LTC4260IUH#PBF Information
LTC4260IUH#PBF by Analog Devices Inc is a Power Management Circuit.
Power Management Circuits are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for LTC4260IUH#PBF
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
51AK7139
|
Newark | Hot-Swap Ctrl, -40 To 85Deg C, Qfn-32, No. Of Channels:-, Supply Voltage Min:8.5V, Supply Voltage Max:80V, Ic Case/Package:Qfn, No. Of Pins:32Pins, Power Switch:-, Ic Mounting:Surface Mount, Ic Function:-, Product Range:- Rohs Compliant: Yes |Analog Devices LTC4260IUH#PBF RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk | 80 |
|
$12.2700 / $19.9000 | Buy Now |
|
DISTI #
LTC4260IUH#PBF-ND
|
DigiKey | IC HOT SWAP CTRLR GP 32QFN Min Qty: 1 Lead time: 20 Weeks Container: Tube |
256 In Stock |
|
$11.7375 / $20.3700 | Buy Now |
|
DISTI #
584-LTC4260IUH#PBF
|
Mouser Electronics | Hot Swap Voltage Controllers Pos Hi V Hot Swap Cntr w/ I2C Compatible RoHS: Compliant | 225 |
|
$12.1800 / $19.9000 | Buy Now |
|
DISTI #
V36:1790_06488931
|
Arrow Electronics | Hot Swap Controller 1-CH 80V N-Channel Positive High Voltage 32-Pin QFN EP Tube RoHS: Compliant Min Qty: 73 Package Multiple: 73 Lead time: 10 Weeks | Americas - 17 |
|
$11.7110 / $11.9690 | Buy Now |
|
|
Analog Devices Inc | Pos Hi V Hot Swap Cntr w/ I2C Package Multiple: 73 | 56 |
|
$9.3900 / $20.3700 | Buy Now |
|
DISTI #
88762411
|
Verical | Hot Swap Controller 1-CH 80V N-Channel Positive High Voltage 32-Pin QFN EP Tube RoHS: Compliant Min Qty: 17 Package Multiple: 17 Date Code: 2508 | Americas - 17 |
|
$11.7110 / $11.9690 | Buy Now |
|
DISTI #
LTC4260IUH#PBF
|
Richardson RFPD | POWER MANAGEMENT IC RoHS: Compliant Min Qty: 73 | 0 |
|
$12.1300 / $14.0900 | Buy Now |
Part Details for LTC4260IUH#PBF
LTC4260IUH#PBF CAD Models
LTC4260IUH#PBF Part Data Attributes
|
|
LTC4260IUH#PBF
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
LTC4260IUH#PBF
Analog Devices Inc
Positive High Voltage Hot Swap Controller with I<sup>2</sup>C Compatible Monitoring
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Package Description | 5 X 5 MM, LEAD FREE, PLASTIC, QFN-32 | |
| Pin Count | 32 | |
| Manufacturer Package Code | 05-08-1693 | |
| Reach Compliance Code | compliant | |
| Samacsys Manufacturer | Analog Devices | |
| Adjustable Threshold | NO | |
| Analog IC - Other Type | HOT SWAP CONTROLLER | |
| JESD-30 Code | S-PQCC-N32 | |
| JESD-609 Code | e3 | |
| Length | 5 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Channels | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 32 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | VQCCN | |
| Package Shape | SQUARE | |
| Package Style | CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 0.8 mm | |
| Supply Voltage-Max (Vsup) | 80 V | |
| Supply Voltage-Min (Vsup) | 8.5 V | |
| Supply Voltage-Nom (Vsup) | 48 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | NO LEAD | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | QUAD | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 5 mm |
