Part Details for LM2574MX-5.0/NOPB by Texas Instruments
Results Overview of LM2574MX-5.0/NOPB by Texas Instruments
- Distributor Offerings: (9 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Education and Research
Internet of Things (IoT)
Computing and Data Storage
Aerospace and Defense
Healthcare
Telecommunications
Automotive
LM2574MX-5.0/NOPB Information
LM2574MX-5.0/NOPB by Texas Instruments is a Switching Regulator or Controller.
Switching Regulator or Controllers are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for LM2574MX-5.0/NOPB
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
LM2574MX-5.0/NOPBCT-ND
|
DigiKey | IC REG BUCK 5V 500MA 14SOIC Min Qty: 1 Lead time: 6 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
1186 In Stock |
|
$1.3466 / $2.6500 | Buy Now |
|
DISTI #
926-LM2574MX-5.0NOPB
|
Mouser Electronics | Switching Voltage Regulators 0.5A STEP-DOWN VLTG REG A 926-LM2574M-5.0/NOPB RoHS: Compliant | 11157 |
|
$1.3900 / $2.6500 | Buy Now |
|
|
Quest Components | SWITCHING REGULATOR, VOLTAGE-MODE, 1.8A, 63KHZ SWITCHING FREQ-MAX, BIPOLAR, PDSO14 | 800 |
|
$5.0670 / $10.1340 | Buy Now |
|
DISTI #
LM2574MX-5.0/NOPB
|
TME | PMIC, DC/DC converter, Uin: 4÷40VDC, Uout: 5VDC, 0.5A, SO14-W, SMD Min Qty: 1 | 1000 |
|
$1.3700 / $2.0700 | Buy Now |
|
|
Chip 1 Exchange | INSTOCK | 2649 |
|
RFQ | |
|
|
LCSC | Step-down type Fixed 5V 500mA 4V40V SOIC-14-300mil DC-DC Converters | 407 |
|
$0.7875 / $1.4393 | Buy Now |
|
|
New Advantage Corporation | IC-2574 V.REG. 0.5A 5V STEP DOWN SO14 SMD RoHS: Compliant Min Qty: 1 Package Multiple: 100 | 1326 |
|
$3.7900 / $4.1000 | Buy Now |
|
|
Vyrian | Other Function Semiconductors | 2610 |
|
RFQ | |
|
|
Win Source Electronics | IC REG BUCK 5V 0.5A 14-SOIC | 27290 |
|
$0.7809 / $1.0085 | Buy Now |
Part Details for LM2574MX-5.0/NOPB
LM2574MX-5.0/NOPB CAD Models
LM2574MX-5.0/NOPB Part Data Attributes
|
|
LM2574MX-5.0/NOPB
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
LM2574MX-5.0/NOPB
Texas Instruments
8V to 40V, 500mA SIMPLE SWITCHER® buck converter with 4 external components 14-SOIC -40 to 125
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Part Package Code | SOIC | |
| Package Description | 0.300 INCH, GREEN, PLASTIC, SOP-14 | |
| Pin Count | 14 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Texas Instruments | |
| Analog IC - Other Type | SWITCHING REGULATOR | |
| Control Mode | VOLTAGE-MODE | |
| Control Technique | PULSE WIDTH MODULATION | |
| Input Voltage-Max | 40 V | |
| Input Voltage-Min | 4 V | |
| Input Voltage-Nom | 12 V | |
| JESD-30 Code | R-PDSO-G14 | |
| JESD-609 Code | e3 | |
| Length | 9 mm | |
| Moisture Sensitivity Level | 3 | |
| Number of Functions | 1 | |
| Number of Outputs | 1 | |
| Number of Terminals | 14 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Current-Max | 0.5 A | |
| Output Voltage-Max | 37 V | |
| Output Voltage-Min | 3.3 V | |
| Output Voltage-Nom | 5 V | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | SOP | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 2.65 mm | |
| Surface Mount | YES | |
| Switcher Configuration | BUCK | |
| Switching Frequency-Max | 52 kHz | |
| Temperature Grade | AUTOMOTIVE | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 1.27 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 7.5 mm |
LM2574MX-5.0/NOPB Frequently Asked Questions (FAQ)
-
The maximum input voltage that can be applied to the LM2574MX-5.0/NOPB is 40V. Exceeding this voltage can cause damage to the device.
-
To ensure the stability of the output voltage, it is recommended to use a minimum output capacitance of 10uF with an ESR of less than 1 ohm. Additionally, the output voltage can be stabilized by adding a 10nF capacitor between the output and ground.
-
The maximum output current that the LM2574MX-5.0/NOPB can provide is 3A. Exceeding this current can cause overheating and damage to the device.
-
The input capacitor value can be calculated using the formula: Cin = (Iout x ΔI) / (f x ΔV), where Cin is the input capacitance, Iout is the output current, ΔI is the ripple current, f is the switching frequency, and ΔV is the input voltage ripple.
-
The feedback pin (FB) is used to regulate the output voltage. It is connected to the output voltage through a resistive divider network, which sets the output voltage. The FB pin is also used to monitor the output voltage and adjust the switching frequency accordingly.
