corporation | Datamate J-Tek Male DIL Cable Connector Kit 2.00mm Pitch RoHS: Compliant Min Qty: 1 Package Multiple: 1 | 264 |
|
$27.8900 / $30.1400 | Buy Now |
Part Details for M80-5C12005M3
M80-5C12005M3 CAD Models
M80-5C12005M3 Part Data Attributes
|
|
M80-5C12005M3
Harwin
Buy Now
Datasheet
|
Compare Parts:
M80-5C12005M3
Harwin
Board Connector, 20 Contact(s), 2 Row(s), Female, 0.079 inch Pitch, Crimp Terminal, M2x0.4, Black Insulator, Receptacle
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | HARWIN PLC | |
| Reach Compliance Code | not_compliant | |
| Samacsys Manufacturer | Harwin | |
| Body Breadth | 0.238 inch | |
| Body Depth | 0.309 inch | |
| Body Length | 1.181 inch | |
| Body/Shell Style | RECEPTACLE | |
| Connector Type | BOARD CONNECTOR | |
| Contact Finish Mating | NOT APPLICABLE | |
| Contact Finish Termination | Gold (Au) | |
| Contact Gender | FEMALE | |
| Contact Material | BRASS | |
| Contact Pattern | RECTANGULAR | |
| Contact Resistance | 25 mΩ | |
| Contact Style | RND PIN-SKT | |
| Durability | 500 Cycles | |
| Filter Feature | NO | |
| Insertion Force-Max | 2.78 N | |
| Insulation Diameter-Min | 0.043 inch | |
| Insulation Resistance | 100000000 Ω | |
| Insulator Color | BLACK | |
| Insulator Material | GLASS FILLED POLYPHENYLENE SULFIDE | |
| JESD-609 Code | e4 | |
| Mating Contact Pitch | 0.079 inch | |
| Mating Contact Row Spacing | 0.079 inch | |
| Mixed Contacts | NO | |
| Mounting Option 1 | M2X0.4 | |
| Mounting Option 2 | JACKSCREW | |
| Mounting Type | CABLE | |
| Number Of Connectors | ONE | |
| Number of Rows Loaded | 2 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -55 °C | |
| Reference Standard | UL | |
| Termination Type | CRIMP | |
| Total Number of Contacts | 20 | |
| Wire Size-Max | 24 AWG | |
| Wire Size-Min | 28 AWG |
Alternate Parts for M80-5C12005M3
This table gives cross-reference parts and alternative options found for M80-5C12005M3. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of M80-5C12005M3, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| M80-5C12005M3-00-000-00-000 | Harwin | Check for Price | Board Connector, 20 Contact(s), 2 Row(s), Male, 0.079 inch Pitch, Crimp Terminal, M2, Black Insulator, Receptacle | M80-5C12005M3 vs M80-5C12005M3-00-000-00-000 |
M80-5C12005M3 Frequently Asked Questions (FAQ)
-
The recommended torque for the M80-5C12005M3 connector is 0.5 Nm to 1.5 Nm, depending on the specific application and environment.
-
Yes, the M80-5C12005M3 connector is designed to withstand high-vibration environments, with a tested vibration resistance of 10-2000 Hz, 10G peak acceleration.
-
Yes, the M80-5C12005M3 connector is designed to operate in harsh environments, with a temperature range of -40°C to +125°C and humidity resistance of up to 95% RH.
-
The M80-5C12005M3 connector has a mating cycle life of up to 500 cycles, depending on the specific application and environment.
-
Yes, the M80-5C12005M3 connector is designed to be compatible with automated assembly processes, including pick-and-place machines and robotic assembly systems.
