M29W160EB70N6E Information
M29W160EB70N6E by STMicroelectronics is a Flash Memory.
Flash Memories are under the broader part category of Memory Components.
Memory components are essential in electronics for computer processing. They can be volatile or non-volatile, depending on the desired function. Read more about Memory Components on our Memory part category page.
Price & Stock for M29W160EB70N6E
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
|
Bristol Electronics | 15 |
|
RFQ | ||
|
|
Bristol Electronics | 14 |
|
RFQ | ||
|
|
Quest Components | IC,EEPROM,NOR FLASH,1MX16/2MX8,CMOS,TSSOP,48PIN,PLASTIC | 16 |
|
$4.5000 / $6.7500 | Buy Now |
|
|
Quest Components | IC,EEPROM,NOR FLASH,1MX16/2MX8,CMOS,TSSOP,48PIN,PLASTIC (Also Known As: M29W160EB-70N6E) | 16 |
|
$4.5000 / $6.7500 | Buy Now |
|
|
Quest Components | IC,EEPROM,NOR FLASH,1MX16/2MX8,CMOS,TSSOP,48PIN,PLASTIC | 2 |
|
$3.0000 / $4.0000 | Buy Now |
|
|
Quest Components | IC,EEPROM,NOR FLASH,1MX16/2MX8,CMOS,TSSOP,48PIN,PLASTIC (Also Known As: M29W160EB-70N6E) | 2 |
|
$3.0000 / $4.0000 | Buy Now |
|
|
Quest Components | IC,EEPROM,NOR FLASH,1MX16/2MX8,CMOS,TSSOP,48PIN,PLASTIC (Also Known As: M29W160EB-70N6E) | 1 |
|
$4.5000 / $6.7500 | Buy Now |
|
|
Quest Components | IC,EEPROM,NOR FLASH,1MX16/2MX8,CMOS,TSSOP,48PIN,PLASTIC | 1 |
|
$4.5000 / $6.7500 | Buy Now |
|
|
ComSIT USA | 16 MBIT PARALLEL NOR FLASH EMBEDDED MEMORY Flash, 1MX16, 70ns, PDSO48 ECCN: EAR99 RoHS: Compliant |
|
|
RFQ | |
|
|
Chip 1 Exchange | INSTOCK | 1997 |
|
RFQ |
Part Details for M29W160EB70N6E
M29W160EB70N6E CAD Models
M29W160EB70N6E Part Data Attributes
|
|
M29W160EB70N6E
STMicroelectronics
Buy Now
Datasheet
|
Compare Parts:
M29W160EB70N6E
STMicroelectronics
1MX16 FLASH 3V PROM, 70ns, PDSO48, 12 X 20 MM, PLASTIC, TSOP-48
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Transferred | |
| Ihs Manufacturer | STMICROELECTRONICS | |
| Part Package Code | TSOP | |
| Package Description | 12 X 20 MM, PLASTIC, TSOP-48 | |
| Pin Count | 48 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.32.00.51 | |
| Samacsys Manufacturer | STMicroelectronics | |
| Access Time-Max | 70 ns | |
| Additional Feature | BOTTOM BOOT BLOCK | |
| Alternate Memory Width | 8 | |
| Boot Block | BOTTOM | |
| Command User Interface | YES | |
| Common Flash Interface | YES | |
| Data Polling | YES | |
| JESD-30 Code | R-PDSO-G48 | |
| Length | 18.4 mm | |
| Memory Density | 16777216 bit | |
| Memory IC Type | FLASH | |
| Memory Width | 16 | |
| Number of Functions | 1 | |
| Number of Sectors/Size | 1,2,1,31 | |
| Number of Terminals | 48 | |
| Number of Words | 1048576 words | |
| Number of Words Code | 1000000 | |
| Operating Mode | ASYNCHRONOUS | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Organization | 1MX16 | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | TSOP1 | |
| Package Equivalence Code | TSSOP48,.8,20 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, THIN PROFILE | |
| Parallel/Serial | PARALLEL | |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED | |
| Programming Voltage | 3 V | |
| Qualification Status | Not Qualified | |
| Ready/Busy | YES | |
| Seated Height-Max | 1.2 mm | |
| Sector Size | 16K,8K,32K,64K | |
| Standby Current-Max | 0.0001 A | |
| Supply Current-Max | 0.02 mA | |
| Supply Voltage-Max (Vsup) | 3.6 V | |
| Supply Voltage-Min (Vsup) | 2.7 V | |
| Supply Voltage-Nom (Vsup) | 3 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED | |
| Toggle Bit | YES | |
| Type | NOR TYPE | |
| Width | 12 mm |
