LTC2325CUKG-16#TRPBF Information
LTC2325CUKG-16#TRPBF by Analog Devices Inc is an Analog to Digital Converter.
Analog to Digital Converters are under the broader part category of Converters.
A converter is an electrical circuit that transforms electric energy into a different form that will support a elecrical load needed by a device. Read more about Converters on our Converters part category page.
Price & Stock for LTC2325CUKG-16#TRPBF
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
LTC2325CUKG-16#TRPBF-ND
|
DigiKey | IC ADC 16BIT SAR 52QFN Min Qty: 2000 Lead time: 26 Weeks Container: Tape & Reel (TR) | Temporarily Out of Stock |
|
$26.5000 | Buy Now |
|
DISTI #
584-2325CUKG16TRPBF
|
Mouser Electronics | Analog to Digital Converters - ADC 4x, 16-B, 5Msps/Ch Simultaneous Smpl ADC RoHS: Compliant | 0 |
|
$28.1100 | Order Now |
|
|
Analog Devices Inc | 4x, 16-B, 5Msps/Ch Simultaneou Min Qty: 2000 Package Multiple: 2000 | 2000 |
|
$21.2000 / $30.2500 | Buy Now |
|
DISTI #
69262037
|
Verical | 4-Channel Quad ADC SAR 5Msps 16-bit Serial (SPI)/LVDS 52-Pin QFN EP T/R RoHS: Compliant Min Qty: 2000 Package Multiple: 2000 | Americas - 2000 |
|
$26.2214 | Buy Now |
|
DISTI #
LTC2325CUKG16TR
|
Richardson RFPD | CONVERTER - ADC RoHS: Compliant Min Qty: 2000 | 0 |
|
$27.3800 / $28.4500 | Buy Now |
|
|
Vyrian | Converters | 3295 |
|
RFQ | |
|
|
Win Source Electronics | IC ADC 16BIT SAR 52QFN | 62 |
|
$45.8793 / $68.8188 | Buy Now |
Part Details for LTC2325CUKG-16#TRPBF
LTC2325CUKG-16#TRPBF CAD Models
LTC2325CUKG-16#TRPBF Part Data Attributes
|
|
LTC2325CUKG-16#TRPBF
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
LTC2325CUKG-16#TRPBF
Analog Devices Inc
Quad, 16-Bit, 5Msps/Ch Simultaneous Sampling ADC
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Pin Count | 52 | |
| Manufacturer Package Code | 05-08-1729 | |
| Reach Compliance Code | compliant | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Analog Devices | |
| Analog Input Voltage-Max | 2.064 V | |
| Analog Input Voltage-Min | -2.034 V | |
| Conversion Time-Max | 0.17 µs | |
| Converter Type | ADC, SUCCESSIVE APPROXIMATION | |
| JESD-30 Code | R-PQCC-N52 | |
| JESD-609 Code | e3 | |
| Length | 8 mm | |
| Linearity Error-Max (EL) | 0.0137% | |
| Moisture Sensitivity Level | 1 | |
| Number of Analog In Channels | 4 | |
| Number of Bits | 16 | |
| Number of Functions | 1 | |
| Number of Terminals | 52 | |
| Operating Temperature-Max | 70 °C | |
| Operating Temperature-Min | ||
| Output Bit Code | BINARY | |
| Output Format | SERIAL | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | HVQCCN | |
| Package Shape | RECTANGULAR | |
| Package Style | CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Sample Rate | 5 MHz | |
| Sample and Hold / Track and Hold | SAMPLE | |
| Seated Height-Max | 0.8 mm | |
| Supply Voltage-Nom | 3.3 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Temperature Grade | COMMERCIAL | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | NO LEAD | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | QUAD | |
| Width | 7 mm |
