LTC3265MPDHC#PBF Information
LTC3265MPDHC#PBF by Analog Devices Inc is a Switching Regulator or Controller.
Switching Regulator or Controllers are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for LTC3265MPDHC#PBF
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
02AM2308
|
Newark | Dc-Dc Charge Pump, Boost, 150Deg C Rohs Compliant: Yes |Analog Devices LTC3265MPDHC#PBF RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk | 0 |
|
$15.1900 / $26.8900 | Buy Now |
|
DISTI #
LTC3265MPDHC#PBF-ND
|
DigiKey | IC REG CHARGE PUMP INV DL 18DFN Min Qty: 1 Lead time: 10 Weeks Container: Tube |
60 In Stock |
|
$15.1751 / $24.8400 | Buy Now |
|
DISTI #
584-LTC3265MPDHC#PBF
|
Mouser Electronics | Switching Voltage Regulators L N 2x S w/ Boost & Inv Ch Pumps RoHS: Compliant | 164 |
|
$15.5400 / $25.0000 | Buy Now |
|
|
Analog Devices Inc | L N 2x S w/ Boost & Inv Ch Pum Package Multiple: 73 | 815 |
|
$12.1400 / $24.8400 | Buy Now |
|
DISTI #
35217547
|
Verical | Charge Pump INV/STPUP 9V to 32V/-4.5V to -32V 50mA 18-Pin DFN EP Tube RoHS: Compliant Min Qty: 73 Package Multiple: 73 | Americas - 803 |
|
$15.2704 | Buy Now |
|
DISTI #
LTC3265MPDHCPBF
|
Richardson RFPD | DC TO DC CONVERTER RoHS: Compliant Min Qty: 73 | 0 |
|
$15.6800 / $18.2100 | Buy Now |
|
|
Vyrian | Other Function Semiconductors | 557 |
|
RFQ |
Part Details for LTC3265MPDHC#PBF
LTC3265MPDHC#PBF CAD Models
LTC3265MPDHC#PBF Part Data Attributes
|
|
LTC3265MPDHC#PBF
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
LTC3265MPDHC#PBF
Analog Devices Inc
Low Noise Dual Supply with Boost and Inverting Charge Pumps
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Package Description | DFN-18 | |
| Pin Count | 18 | |
| Manufacturer Package Code | 05-08-1955 | |
| Reach Compliance Code | compliant | |
| Samacsys Manufacturer | Analog Devices | |
| Additional Feature | ALSO VOUT=20 VOLT | |
| Analog IC - Other Type | SWITCHED CAPACITOR REGULATOR | |
| Input Voltage-Max | 16 V | |
| Input Voltage-Min | 4.5 V | |
| Input Voltage-Nom | 10 V | |
| JESD-30 Code | R-PDSO-N18 | |
| JESD-609 Code | e3 | |
| Length | 5 mm | |
| Number of Functions | 1 | |
| Number of Terminals | 18 | |
| Output Voltage-Nom | 18.8 V | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | HVSON | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE | |
| Seated Height-Max | 0.8 mm | |
| Surface Mount | YES | |
| Switcher Configuration | INVERTER | |
| Switching Frequency-Max | 500 kHz | |
| Technology | CMOS | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | NO LEAD | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | DUAL | |
| Width | 3 mm |
