M3087BFLGP#U3 Information
M3087BFLGP#U3 by Renesas Electronics Corporation is a Microcontroller.
Microcontrollers are under the broader part category of Microcontrollers and Processors.
Microcontrollers (MCUs) are small, low-power integrated circuits used to control embedded systems. Microcontrollers are primarily used to automate and control devices. Read more about Microcontrollers and Processors on our Microcontrollers and Processors part category page.
Price & Stock for M3087BFLGP#U3
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
23AH3324
|
Newark | Mcu, 16Bit, 32Mhz, Lfqfp-144, Product Range:M16C Family M32C/80 Series M32C/87 Group Microcontrollers, Device Core:M32C/80, Data Bus Width:16 Bit, Operating Frequency Max:32Mhz, Program Memory Size:1Mb, No. Of Pins:144Pins Rohs Compliant: Yes |Renesas M3087BFLGP#U3 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk | 57 |
|
$55.6400 / $71.2200 | Buy Now |
|
DISTI #
M3087BFLGP#U3-ND
|
DigiKey | IC MCU 16/32BIT 1MB FLSH 144LQFP Min Qty: 1 Lead time: 18 Weeks Container: Tray |
1102 In Stock |
|
$54.1668 / $73.5600 | Buy Now |
|
DISTI #
M3087BFLGP#U3
|
Avnet Americas | MCU 16-bit M16C CISC 1024KB Flash 3.3V/5V 144-Pin LQFP Tray - Trays (Alt: M3087BFLGP#U3) RoHS: Compliant Min Qty: 60 Package Multiple: 60 Lead time: 12 Weeks, 0 Days Container: Tray | 0 |
|
$51.7300 | Buy Now |
|
DISTI #
968-M3087BFLGP#U3
|
Mouser Electronics | 16-bit Microcontrollers - MCU MCU 3/5V 1024K I-temp Pb-free 144-LQFP RoHS: Compliant | 144 |
|
$54.1600 / $72.2600 | Buy Now |
|
DISTI #
M3087BFLGP#U3
|
Avnet Silica | MCU 16bit M16C CISC 1024KB Flash 33V5V 144Pin LQFP Tray (Alt: M3087BFLGP#U3) RoHS: Compliant Min Qty: 60 Package Multiple: 60 Lead time: 20 Weeks, 0 Days | Silica - 300 |
|
Buy Now |
Part Details for M3087BFLGP#U3
M3087BFLGP#U3 CAD Models
M3087BFLGP#U3 Part Data Attributes
|
|
M3087BFLGP#U3
Renesas Electronics Corporation
Buy Now
Datasheet
|
Compare Parts:
M3087BFLGP#U3
Renesas Electronics Corporation
M3087BFLGP#U3
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | RENESAS ELECTRONICS CORP | |
| Part Package Code | LFQFP | |
| Package Description | LQFP-144 | |
| Pin Count | 144 | |
| Manufacturer Package Code | PLQP0144KA-A144 | |
| Reach Compliance Code | compliant | |
| ECCN Code | 3A991.A.2 | |
| HTS Code | 8542.31.00.01 | |
| Factory Lead Time | 12 Weeks | |
| Samacsys Manufacturer | Renesas Electronics | |
| Has ADC | YES | |
| Additional Feature | ALSO OPERATES AT 3V MINIMUM SUPPLY AT 24 MHZ; ADC IS 18-CH 10-BIT IN MEMORY EXPANSION AND UP MODE | |
| Address Bus Width | 24 | |
| Bit Size | 32 | |
| Boundary Scan | NO | |
| Clock Frequency-Max | 32 MHz | |
| DAC Channels | YES | |
| DMA Channels | YES | |
| External Data Bus Width | 16 | |
| JESD-30 Code | S-PQFP-G144 | |
| Length | 20 mm | |
| Number of I/O Lines | 124 | |
| Number of Terminals | 144 | |
| On Chip Program ROM Width | 8 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -20 °C | |
| PWM Channels | YES | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | LFQFP | |
| Package Shape | SQUARE | |
| Package Style | FLATPACK, LOW PROFILE, FINE PITCH | |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED | |
| RAM (bytes) | 49152 | |
| ROM (words) | 1048576 | |
| ROM Programmability | FLASH | |
| Seated Height-Max | 1.7 mm | |
| Speed | 32 MHz | |
| Supply Voltage-Max | 5.5 V | |
| Supply Voltage-Min | 5 V | |
| Supply Voltage-Nom | 5 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Temperature Grade | OTHER | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | QUAD | |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED | |
| Width | 20 mm | |
| uPs/uCs/Peripheral ICs Type | MICROCONTROLLER |
