Part Details for LM5008ASD/NOPB by Texas Instruments
Results Overview of LM5008ASD/NOPB by Texas Instruments
- Distributor Offerings: (7 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Energy and Power Systems
Renewable Energy
LM5008ASD/NOPB Information
LM5008ASD/NOPB by Texas Instruments is a Switching Regulator or Controller.
Switching Regulator or Controllers are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for LM5008ASD/NOPB
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
296-LM5008ASD/NOPBCT-ND
|
DigiKey | IC REG BUCK ADJ 350MA 8WSON Min Qty: 1 Lead time: 12 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
1443 In Stock |
|
$1.8690 / $3.5400 | Buy Now |
|
DISTI #
926-LM5008ASD/NOPB
|
Mouser Electronics | Switching Voltage Regulators 100V 350Ma Buck Reg A 595-TMUX646NZECR RoHS: Compliant | 10 |
|
$1.8600 / $3.2900 | Buy Now |
|
DISTI #
J56:1989_00535328
|
Arrow Electronics | Conv DC-DC 6V to 95V Inv/Step Down Single-Out 2.5V to 75V 0.35A 8-Pin WSON EP T/R RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Lead time: 12 Weeks Date Code: 2330 | Europe - 2000 |
|
$1.6180 / $1.6660 | Buy Now |
|
DISTI #
V72:2272_07282029
|
Arrow Electronics | Conv DC-DC 6V to 95V Inv/Step Down Single-Out 2.5V to 75V 0.35A 8-Pin WSON EP T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 12 Weeks Date Code: 2316 Container: Cut Strips | Americas - 747 |
|
$1.7880 / $2.2440 | Buy Now |
|
|
Bristol Electronics | 1327 |
|
RFQ | ||
|
DISTI #
LM5008ASD/NOPB
|
TME | PMIC, DC/DC converter, Uin: 6÷95VDC, Uout: 2.5÷75VDC, 0.35A, WSON8 Min Qty: 1 | 0 |
|
$2.4800 / $3.7200 | RFQ |
|
|
Win Source Electronics | 100-V 350-mA Constant On-Time Buck Switching Regulator | 12000 |
|
$5.7184 / $8.5775 | Buy Now |
Part Details for LM5008ASD/NOPB
LM5008ASD/NOPB CAD Models
LM5008ASD/NOPB Part Data Attributes
|
|
LM5008ASD/NOPB
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
LM5008ASD/NOPB
Texas Instruments
6-95V Wide Vin, 350mA Constant On-Time Non-Synchronous Buck Regulator 8-WSON -40 to 125
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Package Description | WSON-8 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Texas Instruments | |
| Additional Feature | ALSO OPERATES IN ADJUSTABLE MODE FROM 2.5V | |
| Analog IC - Other Type | SWITCHING REGULATOR | |
| Input Voltage-Max | 95 V | |
| Input Voltage-Min | 6 V | |
| Input Voltage-Nom | 48 V | |
| JESD-30 Code | S-PDSO-N8 | |
| JESD-609 Code | e3 | |
| Length | 4 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 1 | |
| Number of Outputs | 1 | |
| Number of Terminals | 8 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Current-Max | 0.35 A | |
| Output Voltage-Max | 75 V | |
| Output Voltage-Min | 2.5 V | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | HVSON | |
| Package Shape | SQUARE | |
| Package Style | SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Seated Height-Max | 0.8 mm | |
| Surface Mount | YES | |
| Switcher Configuration | BUCK | |
| Switching Frequency-Max | 600 kHz | |
| Temperature Grade | AUTOMOTIVE | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | NO LEAD | |
| Terminal Pitch | 0.8 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 4 mm |
