Part Details for LTC4416EMS-1#TRPBF by Analog Devices Inc
Results Overview of LTC4416EMS-1#TRPBF by Analog Devices Inc
- Distributor Offerings: (8 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (3 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Industrial Automation
Energy and Power Systems
Transportation and Logistics
Renewable Energy
Automotive
LTC4416EMS-1#TRPBF Information
LTC4416EMS-1#TRPBF by Analog Devices Inc is a Power Management Circuit.
Power Management Circuits are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for LTC4416EMS-1#TRPBF
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
50AK3706
|
Newark | Powerpath Controller, Msop-10, Ic Function:Powerpath Controller, Supply Voltage Min:3.6V, Supply Voltage Max:36V, Ic Package Type:Msop, No. Of Pins:10Pins, Operating Temperature Min:-40°C, Operating Temperature Max:85°C Rohs Compliant: Yes |Analog Devices LTC4416EMS-1#TRPBF RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 1801 |
|
$3.9000 / $6.9500 | Buy Now |
|
DISTI #
LTC4416EMS-1#TRPBFCT-ND
|
DigiKey | IC OR CTRLR SRC SELECT 10MSOP Min Qty: 1 Lead time: 13 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
3867 In Stock |
|
$3.6875 / $8.5200 | Buy Now |
|
DISTI #
584-C4416EMS-1TRPBF
|
Mouser Electronics | Power Management Specialized - PMIC 36V, L Loss 2x PwrPath Cntrs for Lrg PFE RoHS: Compliant | 618 |
|
$3.7300 / $6.9500 | Buy Now |
|
DISTI #
V36:1790_06490783
|
Arrow Electronics | OR Controller P-channel Dual 10-Pin MSOP T/R RoHS: Compliant Min Qty: 2500 Package Multiple: 2500 Lead time: 10 Weeks Date Code: 2345 | Americas - 2500 |
|
$3.6040 | Buy Now |
|
DISTI #
V72:2272_06490783
|
Arrow Electronics | OR Controller P-channel Dual 10-Pin MSOP T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 10 Weeks Date Code: 2102 Container: Cut Strips | Americas - 232 |
|
$3.7830 / $4.2410 | Buy Now |
|
|
Analog Devices Inc | 36V, L Loss 2x PwrPath Cntrs f Min Qty: 1 Package Multiple: 2500 | 774 |
|
$2.9500 / $8.5200 | Buy Now |
|
DISTI #
LTC4416EMS-1TRP
|
Richardson RFPD | POWER MANAGEMENT IC RoHS: Compliant Min Qty: 2500 | 0 |
|
$3.8000 / $3.9600 | Buy Now |
|
|
Win Source Electronics | IC OR CTRLR SRC SELECT 10MSOP / OR Controller Source Selector Switch P-Channel 2:2 10-MSOP | 4501 |
|
$5.2137 / $7.8205 | Buy Now |
Part Details for LTC4416EMS-1#TRPBF
LTC4416EMS-1#TRPBF CAD Models
LTC4416EMS-1#TRPBF Part Data Attributes
|
|
LTC4416EMS-1#TRPBF
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
LTC4416EMS-1#TRPBF
Analog Devices Inc
LTC4416EMS-1#TRPBF
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Package Description | LEAD FREE, PLASTIC, MSOP-10 | |
| Pin Count | 10 | |
| Manufacturer Package Code | 05-08-1661 | |
| Reach Compliance Code | compliant | |
| Samacsys Manufacturer | Analog Devices | |
| Adjustable Threshold | NO | |
| Analog IC - Other Type | POWER SUPPLY SUPPORT CIRCUIT | |
| JESD-30 Code | S-PDSO-G10 | |
| JESD-609 Code | e3 | |
| Length | 3 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Channels | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 10 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | ||
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | TSSOP | |
| Package Shape | SQUARE | |
| Package Style | SMALL OUTLINE, THIN PROFILE, SHRINK PITCH | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.1 mm | |
| Supply Voltage-Max (Vsup) | 36 V | |
| Supply Voltage-Min (Vsup) | 3.6 V | |
| Supply Voltage-Nom (Vsup) | 12 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Temperature Grade | COMMERCIAL EXTENDED | |
| Terminal Finish | Matte Tin (Sn) - annealed | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 3 mm |
Alternate Parts for LTC4416EMS-1#TRPBF
This table gives cross-reference parts and alternative options found for LTC4416EMS-1#TRPBF. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of LTC4416EMS-1#TRPBF, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| LTC4416EMS-1#TRPBF | Linear Technology | Check for Price | LTC4416/LTC4416-1 - 36V, Low Loss Dual PowerPath Controllers for Large PFETs; Package: MSOP; Pins: 10; Temperature Range: -40°C to 85°C | LTC4416EMS-1#TRPBF vs LTC4416EMS-1#TRPBF |
| LTC4416EMS-1#TR | Analog Devices Inc | Check for Price | Power Supply Support Circuit, Fixed, 1 Channel, PDSO10 | LTC4416EMS-1#TRPBF vs LTC4416EMS-1#TR |
| LTC4416EMS-1#TR | Linear Technology | Check for Price | IC 1-CHANNEL POWER SUPPLY SUPPORT CKT, PDSO10, PLASTIC, MSOP-10, Power Management Circuit | LTC4416EMS-1#TRPBF vs LTC4416EMS-1#TR |
