Part Details for LTC1759CG#PBF by Analog Devices Inc
Results Overview of LTC1759CG#PBF by Analog Devices Inc
- Distributor Offerings: (6 listings)
- Number of FFF Equivalents: (1 replacement)
- CAD Models: (Available)
- Number of Functional Equivalents: (4 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Consumer Electronics
LTC1759CG#PBF Information
LTC1759CG#PBF by Analog Devices Inc is a Switching Regulator or Controller.
Switching Regulator or Controllers are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for LTC1759CG#PBF
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
51AK6280
|
Newark | Battery Charger, Li-Ion, 8A, Ssop, Battery Type:Lead Acid, Li-Ion, Li-Pol, Nicd, Nimh, Input Voltage:24V, Battery Charge Voltage:32.7V, Charge Current:8.184A, Ic Case/Package:Ssop, No. Of Pins:36Pins, No. Of Cells:17Cells Rohs Compliant: Yes |Analog Devices LTC1759CG#PBF RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk | 80 |
|
$9.7400 / $17.6500 | Buy Now |
|
DISTI #
LTC1759CG#PBF-ND
|
DigiKey | IC BATT CHG SMART 1CEL 36SSOP Min Qty: 1 Lead time: 10 Weeks Container: Tube | Temporarily Out of Stock |
|
$9.7375 / $17.6500 | Buy Now |
|
DISTI #
584-LTC1759CG#PBF
|
Mouser Electronics | Battery Management Smart Bat Chr RoHS: Compliant | 106 |
|
$9.7300 / $16.8900 | Buy Now |
|
|
Analog Devices Inc | Smart Bat Chr Package Multiple: 37 | 2426 |
|
$7.7900 / $17.6500 | Buy Now |
|
|
Rochester Electronics | LTC1759 - Smart-Battery Charger RoHS: Compliant Status: Active Min Qty: 1 | 6 |
|
$8.2000 / $10.2500 | Buy Now |
|
DISTI #
LTC1759CG#PBF
|
Richardson RFPD | POWER MANAGEMENT IC RoHS: Compliant Min Qty: 37 | 0 |
|
$10.0600 / $11.6900 | Buy Now |
Part Details for LTC1759CG#PBF
LTC1759CG#PBF CAD Models
LTC1759CG#PBF Part Data Attributes
|
|
LTC1759CG#PBF
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
LTC1759CG#PBF
Analog Devices Inc
Smart Battery Charger
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Package Description | 0.209 INCH, PLASTIC, SSOP-36 | |
| Pin Count | 36 | |
| Manufacturer Package Code | 05-08-1640 (G36) | |
| Reach Compliance Code | compliant | |
| Samacsys Manufacturer | Analog Devices | |
| Analog IC - Other Type | BATTERY CHARGE CONTROLLER | |
| Control Mode | CURRENT-MODE | |
| Control Technique | PULSE WIDTH MODULATION | |
| Input Voltage-Max | 24 V | |
| Input Voltage-Min | 11 V | |
| Input Voltage-Nom | 18 V | |
| JESD-30 Code | R-PDSO-G36 | |
| JESD-609 Code | e3 | |
| Length | 12.8 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 36 | |
| Operating Temperature-Max | 70 °C | |
| Operating Temperature-Min | ||
| Output Current-Max | 0.2 A | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | SSOP | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, SHRINK PITCH | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 2 mm | |
| Surface Mount | YES | |
| Switcher Configuration | PUSH-PULL | |
| Switching Frequency-Max | 230 kHz | |
| Technology | CMOS | |
| Temperature Grade | COMMERCIAL | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 5.3 mm |
