Part Details for LTC4279IUFD#TRPBF
LTC4279IUFD#TRPBF CAD Models
LTC4279IUFD#TRPBF Part Data Attributes
|
|
LTC4279IUFD#TRPBF
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
LTC4279IUFD#TRPBF
Analog Devices Inc
Single Port PoE/PoE+/LTPoE++ PSE Controller
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Package Description | QFN-20 | |
| Pin Count | 20 | |
| Manufacturer Package Code | 05-08-1711 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Analog Devices | |
| JESD-30 Code | R-PQCC-N20 | |
| JESD-609 Code | e3 | |
| Length | 5 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Terminals | 20 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | HVQCCN | |
| Package Equivalence Code | LCC20,.2X.16,20 | |
| Package Shape | RECTANGULAR | |
| Package Style | CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Seated Height-Max | 0.8 mm | |
| Supply Voltage-Max | 57 V | |
| Supply Voltage-Min | 45 V | |
| Supply Voltage-Nom | 54 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | NO LEAD | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | QUAD | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 4 mm | |
| uPs/uCs/Peripheral ICs Type | PSE CONTROLLER |
LTC4279IUFD#TRPBF Frequently Asked Questions (FAQ)
-
A good PCB layout for the LTC4279IUFD involves keeping the input and output capacitors close to the IC, using a solid ground plane, and minimizing the length of the traces between the IC and the capacitors. A 4-layer PCB with a dedicated power plane and a dedicated ground plane is recommended.
-
To ensure stability, make sure the input and output capacitors are of high quality and have low ESR. Also, ensure the PCB layout is well-designed, and the input and output voltage rails are well-bypassed. Additionally, the datasheet recommends a minimum output capacitance of 10uF to ensure stability.
-
The maximum input voltage that the LTC4279IUFD can handle is 28V. Exceeding this voltage may damage the IC.
-
The LTC4279IUFD is rated for operation from -40°C to 125°C. However, the IC's performance may degrade at high temperatures, and the maximum junction temperature should not exceed 150°C.
-
The output voltage of the LTC4279IUFD can be calculated using the formula: Vout = (R1/R2) * (Vin - Vref), where R1 and R2 are the resistors in the feedback network, Vin is the input voltage, and Vref is the reference voltage (typically 1.2V).
