LT1792ACS8#PBF Information
LT1792ACS8#PBF by Analog Devices Inc is an Operational Amplifier.
Operational Amplifiers are under the broader part category of Amplifier Circuits.
Amplifier circuits use external power to increase the amplitude of an input signal. They can be used to perform linear amplifications or logarithmic functions. Read more about Amplifier Circuits on our Amplifier Circuits part category page.
Price & Stock for LT1792ACS8#PBF
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
50AK5010
|
Newark | Op-Amp, 5.6Mhz, 0 To 70Deg C, Nsoic-8, No. Of Channels:1Channels, Gain Bandwidth Product:5.6Mhz, Supply Voltage Range:± 4.5V To ± 20V, Ic Case/Package:Nsoic, No. Of Pins:8Pins, Amplifier Type:Jfet, Rail To Rail:-, Product Range:- Rohs Compliant: Yes |Analog Devices LT1792ACS8#PBF RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk | 59 |
|
$6.8800 / $10.8400 | Buy Now |
|
DISTI #
LT1792ACS8#PBF-ND
|
DigiKey | IC OPAMP JFET 1 CIRCUIT 8SO Min Qty: 1 Lead time: 10 Weeks Container: Tube |
47 In Stock |
|
$6.0250 / $12.2700 | Buy Now |
|
DISTI #
584-LT1792ACS8#PBF
|
Mouser Electronics | Precision Amplifiers L N, Prec, JFET In Op Amp RoHS: Compliant | 0 |
|
$6.5300 / $10.6400 | Order Now |
|
DISTI #
V99:2348_06419178
|
Arrow Electronics | Op Amp Single Low Noise Amplifier ±20V 8-Pin SOIC N Tube RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 10 Weeks Date Code: 2234 | Americas - 80 |
|
$6.1170 / $8.3940 | Buy Now |
|
|
Analog Devices Inc | L N, Prec, JFET In Op Amp Package Multiple: 100 | 4010 |
|
$4.8200 / $12.2700 | Buy Now |
|
DISTI #
LT1792ACS8#PBF
|
Richardson RFPD | AMPLIFIER - OP AMPS RoHS: Compliant Min Qty: 100 | 0 |
|
$6.2200 / $6.8200 | Buy Now |
Part Details for LT1792ACS8#PBF
LT1792ACS8#PBF CAD Models
LT1792ACS8#PBF Part Data Attributes
|
|
LT1792ACS8#PBF
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
LT1792ACS8#PBF
Analog Devices Inc
Low Noise, Precision, JFET Input Op Amp
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Package Description | 0.150 INCH, PLASTIC, SO-8 | |
| Pin Count | 8 | |
| Manufacturer Package Code | 05-08-1610 (S8) | |
| Reach Compliance Code | compliant | |
| Samacsys Manufacturer | Analog Devices | |
| Amplifier Type | OPERATIONAL AMPLIFIER | |
| Average Bias Current-Max (IIB) | 0.0018 µA | |
| Common-mode Reject Ratio-Nom | 104 dB | |
| Input Offset Voltage-Max | 800 µV | |
| JESD-30 Code | R-PDSO-G8 | |
| JESD-609 Code | e3 | |
| Length | 4.9 mm | |
| Moisture Sensitivity Level | 1 | |
| Neg Supply Voltage Limit-Max | -20 V | |
| Neg Supply Voltage-Nom (Vsup) | -15 V | |
| Number of Functions | 1 | |
| Number of Terminals | 8 | |
| Operating Temperature-Max | 70 °C | |
| Operating Temperature-Min | ||
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | SOP | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.75 mm | |
| Slew Rate-Nom | 3.1 V/us | |
| Supply Voltage Limit-Max | 20 V | |
| Supply Voltage-Nom (Vsup) | 15 V | |
| Surface Mount | YES | |
| Technology | BIPOLAR | |
| Temperature Grade | COMMERCIAL | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 1.27 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Unity Gain BW-Nom | 4500 | |
| Width | 3.9 mm |
Alternate Parts for LT1792ACS8#PBF
This table gives cross-reference parts and alternative options found for LT1792ACS8#PBF. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of LT1792ACS8#PBF, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| LT1792ACS8#TRPBF | Analog Devices Inc | Check for Price | Low Noise, Precision, JFET Input Op Amp | LT1792ACS8#PBF vs LT1792ACS8#TRPBF |
LT1792ACS8#PBF Frequently Asked Questions (FAQ)
-
A good PCB layout for the LT1792ACS8 involves keeping the input and output traces short and separate, using a solid ground plane, and placing the bypass capacitors close to the device. A 4-layer PCB with a dedicated power plane and a dedicated ground plane is recommended.
-
To ensure stability, make sure to follow the recommended compensation network, use a minimum output capacitance of 10uF, and keep the input and output resistors within the recommended range. Also, avoid using long input traces and ensure that the device is properly decoupled.
-
The maximum power dissipation of the LT1792ACS8 is dependent on the ambient temperature and the thermal resistance of the package. For the SOIC-8 package, the maximum power dissipation is approximately 1.4W at 25°C ambient temperature.
-
The LT1792ACS8 is rated for operation up to 125°C junction temperature. However, the device's performance and reliability may degrade at high temperatures. It's recommended to derate the power dissipation and ensure proper heat sinking to maintain reliable operation.
-
To protect the LT1792ACS8 from overvoltage and overcurrent conditions, use a voltage regulator with overvoltage protection and a current limiter. Additionally, consider using a fuse or a PTC resistor in series with the input to prevent excessive current.
