LSF0108RKSR Information
LSF0108RKSR by Texas Instruments is an Other Interface IC.
Other Interface ICs are under the broader part category of Drivers And Interfaces.
A driver controls the current or voltage delivered to components like LCDs or motors, while an interface component connects systems for data transfer and control. Read more about Drivers And Interfaces on our Drivers And Interfaces part category page.
Price & Stock for LSF0108RKSR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
28AH3795
|
Newark | Volt Level Translator, Octal, Vqfn-20, No. Of Inputs:8, Output Current:-, Propagation Delay:1.5Ns, No. Of Pins:20Pins, Logic Case Style:Vqfn, Supply Voltage Min:0V, Supply Voltage Max:5V, Operating Temperature Min:-40°C, Operating Rohs Compliant: Yes |Texas Instruments LSF0108RKSR RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Cut Tape | 917 |
|
$1.3200 / $1.7100 | Buy Now |
|
DISTI #
296-37841-1-ND
|
DigiKey | IC TRANSLTR BIDIRECTIONAL 20VQFN Min Qty: 1 Lead time: 12 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
8594 In Stock |
|
$0.5863 / $1.2700 | Buy Now |
|
DISTI #
595-LSF0108RKSR
|
Mouser Electronics | Translation - Voltage Levels Octal Bidir Multi- V ltg Lev Translator RoHS: Compliant | 5786 |
|
$0.5890 / $1.2600 | Buy Now |
|
DISTI #
V72:2272_07295306
|
Arrow Electronics | Voltage Level Translator 8-CH Bidirectional 20-Pin VQFN EP T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 12 Weeks Date Code: 2413 Container: Cut Strips | Americas - 2029 |
|
$0.5799 / $1.1652 | Buy Now |
|
DISTI #
84377445
|
Verical | Voltage Level Translator 8-CH Bidirectional 20-Pin VQFN EP T/R RoHS: Compliant Min Qty: 11 Package Multiple: 1 Date Code: 2413 | Americas - 2029 |
|
$0.5799 / $0.8814 | Buy Now |
|
|
Quest Components | 1 FUNC, TRUE OUTPUT, PQCC20 | 104 |
|
$1.0688 / $2.1375 | Buy Now |
|
|
Quest Components | 1 FUNC, TRUE OUTPUT, PQCC20 | 103 |
|
$0.5985 / $1.2825 | Buy Now |
|
DISTI #
SMC-LSF0108RKSR
|
Sensible Micro Corporation | OEM Excess 5-7 Days Leadtime, We are an AS6081 Certified Vendor, 1 Yr Warranty RoHS: Not Compliant Min Qty: 25 Lead time: 2 Weeks, 0 Days | 13702 |
|
RFQ | |
|
|
LCSC | 1.8V5.5V 1 8 950mV4.5V VQFN-20(2.5x4.5) Translators Level Shifters ROHS | 7 |
|
$0.6717 / $0.7019 | Buy Now |
|
|
Vyrian | Interface ICs | 6970 |
|
RFQ |
Part Details for LSF0108RKSR
LSF0108RKSR CAD Models
LSF0108RKSR Part Data Attributes
|
|
LSF0108RKSR
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
LSF0108RKSR
Texas Instruments
Octal bidirectional multi-voltage-level translator 20-VQFN -40 to 125
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Texas Instruments | |
| Interface IC Type | VOLTAGE LEVEL TRANSLATOR | |
| JESD-30 Code | R-PQCC-N20 | |
| JESD-609 Code | e4 | |
| Length | 4.5 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Bits | 8 | |
| Number of Functions | 1 | |
| Number of Terminals | 20 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Characteristics | OPEN-DRAIN | |
| Output Polarity | TRUE | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | HVQCCN | |
| Package Equivalence Code | LCC20,.1X.18,20 | |
| Package Shape | RECTANGULAR | |
| Package Style | CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Seated Height-Max | 1 mm | |
| Supply Current-Max | 0.0125 mA | |
| Supply Voltage-Max | 4.5 V | |
| Supply Voltage-Min | 1 V | |
| Supply Voltage-Nom | 3.3 V | |
| Supply Voltage1-Max | 5.5 V | |
| Supply Voltage1-Min | 1.8 V | |
| Supply Voltage1-Nom | 3.3 V | |
| Surface Mount | YES | |
| Temperature Grade | AUTOMOTIVE | |
| Terminal Finish | Nickel/Palladium/Gold/Silver (Ni/Pd/Au/Ag) | |
| Terminal Form | NO LEAD | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | QUAD | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 2.5 mm |
