LTC3873ETS8-5#TRPBF Information
LTC3873ETS8-5#TRPBF by Analog Devices Inc is a Switching Regulator or Controller.
Switching Regulator or Controllers are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for LTC3873ETS8-5#TRPBF
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
161-LTC3873ETS8-5#TRPBFCT-ND
|
DigiKey | IC REG CTRLR MULT TOP TSOT23-8 Min Qty: 1 Lead time: 10 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
4567 In Stock |
|
$1.9125 / $5.2700 | Buy Now |
|
DISTI #
584-C3873ETS8-5TRPBF
|
Mouser Electronics | Switching Voltage Regulators No RSENSE Constant Frequency Current Mode Boost/Flyback/SEPIC DC/DC Controller RoHS: Compliant | 5403 |
|
$1.9300 / $3.8500 | Buy Now |
|
|
Analog Devices Inc | No RSENSE Const Freq C Mode Bo Min Qty: 1 Package Multiple: 2500 | 5914 |
|
$1.9125 / $5.2700 | Buy Now |
|
|
Bristol Electronics | 1815 |
|
RFQ | ||
|
DISTI #
LTC3873ETS8-5TRPBF
|
TME | PMIC, DC/DC converter, Uin: 4÷75VDC, Uout: 1.2÷60VDC, 10A, TSOT23-8 Min Qty: 2500 | 0 |
|
$1.4900 | RFQ |
|
DISTI #
LTC3873ETS85TRP
|
Richardson RFPD | POWER MANAGEMENT IC RoHS: Compliant Min Qty: 2500 | 0 |
|
$1.9800 / $2.0500 | Buy Now |
Part Details for LTC3873ETS8-5#TRPBF
LTC3873ETS8-5#TRPBF CAD Models
LTC3873ETS8-5#TRPBF Part Data Attributes
|
|
LTC3873ETS8-5#TRPBF
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
LTC3873ETS8-5#TRPBF
Analog Devices Inc
No RSENSE™ Constant Frequency Current Mode Boost/Flyback/SEPIC DC/DC Controller
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Package Description | 1 MM HEIGHT, LEAD FREE, PLASTIC, TSOT-23, 8 PIN | |
| Pin Count | 8 | |
| Manufacturer Package Code | 05-08-1637 | |
| Reach Compliance Code | compliant | |
| Samacsys Manufacturer | Analog Devices | |
| Analog IC - Other Type | SWITCHING CONTROLLER | |
| Control Mode | CURRENT-MODE | |
| Control Technique | PULSE WIDTH MODULATION | |
| Input Voltage-Max | 9 V | |
| Input Voltage-Min | 3.5 V | |
| Input Voltage-Nom | 5 V | |
| JESD-30 Code | R-PDSO-G8 | |
| JESD-609 Code | e3 | |
| Length | 2.9 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 8 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | ||
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | VSSOP | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, VERY THIN PROFILE, SHRINK PITCH | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1 mm | |
| Surface Mount | YES | |
| Switcher Configuration | BUCK-BOOST | |
| Switching Frequency-Max | 240 kHz | |
| Technology | CMOS | |
| Temperature Grade | COMMERCIAL EXTENDED | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 1.625 mm |
