LTC1668IG#PBF Information
LTC1668IG#PBF by Analog Devices Inc is a Digital to Analog Converter.
Digital to Analog Converters are under the broader part category of Converters.
A converter is an electrical circuit that transforms electric energy into a different form that will support a elecrical load needed by a device. Read more about Converters on our Converters part category page.
Price & Stock for LTC1668IG#PBF
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
51AK6246
|
Newark | Dac, 16Bit, Ssop-28, -40 To 85Deg C, Resolution (Bits):16Bit, Sampling Rate:50Msps, Data Interface:Serial, Supply Voltage Range:± 4.75V To ± 5.25V, Adc/Dac Case Style:Ssop, No. Of Pins:28Pins, Input Channel Type:Single Ended Rohs Compliant: Yes |Analog Devices LTC1668IG#PBF RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk | 0 |
|
$23.1500 / $34.5800 | Buy Now |
|
DISTI #
505-LTC1668IG#PBF-ND
|
DigiKey | IC DAC 16BIT A-OUT 28SSOP Min Qty: 1 Lead time: 10 Weeks Container: Tube |
1343 In Stock |
|
$23.1500 / $34.5800 | Buy Now |
|
DISTI #
584-LTC1668IG#PBF
|
Mouser Electronics | Digital to Analog Converters - DAC M RoHS: Compliant | 218 |
|
$24.2300 / $35.7100 | Buy Now |
|
|
Analog Devices Inc | M Package Multiple: 47 | 269 |
|
$18.5200 / $25.7300 | Buy Now |
|
DISTI #
LTC1668IG#PBF
|
Richardson RFPD | CONVERTER - DAC RoHS: Compliant Min Qty: 47 | 0 |
|
$23.9100 / $27.7800 | Buy Now |
|
DISTI #
SMC-LTC1668IG#PBF
|
Sensible Micro Corporation | AS6081 Certified Vendor, 1 Yr Warranty RoHS: Not Compliant Min Qty: 25 Lead time: 2 Weeks, 0 Days | 54 |
|
RFQ |
Part Details for LTC1668IG#PBF
LTC1668IG#PBF CAD Models
LTC1668IG#PBF Part Data Attributes
|
|
LTC1668IG#PBF
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
LTC1668IG#PBF
Analog Devices Inc
16-Bit, 50Msps DAC
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Package Description | 5.30 MM, PLASTIC, SSOP-28 | |
| Pin Count | 28 | |
| Manufacturer Package Code | 05-08-1640 (G28) | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Analog Devices | |
| Analog Output Voltage-Max | 1 V | |
| Analog Output Voltage-Min | -1 V | |
| Converter Type | D/A CONVERTER | |
| Input Bit Code | BINARY | |
| Input Format | PARALLEL, WORD | |
| JESD-30 Code | R-PDSO-G28 | |
| JESD-609 Code | e3 | |
| Length | 10.2 mm | |
| Linearity Error-Max (EL) | 0.0122% | |
| Moisture Sensitivity Level | 1 | |
| Negative Supply Voltage-Nom | -5 V | |
| Number of Bits | 16 | |
| Number of Functions | 1 | |
| Number of Terminals | 28 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | SSOP | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, SHRINK PITCH | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 2 mm | |
| Settling Time-Nom (tstl) | 0.02 µs | |
| Supply Voltage-Nom | 5 V | |
| Surface Mount | YES | |
| Technology | BICMOS | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 5.3 mm |
Alternate Parts for LTC1668IG#PBF
This table gives cross-reference parts and alternative options found for LTC1668IG#PBF. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of LTC1668IG#PBF, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| LTC1668CG#PBF | Analog Devices Inc | $19.3019 | 16-Bit, 50Msps DAC | LTC1668IG#PBF vs LTC1668CG#PBF |
| LTC1668IG | Linear Technology | $2.4016 | LTC1668 - 16-Bit, 50Msps DAC; Package: SSOP; Pins: 28; Temperature Range: -40°C to 85°C | LTC1668IG#PBF vs LTC1668IG |
| LTC1668CG#TRPBF | Analog Devices Inc | $30.3504 | 16-Bit, 50Msps DAC | LTC1668IG#PBF vs LTC1668CG#TRPBF |
| LTC1668CG#TR | Linear Technology | Check for Price | LTC1668 - 16-Bit, 50Msps DAC; Package: SSOP; Pins: 28; Temperature Range: 0°C to 70°C | LTC1668IG#PBF vs LTC1668CG#TR |
| LTC1668CG#PBF | Linear Technology | Check for Price | LTC1668 - 16-Bit, 50Msps DAC; Package: SSOP; Pins: 28; Temperature Range: 0°C to 70°C | LTC1668IG#PBF vs LTC1668CG#PBF |
| LTC1668IG#TR | Linear Technology | Check for Price | LTC1668 - 16-Bit, 50Msps DAC; Package: SSOP; Pins: 28; Temperature Range: -40°C to 85°C | LTC1668IG#PBF vs LTC1668IG#TR |
| LTC1668CG#TRPBF | Linear Technology | Check for Price | LTC1668 - 16-Bit, 50Msps DAC; Package: SSOP; Pins: 28; Temperature Range: 0°C to 70°C | LTC1668IG#PBF vs LTC1668CG#TRPBF |
| LTC1668IG#TR | Analog Devices Inc | Check for Price | D/A Converter, 1 Func, Parallel, Word Input Loading, 0.02us Settling Time, PDSO28 | LTC1668IG#PBF vs LTC1668IG#TR |
