LTC1877IMS8#TRPBF Information
LTC1877IMS8#TRPBF by Analog Devices Inc is a Switching Regulator or Controller.
Switching Regulator or Controllers are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for LTC1877IMS8#TRPBF
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
505-LTC1877IMS8#TRPBFTR-ND
|
DigiKey | IC REG BUCK ADJ 600MA 8MSOP Min Qty: 2500 Lead time: 10 Weeks Container: Tape & Reel (TR) | Temporarily Out of Stock |
|
$5.3375 | Buy Now |
|
DISTI #
584-LTC1877IMS8TRPBF
|
Mouser Electronics | Switching Voltage Regulators Hi Eff Mono Sync Buck Reg RoHS: Compliant | 0 |
|
$5.3300 | Order Now |
|
|
Analog Devices Inc | Hi Eff Mono Sync Buck Reg Min Qty: 2500 Package Multiple: 2500 | 5000 |
|
$4.2700 / $11.8100 | Buy Now |
|
DISTI #
LTC1877IMS8TRPBF
|
TME | PMIC, DC/DC converter, Uin: 2.65÷10VDC, Uout: 0.8÷10VDC, 1A, MSOP8 Min Qty: 2500 | 0 |
|
$4.5600 | RFQ |
|
DISTI #
LTC1877IMS8TRPB
|
Richardson RFPD | DC TO DC CONVERTER RoHS: Compliant Min Qty: 2500 | 0 |
|
$5.5200 / $5.7300 | Buy Now |
Part Details for LTC1877IMS8#TRPBF
LTC1877IMS8#TRPBF CAD Models
LTC1877IMS8#TRPBF Part Data Attributes
|
|
LTC1877IMS8#TRPBF
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
LTC1877IMS8#TRPBF
Analog Devices Inc
High Efficiency Monolithic Synchronous Step-Down Regulator
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Package Description | LEAD FREE, PLASTIC, MSOP-8 | |
| Pin Count | 8 | |
| Manufacturer Package Code | 05-08-1660 | |
| Reach Compliance Code | compliant | |
| Samacsys Manufacturer | Analog Devices | |
| Additional Feature | ALSO OPERATES IN ADJUSTABLE MODE FROM 0.74 V TO 0.84 V | |
| Analog IC - Other Type | SWITCHING REGULATOR | |
| Control Mode | CURRENT-MODE | |
| Control Technique | PULSE WIDTH MODULATION | |
| Input Voltage-Max | 10 V | |
| Input Voltage-Min | 2.65 V | |
| Input Voltage-Nom | 5 V | |
| JESD-30 Code | S-PDSO-G8 | |
| JESD-609 Code | e3 | |
| Length | 3 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 8 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Current-Max | 1.5 A | |
| Output Voltage-Nom | 0.8 V | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | TSSOP | |
| Package Shape | SQUARE | |
| Package Style | SMALL OUTLINE, THIN PROFILE, SHRINK PITCH | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.1 mm | |
| Surface Mount | YES | |
| Switcher Configuration | BUCK | |
| Switching Frequency-Max | 605 kHz | |
| Technology | CMOS | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 3 mm |
Alternate Parts for LTC1877IMS8#TRPBF
This table gives cross-reference parts and alternative options found for LTC1877IMS8#TRPBF. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of LTC1877IMS8#TRPBF, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| TPS62020DGQ | Texas Instruments | $1.0878 | Adjustable, 600-mA, 95% Efficient Step-Down Converter, 18uA, MSOP-10 10-HVSSOP -40 to 85 | LTC1877IMS8#TRPBF vs TPS62020DGQ |
| LTC1877EMS8#TRPBF | Analog Devices Inc | $4.8929 | High Efficiency Monolithic Synchronous Step-Down Regulator | LTC1877IMS8#TRPBF vs LTC1877EMS8#TRPBF |
| LTC1877EMS8#PBF | Analog Devices Inc | $4.9026 | High Efficiency Monolithic Synchronous Step-Down Regulator | LTC1877IMS8#TRPBF vs LTC1877EMS8#PBF |
| LTC1877IMS8#PBF | Analog Devices Inc | $5.7112 | High Efficiency Monolithic Synchronous Step-Down Regulator | LTC1877IMS8#TRPBF vs LTC1877IMS8#PBF |
| LTC1877EMS8#TRPBF | Linear Technology | Check for Price | LTC1877 - High Efficiency Monolithic Synchronous Step-Down Regulator; Package: MSOP; Pins: 8; Temperature Range: -40°C to 85°C | LTC1877IMS8#TRPBF vs LTC1877EMS8#TRPBF |
| LTC1877EMS8#TR | Analog Devices Inc | Check for Price | Switching Regulator, Current-mode, 1.5A, 605kHz Switching Freq-Max, CMOS, PDSO8 | LTC1877IMS8#TRPBF vs LTC1877EMS8#TR |
| LTC1877EMS8 | Linear Technology | Check for Price | LTC1877 - High Efficiency Monolithic Synchronous Step-Down Regulator; Package: MSOP; Pins: 8; Temperature Range: -40°C to 85°C | LTC1877IMS8#TRPBF vs LTC1877EMS8 |
| LTC1877EMS8 | Analog Devices Inc | Check for Price | Switching Regulator, Current-mode, 1.5A, 605kHz Switching Freq-Max, CMOS, PDSO8 | LTC1877IMS8#TRPBF vs LTC1877EMS8 |
| LTC1877IMS8#TRPBF | Linear Technology | Check for Price | LTC1877 - High Efficiency Monolithic Synchronous Step-Down Regulator; Package: MSOP; Pins: 8; Temperature Range: -40°C to 85°C | LTC1877IMS8#TRPBF vs LTC1877IMS8#TRPBF |
| TPS62020DGQG4 | Texas Instruments | Check for Price | Adjustable, 600-mA, 95% Efficient Step-Down Converter, 18uA, MSOP-10 10-MSOP-PowerPAD -40 to 85 | LTC1877IMS8#TRPBF vs TPS62020DGQG4 |
