Part Details for LTC4413EDD-1#PBF by Analog Devices Inc
Results Overview of LTC4413EDD-1#PBF by Analog Devices Inc
- Distributor Offerings: (8 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (1 option)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Consumer Electronics
Energy and Power Systems
Transportation and Logistics
Renewable Energy
Automotive
LTC4413EDD-1#PBF Information
LTC4413EDD-1#PBF by Analog Devices Inc is an Other Signal Circuit.
Other Signal Circuits are under the broader part category of Signal Circuits.
A signal is an electronic means of transmitting information, either as an analog signal with continuous values or a digital signal with discrete values. Signals are used in various systems and networks. Read more about Signal Circuits on our Signal Circuits part category page.
Price & Stock for LTC4413EDD-1#PBF
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
51AK7237
|
Newark | Ideal Diode, Dual, Monolithic, Dfn-Ep-10, Ic Function:Ideal Diode Controller, Supply Voltage Min:2.5V, Supply Voltage Max:5.5V, Ic Package Type:Dfn-Ep, No. Of Pins:10Pins, Operating Temperature Min:-40°C, Product Range:- Rohs Compliant: Yes |Analog Devices LTC4413EDD-1#PBF RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk | 133 |
|
$3.3100 / $6.3100 | Buy Now |
|
DISTI #
505-LTC4413EDD-1#PBF-ND
|
DigiKey | IC OR CTRLR SRC SELECT 10DFN Min Qty: 1 Lead time: 10 Weeks Container: Tube |
9202 In Stock |
|
$3.3125 / $7.8700 | Buy Now |
|
DISTI #
584-LTC4413EDD-1#PBF
|
Mouser Electronics | Power Management Specialized - PMIC 2x 2.6A, 2.5V to 5.5V Fast Ideal Diodes RoHS: Compliant | 19086 |
|
$3.3100 / $6.3100 | Buy Now |
|
DISTI #
E54:1762_00091470
|
Arrow Electronics | OR Controller P-channel Dual 0.14Ohm 10-Pin DFN EP Tube RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 10 Weeks Date Code: 2513 | Europe - 2165 |
|
$3.1720 / $6.2250 | Buy Now |
|
|
Analog Devices Inc | 2x 2.6A, 2.5V to 5.5V Fast Id Package Multiple: 121 | 2325 |
|
$2.6500 / $7.8700 | Buy Now |
|
DISTI #
88767006
|
Verical | OR Controller P-channel Dual 0.14Ohm 10-Pin DFN EP Tube RoHS: Compliant Min Qty: 2 Package Multiple: 1 Date Code: 2513 | Americas - 2164 |
|
$3.0700 | Buy Now |
|
DISTI #
35212092
|
Verical | OR Controller P-channel Dual 0.14Ohm 10-Pin DFN EP Tube RoHS: Compliant Min Qty: 121 Package Multiple: 121 | Americas - 484 |
|
$3.2777 | Buy Now |
|
DISTI #
LTC4413EDD-1PBF
|
Richardson RFPD | POWER MANAGEMENT IC RoHS: Compliant Min Qty: 121 | 0 |
|
$3.4200 / $3.7500 | Buy Now |
Part Details for LTC4413EDD-1#PBF
LTC4413EDD-1#PBF CAD Models
LTC4413EDD-1#PBF Part Data Attributes
|
|
LTC4413EDD-1#PBF
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
LTC4413EDD-1#PBF
Analog Devices Inc
LTC4413EDD-1#PBF
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Package Description | DFN-10 | |
| Pin Count | 10 | |
| Manufacturer Package Code | 05-08-1699 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Analog Devices | |
| Analog IC - Other Type | ANALOG CIRCUIT | |
| JESD-30 Code | S-PDSO-N10 | |
| JESD-609 Code | e3 | |
| Length | 3 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Channels | 2 | |
| Number of Functions | 1 | |
| Number of Terminals | 10 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | HVSON | |
| Package Equivalence Code | SOLCC10,.12,20 | |
| Package Shape | SQUARE | |
| Package Style | SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 0.8 mm | |
| Supply Voltage-Max (Vsup) | 5.5 V | |
| Supply Voltage-Min (Vsup) | 2.5 V | |
| Supply Voltage-Nom (Vsup) | 3.6 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | NO LEAD | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 3 mm |
Alternate Parts for LTC4413EDD-1#PBF
This table gives cross-reference parts and alternative options found for LTC4413EDD-1#PBF. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of LTC4413EDD-1#PBF, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| LTC4413EDD-1#TRPBF | Analog Devices Inc | $3.8372 | LTC4413EDD-1#TRPBF | LTC4413EDD-1#PBF vs LTC4413EDD-1#TRPBF |
