LM3S9B96-IQC80-C5 Information
LM3S9B96-IQC80-C5 by Texas Instruments is a Microcontroller.
Microcontrollers are under the broader part category of Microcontrollers and Processors.
Microcontrollers (MCUs) are small, low-power integrated circuits used to control embedded systems. Microcontrollers are primarily used to automate and control devices. Read more about Microcontrollers and Processors on our Microcontrollers and Processors part category page.
Price & Stock for LM3S9B96-IQC80-C5
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
|
Component Electronics, Inc | IN STOCK SHIP TODAY | 70 |
|
$300.0000 / $461.5400 | Buy Now |
|
|
Vyrian | Peripheral ICs | 512 |
|
RFQ | |
|
|
Win Source Electronics | MCU 32-bit ARM Cortex M3 RISC 256KB Flash 1.3V/3.3V 100-Pin LQFP Tray / IC MCU 32BIT 256KB FLASH 100LQFP | 800 |
|
$500.5000 | Buy Now |
Part Details for LM3S9B96-IQC80-C5
LM3S9B96-IQC80-C5 CAD Models
LM3S9B96-IQC80-C5 Part Data Attributes
|
|
LM3S9B96-IQC80-C5
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
LM3S9B96-IQC80-C5
Texas Instruments
Stellaris LM3S Microcontroller 100-LQFP -40 to 85
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Part Package Code | QFP | |
| Package Description | LQFP-100 | |
| Pin Count | 100 | |
| Reach Compliance Code | compliant | |
| HTS Code | 8542.31.00.01 | |
| Samacsys Manufacturer | Texas Instruments | |
| Has ADC | YES | |
| Address Bus Width | ||
| Bit Size | 32 | |
| CPU Family | CORTEX-M3 | |
| Clock Frequency-Max | 25 MHz | |
| DAC Channels | NO | |
| DMA Channels | YES | |
| External Data Bus Width | ||
| JESD-30 Code | S-PQFP-G100 | |
| Length | 14 mm | |
| Moisture Sensitivity Level | 3 | |
| Number of I/O Lines | 65 | |
| Number of Terminals | 100 | |
| On Chip Program ROM Width | 8 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| PWM Channels | YES | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | LFQFP | |
| Package Equivalence Code | QFP100,.63SQ,20 | |
| Package Shape | SQUARE | |
| Package Style | FLATPACK, LOW PROFILE, FINE PITCH | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| RAM (bytes) | 98304 | |
| ROM (words) | 262144 | |
| ROM Programmability | FLASH | |
| Seated Height-Max | 1.6 mm | |
| Speed | 80 MHz | |
| Supply Current-Max | 170 mA | |
| Supply Voltage-Max | 3.6 V | |
| Supply Voltage-Min | 3.3 V | |
| Supply Voltage-Nom | 3.3 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | QUAD | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 14 mm | |
| uPs/uCs/Peripheral ICs Type | MICROCONTROLLER, RISC |
Alternate Parts for LM3S9B96-IQC80-C5
This table gives cross-reference parts and alternative options found for LM3S9B96-IQC80-C5. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of LM3S9B96-IQC80-C5, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| LM3S2B93-IQC80-C5 | Texas Instruments | Check for Price | Stellaris LM3S Microcontroller 100-LQFP -40 to 85 | LM3S9B96-IQC80-C5 vs LM3S2B93-IQC80-C5 |
| LM3S2B93-IQC80-C5T | Texas Instruments | Check for Price | Stellaris LM3S Microcontroller 100-LQFP -40 to 85 | LM3S9B96-IQC80-C5 vs LM3S2B93-IQC80-C5T |
| LM3S2B93-IQC80-C1T | Texas Instruments | Check for Price | 32-BIT, FLASH, 80MHz, MICROCONTROLLER, PQFP100, ROHS COMPLIANT, MS-026BED, LQFP-100 | LM3S9B96-IQC80-C5 vs LM3S2B93-IQC80-C1T |
| LM3S2B93-IQC80-C3 | Texas Instruments | Check for Price | 32-BIT, FLASH, 80MHz, MICROCONTROLLER, PQFP100, ROHS COMPLIANT, MO-026, LQFP-100 | LM3S9B96-IQC80-C5 vs LM3S2B93-IQC80-C3 |
| LM3S9B96-IQC80-C3T | Texas Instruments | Check for Price | 32-BIT, FLASH, 80MHz, RISC MICROCONTROLLER, PQFP100, MS-026BED, LQFP-100 | LM3S9B96-IQC80-C5 vs LM3S9B96-IQC80-C3T |
| LM3S2B93-IQC80-C3T | Texas Instruments | Check for Price | 32-BIT, FLASH, 80MHz, MICROCONTROLLER, PQFP100, ROHS COMPLIANT, MO-026, LQFP-100 | LM3S9B96-IQC80-C5 vs LM3S2B93-IQC80-C3T |
LM3S9B96-IQC80-C5 Frequently Asked Questions (FAQ)
-
The maximum operating frequency of the LM3S9B96 is 80 MHz.
-
The LM3S9B96 has 512 KB of flash memory.
-
The LM3S9B96 has 96 KB of SRAM.
-
Yes, the LM3S9B96 has a USB 2.0 full-speed device interface.
-
The power consumption of the LM3S9B96 varies depending on the operating frequency and mode, but it can be as low as 350 μA/MHz in active mode.
