LMT01DQXR Information
LMT01DQXR by Texas Instruments is a Temperature Sensor.
Temperature Sensors are under the broader part category of Sensors/Transducers.
Sensors and transducers detect and measure physical quantities like temperature, pressure, and force, converting them into electrical signals for various applications. Read more about Sensors/Transducers on our Sensors/Transducers part category page.
Price & Stock for LMT01DQXR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
296-47665-1-ND
|
DigiKey | SENSOR DIGITAL -50C-150C 2WSON Min Qty: 1 Lead time: 12 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
1474 In Stock |
|
$1.0122 / $1.8200 | Buy Now |
|
DISTI #
595-LMT01DQXR
|
Mouser Electronics | Board Mount Temperature Sensors 0.5 C Accurate 2-pin Temperature Sensor A 595-LMT01DQXT RoHS: Compliant | 3211 |
|
$1.0100 / $1.8200 | Buy Now |
|
|
Win Source Electronics | SENSOR DIGITAL -50C-150C 2WSON / Temperature Sensor Digital, Local -50°C ~ 150°C 0.0625°C 2-WSON (1.7x2.5) | 7765 |
|
$1.3747 / $2.0619 | Buy Now |
Part Details for LMT01DQXR
LMT01DQXR CAD Models
LMT01DQXR Part Data Attributes
|
|
LMT01DQXR
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
LMT01DQXR
Texas Instruments
0.5°C Accurate 2-pin Temperature Sensor with a Pulse Train Interface 2-WSON -50 to 150
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Package Description | WSON-2 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Texas Instruments | |
| Accuracy-Max (Cel) | 0.5 Cel | |
| Body Breadth | 1.7 mm | |
| Body Height | 0.8 mm | |
| Body Length or Diameter | 2.5 mm | |
| Housing | PLASTIC | |
| JESD-609 Code | e3 | |
| Mounting Feature | SURFACE MOUNT | |
| Number of Bits | 13 | |
| Number of Terminals | 2 | |
| Operating Current-Max | 0.039 mA | |
| Operating Temperature-Max | 150 °C | |
| Operating Temperature-Min | -50 °C | |
| Output Interface Type | 1-WIRE INTERFACE | |
| Package Shape/Style | RECTANGULAR | |
| Sensors/Transducers Type | TEMPERATURE SENSOR,SWITCH/DIGITAL OUTPUT,SERIAL | |
| Supply Voltage-Max | 5.5 V | |
| Supply Voltage-Min | 2 V | |
| Surface Mount | YES | |
| Terminal Finish | Matte Tin (Sn) | |
| Termination Type | SOLDER |
