LM26CIM5-SHA/NOPB Information
LM26CIM5-SHA/NOPB by Texas Instruments is a Temperature Sensor.
Temperature Sensors are under the broader part category of Sensors/Transducers.
Sensors and transducers detect and measure physical quantities like temperature, pressure, and force, converting them into electrical signals for various applications. Read more about Sensors/Transducers on our Sensors/Transducers part category page.
Available Datasheets
| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| DS96174CN/NOPB | Rochester Electronics LLC | DS96174 - Line Driver, 4 Func, 4 Driver, BIPolar, PDIP16 | |
| LM611IM/NOPB | Rochester Electronics LLC | LM611IM - Operational Amplifier, 7000uV Offset-Max, BIPolar |
Price & Stock for LM26CIM5-SHA/NOPB
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
LM26CIM5-SHA/NOPBCT-ND
|
DigiKey | THERMOSTAT 70DEGC ACT LO SOT23-5 Min Qty: 1 Lead time: 6 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
3225 In Stock |
|
$0.5817 / $1.0500 | Buy Now |
|
DISTI #
926-LM26CIM5SHANOPB
|
Mouser Electronics | Thermostats Accurate Factory Pre set Thermostat RoHS: Compliant | 1809 |
|
$0.5940 / $0.9700 | Buy Now |
|
DISTI #
V72:2272_07270220
|
Arrow Electronics | Preset Thermostat 5-Pin SOT-23 T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 6 Weeks Date Code: 2202 Container: Cut Strips | Americas - 364 |
|
$0.5579 / $0.5939 | Buy Now |
|
DISTI #
61564966
|
Verical | Preset Thermostat 5-Pin SOT-23 T/R RoHS: Compliant Min Qty: 11 Package Multiple: 1 Date Code: 2202 | Americas - 364 |
|
$0.5579 / $0.5730 | Buy Now |
|
|
LCSC | SOT-23-5 Thermostat Switches ROHS | 231 |
|
$0.6550 / $1.1728 | Buy Now |
|
|
Vyrian | Sensors & Transducers | 6214 |
|
RFQ |
Part Details for LM26CIM5-SHA/NOPB
LM26CIM5-SHA/NOPB CAD Models
LM26CIM5-SHA/NOPB Part Data Attributes
|
|
LM26CIM5-SHA/NOPB
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
LM26CIM5-SHA/NOPB
Texas Instruments
±3°C Factory preset trip point temperature switch with analog output 5-SOT-23 -55 to 125
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Texas Instruments | |
| Accuracy-Max (Cel) | 3 Cel | |
| Additional Feature | CMOS COMPATIBLE | |
| Body Breadth | 1.6 mm | |
| Body Height | 1.45 mm | |
| Body Length or Diameter | 2.9 mm | |
| Housing | PLASTIC | |
| JESD-609 Code | e3 | |
| Mounting Feature | SURFACE MOUNT | |
| Number of Terminals | 5 | |
| Operating Current-Max | 0.04 mA | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -55 °C | |
| Output Voltage-Max | 0.4 V | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Equivalence Code | TSOP5/6,.11,37 | |
| Package Shape/Style | RECTANGULAR | |
| Sensors/Transducers Type | TEMPERATURE SENSOR,SWITCH/DIGITAL OUTPUT,SINGLE TRIP POINT | |
| Supply Voltage-Max | 5.5 V | |
| Supply Voltage-Min | 2.7 V | |
| Surface Mount | YES | |
| Terminal Finish | Matte Tin (Sn) | |
| Termination Type | SOLDER |
Alternate Parts for LM26CIM5-SHA/NOPB
This table gives cross-reference parts and alternative options found for LM26CIM5-SHA/NOPB. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of LM26CIM5-SHA/NOPB, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| LM26CIM5-SHA | Texas Instruments | Check for Price | SOT-23, ?3?C Accurate, Factory Preset Thermostat 5-SOT-23 -55 to 125 | LM26CIM5-SHA/NOPB vs LM26CIM5-SHA |
