LTC4365HTS8#TRMPBF Information
LTC4365HTS8#TRMPBF by Analog Devices Inc is a Power Management Circuit.
Power Management Circuits are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for LTC4365HTS8#TRMPBF
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
50AK3607
|
Newark | Hot-Swap Ctrl, -40 To 125Deg C, Tsot-23, No. Of Channels:-, Supply Voltage Min:2.5V, Supply Voltage Max:34V, Ic Case/Package:Tsot-23, No. Of Pins:8Pins, Power Switch:-, Ic Mounting:Surface Mount, Ic Function:-, Product Range:- Rohs Compliant: Yes |Analog Devices LTC4365HTS8#TRMPBF RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 112 |
|
$2.8400 / $5.2900 | Buy Now |
|
DISTI #
505-LTC4365HTS8#TRMPBFCT-ND
|
DigiKey | IC OVERVOLTAGE PROT TSOT23-8 Min Qty: 1 Lead time: 10 Weeks Container: Digi-Reel®, Tape & Reel (TR), Cut Tape (CT) |
2562 In Stock |
|
$2.7250 / $6.8200 | Buy Now |
|
DISTI #
584-C4365HTS8TRMPBF
|
Mouser Electronics | Board Mount Surge Protectors Overvoltage, Undervoltage & Reverse S Pr RoHS: Compliant | 483 |
|
$2.8200 / $5.2900 | Buy Now |
|
DISTI #
E22:3490_02940900
|
Arrow Electronics | Over Voltage Protection Controller 8-Pin TSOT-23 T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 10 Weeks Date Code: 2447 | Europe - 8 |
|
$2.5880 / $5.2160 | Buy Now |
|
|
Analog Devices Inc | Overvoltage, Undervoltage & Re Package Multiple: 500 | 513 |
|
$2.1800 / $6.8200 | Buy Now |
|
DISTI #
LTC4365HTS8TRMP
|
Richardson RFPD | POWER MANAGEMENT IC RoHS: Compliant Min Qty: 500 | 0 |
|
$2.8200 / $3.0100 | Buy Now |
|
DISTI #
SMC-LTC4365HTS8#TRMPBF
|
Sensible Micro Corporation | OEM Excess 5-7 Days Leadtime, We are an AS6081 Certified Vendor, 1 Yr Warranty RoHS: Not Compliant Min Qty: 25 Lead time: 2 Weeks, 0 Days Date Code: 2424 Container: Tape & Reel | 58 |
|
RFQ |
Part Details for LTC4365HTS8#TRMPBF
LTC4365HTS8#TRMPBF CAD Models
LTC4365HTS8#TRMPBF Part Data Attributes
|
|
LTC4365HTS8#TRMPBF
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
LTC4365HTS8#TRMPBF
Analog Devices Inc
Overvoltage, Undervoltage and Reverse Supply Protection Controller
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Package Description | TSOT-23, 8 PIN | |
| Pin Count | 8 | |
| Manufacturer Package Code | 05-08-1637 | |
| Reach Compliance Code | compliant | |
| Samacsys Manufacturer | Analog Devices | |
| Adjustable Threshold | NO | |
| Analog IC - Other Type | POWER SUPPLY SUPPORT CIRCUIT | |
| JESD-30 Code | R-PDSO-G8 | |
| JESD-609 Code | e3 | |
| Length | 2.9 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Channels | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 8 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | VSSOP | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, VERY THIN PROFILE, SHRINK PITCH | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1 mm | |
| Supply Voltage-Max (Vsup) | 34 V | |
| Supply Voltage-Min (Vsup) | 2.5 V | |
| Supply Voltage-Nom (Vsup) | 5 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Temperature Grade | AUTOMOTIVE | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 1.625 mm |
Alternate Parts for LTC4365HTS8#TRMPBF
This table gives cross-reference parts and alternative options found for LTC4365HTS8#TRMPBF. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of LTC4365HTS8#TRMPBF, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| LTC4365CTS8#TRMPBF | Analog Devices Inc | $2.4887 | Overvoltage, Undervoltage and Reverse Supply Protection Controller | LTC4365HTS8#TRMPBF vs LTC4365CTS8#TRMPBF |
| LTC4365CTS8#TRPBF | Analog Devices Inc | $2.9060 | Overvoltage, Undervoltage and Reverse Supply Protection Controller | LTC4365HTS8#TRMPBF vs LTC4365CTS8#TRPBF |
| LTC4365ITS8#PBF | Analog Devices Inc | Check for Price | Overvoltage, Undervoltage and Reverse Supply Protection Controller | LTC4365HTS8#TRMPBF vs LTC4365ITS8#PBF |
| LTC4365ITS8#PBF | Linear Technology | Check for Price | LTC4365 - Overvoltage, Undervoltage and Reverse Supply Protection Controller; Package: SOT; Pins: 8; Temperature Range: -40°C to 85°C | LTC4365HTS8#TRMPBF vs LTC4365ITS8#PBF |
| LTC4365CTS8#TRMPBF | Linear Technology | Check for Price | LTC4365 - Overvoltage, Undervoltage and Reverse Supply Protection Controller; Package: SOT; Pins: 8; Temperature Range: 0°C to 70°C | LTC4365HTS8#TRMPBF vs LTC4365CTS8#TRMPBF |
| LTC4365HTS8#TRPBF | Analog Devices Inc | Check for Price | Overvoltage, Undervoltage and Reverse Supply Protection Controller | LTC4365HTS8#TRMPBF vs LTC4365HTS8#TRPBF |
| LTC4365HTS8#TRMPBF | Linear Technology | Check for Price | LTC4365 - Overvoltage, Undervoltage and Reverse Supply Protection Controller; Package: SOT; Pins: 8; Temperature Range: -40°C to 125°C | LTC4365HTS8#TRMPBF vs LTC4365HTS8#TRMPBF |
| LTC4365CTS8#PBF | Linear Technology | Check for Price | LTC4365 - Overvoltage, Undervoltage and Reverse Supply Protection Controller; Package: SOT; Pins: 8; Temperature Range: 0°C to 70°C | LTC4365HTS8#TRMPBF vs LTC4365CTS8#PBF |
LTC4365HTS8#TRMPBF Frequently Asked Questions (FAQ)
-
The maximum voltage rating for the input pins is 80V, but it's recommended to keep the input voltage below 60V for reliable operation.
-
To ensure the OVP threshold is accurate, make sure to decouple the VIN pin with a 10uF capacitor to GND, and use a low-ESR capacitor to minimize voltage droop.
-
For optimal performance, keep the input capacitors close to the VIN pin, and use a star-ground configuration to minimize noise. Also, keep the GND pin connected to a solid ground plane to reduce noise and EMI.
-
The OCP threshold can be adjusted by connecting a resistor (RILT) between the ILIM pin and GND. The OCP threshold (Ilim) is calculated as Ilim = 0.5V / RILT.
-
The FAULT pin is an open-drain output that indicates when an overvoltage or overcurrent fault occurs. You can connect a pull-up resistor to a voltage source (e.g., 3.3V or 5V) and monitor the FAULT pin to detect faults.
