LM397MF/NOPB Information
LM397MF/NOPB by Texas Instruments is a Comparator.
Comparators are under the broader part category of Amplifier Circuits.
Amplifier circuits use external power to increase the amplitude of an input signal. They can be used to perform linear amplifications or logarithmic functions. Read more about Amplifier Circuits on our Amplifier Circuits part category page.
Available Datasheets
| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| LM397MF/NOPB | Texas Instruments | Single General Purpose Voltage Comparator 5-SOT-23 -40 to 85 | |
| LM397MFX/NOPB | Texas Instruments | Single General Purpose Voltage Comparator 5-SOT-23 -40 to 85 | |
| DS96174CN/NOPB | Rochester Electronics LLC | DS96174 - Line Driver, 4 Func, 4 Driver, BIPolar, PDIP16 |
Price & Stock for LM397MF/NOPB
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
28AH3402
|
Newark | Ic, Comparator, Single, Smd, Comparator Type:General Purpose, No. Of Comparators:1 Comparator, Response Time:440Ns, Supply Voltage Range:5V To 30V, Comparator Case Style:Sot-23, No. Of Pins:5Pins, Ic Output Type:Cmos, Ttl, Operating Rohs Compliant: Yes |Texas Instruments LM397MF/NOPB RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 15736 |
|
$0.2000 | Buy Now |
|
DISTI #
LM397MF/NOPBCT-ND
|
DigiKey | IC COMPARATOR 1 GEN PUR SOT23-5 Min Qty: 1 Lead time: 6 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
15188 In Stock |
|
$0.5563 / $1.2000 | Buy Now |
|
DISTI #
926-LM397MF/NOPB
|
Mouser Electronics | Analog Comparators SGL GEN PURP VLTG CO MPARATOR A 926-LM397MFX/NOPB RoHS: Compliant | 23609 |
|
$0.5450 / $1.2000 | Buy Now |
|
DISTI #
J56:1989_00015413
|
Arrow Electronics | Comparator Single R-R O/P ±15V/30V 5-Pin SOT-23 T/R RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Lead time: 6 Weeks Date Code: 2318 | Europe - 77000 |
|
$0.5385 | Buy Now |
|
DISTI #
V72:2272_07275610
|
Arrow Electronics | Comparator Single R-R O/P ±15V/30V 5-Pin SOT-23 T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 6 Weeks Date Code: 2230 Container: Cut Strips | Americas - 49 |
|
$0.5385 / $1.1801 | Buy Now |
|
DISTI #
67461521
|
Verical | Comparator Single R-R O/P ±15V/30V 5-Pin SOT-23 T/R RoHS: Compliant Min Qty: 12 Package Multiple: 1 Date Code: 2230 | Americas - 49 |
|
$0.5385 / $0.8409 | Buy Now |
|
|
Bristol Electronics | 3063 |
|
RFQ | ||
|
|
Bristol Electronics | 400 |
|
RFQ | ||
|
|
Quest Components | COMPARATOR, 10000UV OFFSET-MAX, 940000NS RESPONSE TIME, PDSO5 | 233 |
|
$0.5597 / $1.1994 | Buy Now |
|
|
Quest Components | COMPARATOR, 10000UV OFFSET-MAX, 940000NS RESPONSE TIME, PDSO5 | 90 |
|
$0.3300 / $0.5500 | Buy Now |
Part Details for LM397MF/NOPB
LM397MF/NOPB CAD Models
LM397MF/NOPB Part Data Attributes
|
|
LM397MF/NOPB
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
LM397MF/NOPB
Texas Instruments
Single General Purpose Voltage Comparator 5-SOT-23 -40 to 85
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Part Package Code | SOT-23 | |
| Package Description | LEAD FREE, SOT-23, 5 PIN | |
| Pin Count | 5 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Texas Instruments | |
| Amplifier Type | COMPARATOR | |
| Average Bias Current-Max (IIB) | 0.4 µA | |
| Bias Current-Max (IIB) @25C | 0.25 µA | |
| Input Offset Voltage-Max | 7000 µV | |
| JESD-30 Code | R-PDSO-G5 | |
| JESD-609 Code | e3 | |
| Length | 2.92 mm | |
| Moisture Sensitivity Level | 1 | |
| Neg Supply Voltage Limit-Max | ||
| Neg Supply Voltage-Nom (Vsup) | ||
| Number of Functions | 1 | |
| Number of Terminals | 5 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Type | OPEN-COLLECTOR; OPEN-DRAIN | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | LSSOP | |
| Package Equivalence Code | TSOP5/6,.11,37 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, LOW PROFILE, SHRINK PITCH | |
| Packing Method | TR | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Response Time-Nom | 940000 ns | |
| Seated Height-Max | 1.22 mm | |
| Supply Current-Max | 1 mA | |
| Supply Voltage Limit-Max | 30 V | |
| Supply Voltage-Nom (Vsup) | 5 V | |
| Surface Mount | YES | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.953 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 1.6 mm |
